INSTALLATION INSTRUCTIONS FOR PART 99-7009

Phillips Screwdriver I Socket Wrench

1-800-221-0932 www.metraonline.com

KIT FEATURES

APPLICATIONS

2004-2007 Mitsubishi Endeavor

• DIN Head Unit Provisions

• ISO DIN Head Unit Provisions

A) Radio Housing I B) ISO Brackets I C) Trim Plate

KIT COMPONENTS

TOOLS REQUIRED:

99-7009

•

Dash Disassembly

- 2004-2007 Mitsubishi Endeavor---------------------------------- 1

•

Kit Assembly

- ISO Head Unit Provision with Pocket ---------------------------- 2

- DIN Head Unit Provision with Pocket ---------------------------- 3

•

Final Assembly ------------------------------------------------------ 4

• Notes ---------------------------------------------------------------- 5

TSTNETN

99-7009

2004-2007 MITSUBISHI ENDEAVOR

Disconnect the negative battery terminal

to prevent an accidental short circuit.

Unsnap and remove entire panel sur-

rounding radio and A/C controls.

(Figure A)

Remove (1) 10MM nut from the rear support

on the top left of radio on cross bar behind

dash. (FIGURE B)

Remove (3) Phillips screws to remove

factory radio chassis (Figure C)

Remove (4) Phillips screws from the pock-

et at the bottom of the radio and A/C panel

and remove the pocket. (This is where the

99-7009 will be mounted.) (Figure D)

99-7009

KIT ASSEMBLY

DIN Head Unit Provision

1Slide the DIN cage into the Radio

Housing and secure by bending

the metal locking tabs down.

2Slide the after-market head unit

into the cage and secure. Snap

trim plate into the radio housing.

Using the factory hardware, mount

the 99-7009 in the location where

the factory pocket resided.

99-7009

ISO DIN HEAD UNIT PROVISION

1Mount the ISO Brackets to the head

unit with the screws supplied with

the unit.

2Slide the head unit into the radio

opening until the side clips engage.

3Snap the Trim plate into the Radio

Housing.

99-7009

ESS

A LAN

Locate the factory wiring harness in the dash.

Metra recommends using the proper mating

adapter and making the connections as

shown. (Isolate and individually tape off the

ends of any unused wires to prevent electrical

short circuit) See figure A.

Re-connect the negative battery terminal and test

the unit for proper operation.

A) Strip wire ends back 1/2"

B) Twist ends together

C) Solder

D) Tape

Reassemble radio and dash assemblies in

reverse order of disassembly.

99-7009

NOTES

INST997009

1-800-221-0932 www.metraonline.com
