INSTALLATION INSTRUCTIONS FOR PART 99-3042

APPLICATIONS

REV. 10/5/2012 INST99-3042

CAUTION: Metra recommends disconnecting the

negative battery terminal before beginning any

installation. All accessories, switches, and especially

air bag indicator lights must be plugged in before

reconnecting the battery or cycling the ignition.

NOTE: Refer to the instructions included with the

aftermarket radio.

• DINheadunitprovision

• Rearsupportprovision

•A)Radiohousing•B)Rearsupportbullet

KIT FEATURES

KIT COMPONENTS

WIRING & ANTENNA CONNECTIONS(soldseparately)

WiringHarness:

•70-1858-GMharnessforselect1988-2002

•70-1677-1-GM/Chevyharnessselect1978-1993

AntennaAdapter:

•40-GM10-GMadaptorforselect1988-2006

•Torxdriver•Phillipsscrewdriver•Cuttingtool

•Socketwrench

TOOLS REQUIRED

Chevrolet/GMC/Pontiac/Saturn 1982-1994

99-3042

See application list inside

Applications

Chevrolet

Camaro............................ 1982-1992/1982-1984/1985-1992

S-10Blazer.......................................................... 1986-1994

S-10Pickup.......................................................... 1986-1993

GMC

Jimmy.................................................................. 1986-1994

S-15Pickup.......................................................... 1986-1994

Oldsmobile

Bravada................................................................ 1991-1994

Pontiac

Firebird...............................................1982-1992/1985-1992

Saturn

(allmodels)........................................................... 1991-1994

Table of Contents

Dash Disassembly

-ChevroletCamaro1982-1992/1982-1984/1985-1992.......2

-ChevroletS-10Blazer1986-1994......................................3

-ChevroletS-10Pickup1986-1993.....................................3

-GMCJimmy1986-1994.....................................................3

-GMCS-15Pickup1986-1994............................................3

-OldsmobileBravada1991-1994.........................................3

-PontiacFirebird1982-1984/Firebird1985-1992................2

-Saturn(Allmodels)1991-1994..........................................3

Kit Assembly

-DINheadunitprovision......................................................3

Chevrolet Camaro 1982-1992/Pontiac

Firebird 1982-1992

99-3042 Dash Disassembly

(Figure B) (Figure C)(Figure A)

Fig. A

Fig. B

Fig. A

Fig. B

STEP 1

Camaro 1982-1992,

Firebird 1982-1984:

• Remove(4)torxhead

screwsfromtheradio

trimbezel.

• Remove(4)hexhead

screwssecuringthe

factoryradiodummy

plateandremovethe

plate.(FigureA)

Firebird 1985-1992:

• Uncliptheradio

trimbezelandremove

thebezel.

• Remove(4)hex-head

screwssecuringthe

factoryradiodummy

plateandremovethe

plate.(FigureB)

Continue to Step 2

STEP 2

Camaro 1985-1992,

Firebird 1985-1992:

• Cutandremoveall

mountingtabsonthe

radiohousingexcept

tabs“C”.(FigureC)

Camaro 1982-1984,

Firebird 1982-1984:

• Cutandremoveall

mountingtabsonthe

radiohousingexcept

tabs“D”.(FigureC)

Continue to kit assembly

Identify mounting tabs by

the stamped letter on the

back of each tab.

“C, D”

Dash Disassembly

"B"

“B”

1. Unclipthedashtrimbezel.(FigureA)

2. Remove(4)hexheadscrewssecuringthefactory

headunitanddisconnectthewiring.

3. Cutandremoveallmountingtabsontheradio

housingEXCEPTtabs“A”.(FigureB)

Continue to kit assembly

Chevrolet S-10 Pickup 1986-

1993, Chevrolet S-10 Blazer/

GMC S-15 Pickup/Jimmy

1986-1994, Oldsmobile

Bravada 1991-1994

(Figure A)

4. Remove(4)Phillipsheadscrewssecuringthe

radio.Disconnectandremovetheradio.

Continue to kit assembly

Saturn (all models) 1991-1994

(Figure A)

(Figure B)

"A"

“A”

(Figure B)

Kit Assembly

(Figure A)

(Figure B)

MetraorAXXESS.Re-connectthenegativebattery

terminalandtesttheunitforproperoperation.

5.Screwtherearsupportbulletontotheboltonthe

backoftheaftermarketheadunit(“A”).

6.Mounttheradio/kitassemblytothesub-dashwith

thosescrewspreviouslyremoved.(FigureB)

7.Reassembledashinreverseorderofdisassembly.

1. Unclippowerwindowcontrolpanel.Disconnect

andremovepanel.

2. Pulloffclimatecontrolknobs.

3. Unclipandremovethedashtrimpanel.(FigureA)

Saturn (all models) 1991-1994

Kit Assembly

DIN head unit provision

1.Cutandremovetheshaftsupportsfromthe

radiohousing.

2.SlidetheDINcageintothekitandsecureby

bendingthemetallockingtabsdown.(FigureA)

3.Slidetheaftermarketheadunitintothecageuntil

secure.(FigureA)

4.Locatethefactorywiringharnessinthedash.Metra

recommendsusingthepropermatingadapterfrom

INSTALLATION INSTRUCTIONS FOR PART 99-3042

REV. 10/5/2012 INST99-3042

KNOWLEDGE IS POWER

Enhance your installation and fabrication skills by

enrolling in the most recognized and respected

mobile electronics school in our industry.

Log onto www.installerinstitute.com or call

800-354-6782 for more information and take steps

toward a better tomorrow.

Metra recommends MECP

certiﬁed technicians
