P7 FLEX

INSTALLATION

INSTRUCTIONS

USER GUIDE

for details.

MIDEA

2 in 1

Cordless Handstick

2 in 1

Cordless Handstick

PLEASE READ THE

MANUAL CAREFULLY

BEFORE USING AND

KEEP IT PROPERLY FOR

FUTURE USE

EN, PL, CZ, SK, HU, RU, UK, ET, LT, LV, RO, SL

MCS2129BR

English..................................................................

Polish...................................................................

Czech................................................................

Slovakian..........................................................

Hungarian........................................................

Russian..............................................................

Ukrainian..........................................................

Estonian............................................................

Lithuanian......................................................

Latvian..............................................................

Romanian.......................................................

Slovenian.......................................................

3-13

14-25

26-37

38-49

50-61

62-73

74-85

86-97

98-109

110-121

122-133

134-145

Safety Instructions

- Do not place the vacuum cleaner close to heat sources, radiation

sources or burning cigarette butts. Sucking in the following objects is

strictly forbidden:

1. All liquids such as water and solvent;

2. Construction dust and trash such as lime and cement dust.

3. Heat sources, such as carbon butts and cigarette butts that have

not been put out.

4. Sharp fragments, such as glass.

5. Flammable and explosive articles, such as gasoline and alcohol

products.

- This product can only be disassembled by authorized technical

personnel. Disassembling without guidance is strictly forbidden.

- Children, persons with reduced phycial, sensory or mental

capabilities, and persons who lack knowledge and/or experience of

using household appliances are strictly forbidden to use this product

without special guidance!

- This product is an indoor household product, please do not use it

outdoors.

- The vacuum cleaner is an electric appliance that must be used under

normal use conditions. Do not leave it unattended while running.

- Do not touch the power cord, socket or power adapter with wet hands.

- Clean the dust cup when it is full before using this product.

- Turn off the power when cleaning, repairing or not using the vacuum

cleaner.

- Do not immerse the vacuum cleaner in water or place it near heat

sources or in the sun, so as to avoid fire.

- Use only the original power adapter that comes with the package for

this product. Use of other adapters may damage this product.

- Turn off the power when taking out the battery. Do not disassemble

the battery by yourself. If you need Please contact the after-sales

maintenance personnel for replacement if needed. Please properly

dispose of the battery when discarding the product.

- Do not touch the pole piece or jack with conductors to avoid short

circuit.

Safety Instructions

- Power cut-off: Do not pull the power cord, hold the plastic part of the

plug with your hand and unplug the plug.

- Do not pass the power cord of the vacuum cleaner through sharp

objects, so as not to damage the power cord.

- Do not drag the power cord to move the charging base.

- Check the power supply voltage to ensure the same voltage as the

charging voltage of the vacuum cleaner.

- Avoid running for a long time when the suction inlet is blocked, so

as to avoid motor damage and heating deformation of the vacuum

cleaner.

- Do not use the vacuum cleaner and send it to the maintenance

department designated by Midea for maintenance in time under the

following circumstances:

1. The vacuum cleaner has obvious damage or abnormal operation

condition after falling to the floor

2. The power cord is damaged.

Tips

1. Longer charging time may be needed in the following circumstances.

a. When charging in a place where the indoor temperature exceeds

30°C;

b. When charging immediately after stopping running.

2. Please charge the vacuum cleaner after using no matter how long

it is used.

3. When not charging, it is recommended to unplug the power plug

in time.

4. If the vacuum cleaner is not in use for a long time (more than

2 months), please unplug the power plug, but in order to ensure

the battery life, please fully charge it every 2 months.

5. During charging, the machine or the power adapter may heat up,

which is a normal phenomenon. Please rest assured to use it.

Introduction to the Product

Installation and Parts

Battery pack

Main unit

Bent pipe

Electric scrubbing brush

List of accessories

Bed brush 2-in-1 suction

brush

Storage buckle

assembly Flat nozzle Storage base

assembly Power adapter Instructions

Function Operation

Use of bent pipe

Pull upwards the upper sleeve of the bent pipe, and the bent

pipe automatically rotates and bends.

Battery charging

Note

1. The battery is not charged when leaving the factory, so please fully charge the bat-

4. When the battery life of the machine is obviously shortened and the charging time

is prolonged, please replace the battery with professionals. Do not disassemble and

assemble the machine by yourself to avoid danger.

S/N Operation Instructions

Plug one end of the power cord into the

socket and insert the other end into the

charging port at the tail of the handle on the

a period of full power, the indicator will go

out.

Charging time: 5-7 hours

Discharge time: About 10 minutes for High

Speed About 20 minutes for

Intermediate SpeedAbout 60

minutes for Low-Speed

Function Operation

Cleaning

Note

1. To avoid blocking the air duct, please clean up large pieces of garbage (such as large piec-

4. It is strictly forbidden to remodel the complete machine, accessories and replace the power

5. Battery model: BP28825A

S/N Use of the machine

Press the "Switch button" once to start;

Press the "Switch button" again to stop;

it is an alarm that requires professional

maintenance.

It defaults to the Intermediate Speed when

powered on with a full battery (Light 1, 2, and 3

are on simultaneously). Press the "Speed control

button" once for High Speed (Light 1 and 2 is

on and Light 3 is blue), and press the "Speed

control button" again for Low Speed (Light 1 and

2 is on and Light 3 is off);

Energy indication during charging:

battery is low, and it needs to continue charging.

When Light 1 and 2 are on, the battery is fully

charged, and the lights will go out after a period

of full charge.

Energy indication during operation (discharge):

When Light 1 and 2 are on, it shows that the

or Light 2 goes off, it shows that the battery is

low. Please charge in time.

Speed

control

button

Switch

button

Light 2

Light 1 Light 3

Switch

button

Indicator

Lamp

Speed

control

button

Cleaning and Maintenance

Placement and use of the machine

Note

1. When the machine is placed on the storage rack or when the storage rack is

placed alone, it must be placed on a horizontal plane to avoid falling and dam-

2. The machine should be handled with care whether it is in work or placed on the

storage rack, so as not to damage the machine.

1. Installation of storage rack

and place the installed storage rack assembly

2. Placement of the machine

again whether the placement position is horizontal, and ensure that the machine

has stopped working and closed. Gently place the machine on the buckle position

of the storage rack according to the position shown on the right, and leave after

the machine is placed stably.

Cleaning and Maintenance

Disassembling and cleaning of dust cup

Note

1. To keep the suction of the vacuum cleaner, please clean the dust regularly,

bottom cover of the dust cup to dump the dust.

Dust full

position Press

with one hand and take out the dust cup assembly with the other hand.

Push the button

Note

1. The parts in the dust cup are washable

2. Please make sure that every part has been dried after cleaning and be-

fore mounting it back!

1. Remove the dust cup

assembly from the machine

Filter

sponge

Filter

assembly

Cleaning and Maintenance

Disassembling and cleaning of cyclone cone

according to the disassembly procedure.

Close Close

Disassembl and cleaning of electric scrubbing brush

Note

2. When disassembling and maintaining, be sure to stop the operation of the

3. It is not recommended to wash the scrubbing brush with water. The entan-

gled hair can be cleaned with scissors or blades, and the dust stuck on the

roller brush can be cleaned with a brush.
