Mitsubishi MELSEC-A A1SJ71AS92 Bedienungsanleitung
AS-i Master Module
User’s Manual
(Hardware)
A1SJ71AS92
Thank you for buying the Mitsubishi general-purpose programmable
controller MELSEC-A Series
Prior to use, please read both this manual and detailed manual
thoroughly and familiarize yourself with the product.
MODEL A1SJ71AS92-U-H-JE
MODEL
CODE 13JQ99
IB(NA)-0800122-D(1112)MEE
2000 MITSUBISHI ELECTRIC CORPORATION
A
-1
WARNING
CAUTION
zSAFETY PRECAUTIONS z
(Read these precautions before using.)
Before using this product, please read this manual and the relevant manuals
carefully and pay full attention to safety to handle the product correctly.
These precautions apply only to Mitsubishi equipment. Refer to the CPU
module user's manual for a description of the programmable controller system
safety precautions.
In this manual, the safety precautions are classified into two levels:
"WARNING" and " CAUTION".
Indicates that incorrect handling may cause hazardous
conditions, resulting in death or severe injury.
Indicates that incorrect handling may cause hazardous
conditions, resulting in minor or moderate injury or
property damage.
Under some circumstances, failure to observe the precautions given under
"CAUTION" may lead to serious consequences.
Observe the precautions of both levels because they are important for personal
and system safety.
Make sure that the end users read this manual and then keep the manual in a
safe place for future reference.
A
-2
[DESIGN PRECAUTIONS]
WARNING
zIf a communication error occurs in the AS-i system, the input will turn OFF
from the slave having the communication error.
Output to the slave with communication error will be held or cleared
depending on the slave specifications.
The AS-i system communication error can be confirmed with the buffer
memory's List of Active Slaves (LAS) (15 to 16H, 75 to 76H) and with the
input signal Config OK (X4, X9).
Using the above information, configure an interlock circuit on the sequence
program so that the system activates safely.
There is a risk of accidents caused by incorrect outputs or incorrect
operations.
zDepending on the unit fault, the input/output could enter the ON state or
OFF state.
Provide a circuit for external monitoring for input/output signals that could
lead to major accidents.
CAUTION
zDo not bundle AS-i cable together with main circuit or power lines, or lay
them close to these lines.
As a guide, separate these lines by a distance of at least 100 mm,
otherwise malfunctions may occur due to noise.
A
-3
[INSTALLATION PRECAUTIONS]
CAUTION
zUse the programmable controller in an environment that conforms to the
general specifications in CPU module user's manual.
Using the programmable controller in the environments outside the ranges
stated in the general specifications will cause electric shock, fire,
malfunction, or damage to/deterioration of the product.
zDo not touch conductive parts or electronic components of the module with
your bare hands.
This could cause malfunction or failure of the module
zInsert the module fixing projection into the fixing hole in the base unit and
then tighten the module mounting screw within the specified torque. Then
tighten the module mounting screw to the specified torque. Incorrect
installation with no screws could result in malfunction, failure or fall of the
module. Tightening the screw excessively may cause fall, short circuit, or
malfunction of the module due to damage of the screw or the module.
zAlways shut off all phases of the programmable controller power supply
and AS-i power supply externally before mounting or removing the module.
Failure to shut off all phases could lead to product damage.
[WIRING PRECAUTIONS]
WARNING
zSwitch off all phases of the programmable controller power supply and AS-i
power supply outside the programmable controller before starting installing
or wiring work. There is a risk of electric shock or malfunction.
zAlways install the terminal covers enclosed with the product before turning
ON the power or operating the product after installation or wiring.
Failure to install the terminal cover could lead to electric shocks.
A
-4
[WIRING PRECAUTIONS]
CAUTION
zAlways confirm the products terminal layout before wiring to the module.
Incorrect wiring could lead to fires or faults.
zTighten terminal screws to the specified torque.
If a terminal screw is not tightened to the specified torque, the module may
fall out, short circuit, or malfunction. If a terminal screw is tightened
excessively, exceeding the specified torque, the module may fall out, short
circuit, or malfunction due to breakage of the screw or the module.
zMake sure that no foreign matter such as chips or wire offcuts gets inside
the module. It will cause fire, failure, or malfunction.
zAS-i cables connected to a module must always be run in a duct or held
securely using clamps.
