INSTALLATION INSTRUCTIONS

70-9800

WIRING INSTRUCTIONS

From the aftermarket radio to the wiring harness:

• Connect the Black wire to the ground wire.

• Connect the Yellow wire to the battery wire.

• Connect the Red wire to the accessory wire.

• Connect the Gray wire to the right front positive speaker output.

• Connect the Gray/Black wire to the right front negative speaker output.

• Connect the White wire to the left front positive speaker output.

• Connect the White/Black wire to the left front negative speaker output.

12-pin pre-wired ASWC-1 harness:

This harness is only to be used along with the ASWC-1 (sold separately) to retain

handlebar audio controls. Please note that “handlebar control” is also referred to as

“steering wheel control”.

• For the radios listed below, connect the included

female 3.5mm connector with

stripped leads

provided with the ASWC-1, to the male 3.5mm SWC jack. Any

remaining wires tape off and disregard:

•

Eclipse: Connect the steering wheel control wire, normally Brown, to the

Brown/White wire of the connector. Then connect the remaining steering

wheel control wire, normally Brown/White, to the Brown wire of the connector.

•

Metra OE: Connect the steering wheel control Key 1 wire (Gray) to the Brown wire

• Kenwood or select JVC with a steering wheel control wire: Connect the Blue/

Yellow wire to the Brown wire.

• XITE: Connect the steering wheel control SWC-2 wire from the radio to the

Brown wire.

• Parrot Asteroid Smart or Tablet: Connect the 3.5mm jack into the AX-SWC-

PARROT (sold separately), and then connect the 4-pin connector from the

AX-SWC-PARROT into the radio.

Note:

The radio must be updated to rev. 2.1.4 or higher software.

• Universal “2 or 3 wire” radio: Connect the steering wheel control wire,

referred to as Key-A or SWC-1, to the Brown wire of the connector. Then

connect the remaining steering wheel control wire, referred to as Key-B or

SWC-2, to the Brown/White wire of the connector. If the radio comes with a

third wire for ground, disregard this wire.

Note:

After the interface has been programmed to the vehicle, refer to the

manual provided with the radio for assigning the SWC buttons. Contact the

radio manufacturer for more information.

• For all other radios: Connect the 3.5mm jack into the jack on the aftermarket

radio designated for an external steering wheel control interface. Please refer to

the aftermarket radios manual if in doubt as to where the 3.5mm jack goes to.

Continued on next page

386.257.1187

MetraOnline.com

WIRING INSTRUCTIONS

• Program the ASWC-1:

a. Turn the ignition on, the LED will start ﬂashing rapidly, which means the ASWC-1

is looking for the vehicle and the radio.

Note:

If the LED did not start ﬂashing rapidly, press the reset button for 3 seconds

b. After a few seconds the LED should stop ﬂashing rapidly, and then go out for

approximately 2 seconds.

c. After approximately 2 seconds there will be a series of 7 Green ﬂashes, some

short, and some long. The long ﬂashes represent the wires that are connected to

the ASWC-1.

Tip:

Knowing this will help to troubleshoot, if need be.

d. The LED will pause for another 2 seconds, and then ﬂash Red up to 18 times

depending on which radio is connected to the ASWC-1. Refer to the L.E.D.

feedback section for information.

e. This is the end of the auto detection stage. If the ASWC-1 detected the vehicle

and the radio successfully, the L.E.D. will light up solid.

f. Test the handlebar controls for proper operation. Refer to the “Programming

Information” document online at axxessinterfaces.com for customizing the

buttons, if so desired.

L.E.D. Feedback

The (18) Red L.E.D. ﬂashes represent which brand radio the ASWC-1 is connected to. Each ﬂash

represents a different radio manufacturer. For example, if you are installing a JVC radio, the

ASWC-1 will ﬂash Red (5) times, and then stop. Following is a legend that dictates which radio

manufacturer corresponds to which ﬂash.

L.E.D. Feedback Legend

* Note:

If the ASWC-1 ﬂashes Red (7) times, and you do not have an Alpine radio connected to it, that

means the ASWC-1 does not detect a radio connected it. Verify that the 3.5mm jack is connected to the

correct steering wheel jack/wire in the radio.

** Note:

The AX-SWC-PARROT is required (sold separately). Also, the Parrot radio must be updated to

rev. 2.1.4 or higher through www.parrot.com.

† Note:

If you have a Clarion radio and the handlebar controls do not work, change the radio type to the

other Clarion radio type; same for Eclipse. Refer to the “Programming Information” document online

‡ Note:

If you have a Kenwood radio and the L.E.D. feedback comes back as showing as a JVC radio,

change the radio type to a Kenwood. Refer to the “Programming Information” document online.

1 ﬂash - Eclipse (Type 1) †

2 ﬂashes - Kenwood ‡

3 ﬂashes - Clarion (Type 1) †

4 ﬂashes - Sony / Dual

5 ﬂashes - JVC

ﬂashes -

Pioneer / Jensen

7 ﬂashes - Alpine *

8 ﬂashes - Visteon

9 ﬂashes - Valor

10 ﬂashes - Clarion (Type 2) †

11 ﬂashes - Metra OE

12 ﬂashes - Eclipse (Type 2) †

13 ﬂashes - LG

14 ﬂashes - Parrot **

15 ﬂashes - XITE

16 ﬂashes - Philips

17 ﬂashes - TBD

18 ﬂashes - JBL

REV. 4/8/22 INST70-9800 3

WIRING INSTRUCTIONS (CONT)

INSTALLATION INSTRUCTIONS

70-9800

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.edu or call

386-672-5771 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certiﬁed technicians

Having difﬁculties? We’re here to help.

Contact our Tech Support line at:

386-257-1187

Or via email at:

techsupport@metra-autosound.com

Tech Support Hours (Eastern Standard Time)

Monday - Friday: 9:00 AM - 7:00 PM

Saturday: 10:00 AM - 7:00 PM

Sunday: 10:00 AM - 4:00 PM
