INSTALLATION & MAINTENANCE MANUAL

TRIBCCW / TRIBCWW

These instructions should be read carefully and retained after installation by the end user for

future reference and maintenance.

These instructions should be used to aid installation of the following products:

TRIBCCW / TRIBCWW

GENERAL INSTRUCTIONS

• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671)

and current Building Regulations. If in any doubt, consult a qualiﬁed electrician

• Please isolate mains prior to installation or maintenance

• Check the total load on the circuit (including when this luminaire is ﬁtted) does not exceed the rating of the

circuit cable, fuse, or circuit breaker

• Please note the IP (Ingress Protection) rating of this luminaire when deciding the location for installation

• This product is for indoor use only

• This product is Class I and must be earthed

• This product series is IP20 rated

SAFETY

INSTALLATION

Note - If this luminaire is being used in conjunction with an external PIR or sensor, please conﬁrm with the

manufacturer of the sensors that they are compatible with LED luminaires.

• Provide power to the required point of installation

• Remove the lamp housing from the triangular body by pressing from the rear

• Using the triangular body as a template, mark the location for, and drill the ﬁxing holes ensuring not to

infringe with any gas/water pipes or electrical cables

WARRANTY

This product has a warranty of 3 years from date of purchase. Failure to install this product in accordance with

the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will

invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place

of purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation

costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve

the right to alter product speciﬁcation without prior notice.

GENERAL

WARNING

This luminaire must be disconnected from the circuit if subjected to any high voltage or insulation resistance

testing. Irreparable damage will occur if this instruction is not followed.

The light source of this luminaire is not replaceable; when the light source reaches its end of life the whole

luminaire should be replaced.

Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the

product.

This product is non-dimmable.

This product should be recycled in the correct manner when it reaches the end of its life. Check local authorities

for where facilities exist.

• Fix the base to a suitable solid surface using the screw provided

• Connect the luminaire to the mains supply ensuring the correct polarity is observed: L - Live (brown), E -

Earth (green/yellow), N - Neutral (blue)

• Reattach the lamp housing to the triangular body

• Switch on and check for correct operation

AVAUG21_V3

ML Accessories Limited LU5 4LT

www.mlaccessories.co.uk