If a cable is not run in a duct or not held securely using clamps, the cable
will sag, move, or be pulled by mistake, which will cause damage to the
module and the cable and also malfunctioning due to loose connection of
the cable.
zWhen removing the AS-i cable from a module, do not pull it out by the cable.
A cable loosen the screws that hold the cable onto the module then
remove the cable.
If the cable is pulled while it is connected to the module, the module and/or
the cable will be damaged and may malfunction due to loose connection of
the cable.
zUse applicable solderless terminals and tighten them within the specified
torque range. If any spade solderless terminal is used, it may be
disconnected when the terminal screw comes loose, resulting in failure.
A
-5
zCONDITIONS OF USE FOR THE PRODUCT z
(1) Mitsubishi programmable controller ("the PRODUCT") shall be used in
conditions;
i) where any problem, fault or failure occurring in the PRODUCT, if any,
shall not lead to any major or serious accident; and
ii) where the backup and fail-safe function are systematically or
automatically provided outside of the PRODUCT for the case of any
problem, fault or failure occurring in the PRODUCT.
(2) The PRODUCT has been designed and manufactured for the purpose of
being used in general industries.
MITSUBISHI SHALL HAVE NO RESPONSIBILITY OR LIABILITY
(INCLUDING, BUT NOT LIMITED TO ANY AND ALL RESPONSIBILITY
OR LIABILITY BASED ON CONTRACT, WARRANTY, TORT, PRODUCT
LIABILITY) FOR ANY INJURY OR DEATH TO PERSONS OR LOSS OR
DAMAGE TO PROPERTY CAUSED BY the PRODUCT THAT ARE
OPERATED OR USED IN APPLICATION NOT INTENDED OR
EXCLUDED BY INSTRUCTIONS, PRECAUTIONS, OR WARNING
CONTAINED IN MITSUBISHI'S USER, INSTRUCTION AND/OR SAFETY
MANUALS, TECHNICAL BULLETINS AND GUIDELINES FOR the
PRODUCT.
("Prohibited Application")
Prohibited Applications include, but not limited to, the use of the PRODUCT
in;
yNuclear Power Plants and any other power plants operated by Power
companies, and/or any other cases in which the public could be affected
if any problem or fault occurs in the PRODUCT.
yRailway companies or Public service purposes, and/or any other cases
in which establishment of a special quality assurance system is required
by the Purchaser or End User.
yAircraft or Aerospace, Medical applications, Train equipment, transport
equipment such as Elevator and Escalator, Incineration and Fuel
devices, Vehicles, Manned transportation, Equipment for Recreation and
Amusement, and Safety devices, handling of Nuclear or Hazardous
Materials or Chemicals, Mining and Drilling, and/or other applications
where there is a significant risk of injury to the public or property.
Notwithstanding the above, restrictions Mitsubishi may in its sole discretion,
authorize use of the PRODUCT in one or more of the Prohibited
Applications, provided that the usage of the PRODUCT is limited only for
the specific applications agreed to by Mitsubishi and provided further that
no special quality assurance or fail-safe, redundant or other safety features
which exceed the general specifications of the PRODUCTs are required.
For details, please contact the Mitsubishi representative in your region.
A
-6
Revisions
*The manual number is given on the bottom right of the top cover.
Print Date *Manual Number Revision
Apr.,2000 IB(NA)-0800122-A First edition
Jun., 2004 IB(NA)-0800122-B
Partial correction
SAFETY PRECAUTIONS, Section 3.1,
Chapter 5
Sep., 2010 IB(NA)-0800122-C
"PLC" was changed to "programmable
controller".
Partial correction
SAFETY PRECAUTIONS,
Correspondence to EMC Directives and
Low-Voltage Directives, Chapter 3, 4, 6
Addition
CONDITIONS OF USE FOR THE
PRODUCT
Dec., 2011 IB(NA)-0800122-D
Addition
SAFETY PRECAUTIONS (Chinese)
This manual confers no industrial property rights or any rights of any other kind, nor does
it confer any patent licenses. Mitsubishi electric Corporation cannot be held responsible
for any problems involving industrial property rights which may occur as a result of using
the contents noted in this manual.
2000 MITSUBISHI ELECTRIC CORPORATION
A
-7
CONTENTS
1. Overview ....................................................................................................... 1
2. Performance Specifications .......................................................................... 2
3. Handing ......................................................................................................... 3
3.1 Precautions for Handling.......................................................................... 3
4. Part Identification Nomenclature ................................................................... 4
5. Wiring ........................................................................................................... 5
5.1 Precautions for Wiring ............................................................................. 5
5.2 Wiring....................................................................................................... 5
6. Outline Dimension Drawings ......................................................................... 6
6.1 A1SJ71AS92............................................................................................ 6
A
-8
About the Manuals
The following product manuals are available. Please use this table as a
reference to request the appropriate manual as necessary.
Detailed Manual
Manual name Manual No.
(Model code)
AS-i Master Module User's Manual type A1SJ71AS92 SH-080085
(13JR15)
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES
(1) Method of ensuring compliance
To ensure that Mitsubishi programmable controllers maintain EMC and Low
Voltage Directives when incorporated into other machinery or equipment,
certain measures may be necessary. Please refer to one of the following
manuals.
yUser's manual for the CPU module used
yUser's manual (hardware) for the CPU module or base unit used
The CE mark on the side of the programmable controller indicates
compliance with EMC and Low Voltage Directives.
(2) Additional measures
To ensure that this product maintains EMC and Low Voltage Directives,
please refer to one of the manuals listed under (1).
1
1. Overview
This manual explains the specifications and names of each parts, etc., of the
A1SJ71AS92 model AS-i master module (abberviated as A1SJ71AS92) which
are used with AS-i system.
1) The use, cable used and installation position of the A1SJ71AS92 are
indicated on the following chart.
Use Application
The master of AS-i system Main base, Extension base I/O slot
2) Please verify the existence of the following parts after opening the
package.
a) In the case of A1SJ71LP21
Product name Quantity
AS-i Master Module A1SJ71AS92 1
3) Application CPU
A1SJCPU-S3, A1SCPU, A2SCPU, A1SJHCPU, A1SHCPU, A2SHCPU,
A2USCPU(S1), A2USHCPU-S1, Q2ASCPU(S1), Q2ASHCPU(S1),
Q02CPU-A, Q02HCPU-A and Q06HCPU-A
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Mitsubishi Steuereinheit Handbücher
Mitsubishi
Mitsubishi GOT 1000 Bedienungsanleitung
Mitsubishi
Mitsubishi MELSEC-A A1S68AD Bedienungsanleitung
Mitsubishi
Mitsubishi MELDAS MDS-C1 Bedienungsanleitung
Mitsubishi
Mitsubishi Q64AD Bedienungsanleitung
Mitsubishi
Mitsubishi AJ65BT-64DAV Bedienungsanleitung
Mitsubishi
Mitsubishi Wi-Fi Control Bedienungsanleitung
Mitsubishi
Mitsubishi MAC-588IF-E Bedienungsanleitung
Mitsubishi
Mitsubishi FR-A5ND Bedienungsanleitung
Mitsubishi
Mitsubishi A1S62TCRTBW-S2 Bedienungsanleitung
Mitsubishi
Mitsubishi FX3U-ENET-ADP Bedienungsanleitung
Mitsubishi
Mitsubishi MELSEC-Q QD77MS Bedienungsanleitung
Mitsubishi
Mitsubishi MELSEC L Series Bedienungsanleitung
Mitsubishi
Mitsubishi MELSEC System Q Bedienungsanleitung
Mitsubishi
Mitsubishi AJ71PB92D Bedienungsanleitung
Mitsubishi
Mitsubishi MELSEC-F FX2N Series Bedienungsanleitung
Mitsubishi
Mitsubishi C70 Bedienungsanleitung
Mitsubishi
Mitsubishi MELSEC Q Series Bedienungsanleitung
Mitsubishi
Mitsubishi QJ72LP25-25 Gebrauchsanweisung
Mitsubishi
Mitsubishi NZ2GF2B-60DA4 Bedienungsanleitung
Mitsubishi
Mitsubishi Q62HLC Bedienungsanleitung
Beliebte Steuereinheit Handbücher anderer Marken
Festo
Festo Compact Performance CP-FB6-E Stücklistenhandbuch
Elo TouchSystems
Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung
JS Automation
JS Automation MPC3034A Bedienungsanleitung
JAUDT
JAUDT SW GII 6406 Series Kurzanleitung
Spektrum
Spektrum Air Module System Bedienungsanleitung
BOC Edwards
BOC Edwards Q Series Bedienungsanleitung
