Multitech MT128NTZLX Bedienerhandbuch

MULTIMOBILE PC CARDS

MT128NTZLX

MT128STZLX

Product Update

FIRMWARE VERSION 4.101

PN 82098300

April 20, 1999

Update–Firmware v. 4.101

Contents

Introduction .............................................................1

Safety Warnings .....................................................1

Windows 95/98 Installation—VCOMM & CAPI ......2

Windows 95/98 Installation—NDIS ........................4

Windows NT Installation.........................................5

Update–Firmware v. 4.101 1

Introduction

Use this Product Update in conjunction with Chapter 2,

Installation, in the Owners Manual. This Product

Update presents separately the VCOMM, CAPI, and

NDIS installation procedures for Windows 95/98 which

feature Plug and Play and Windows NT4.x which does

NOT have Plug and Play capability.

Installing the MultiMobile PC Card consists of

1. Installing the setup drivers/software

2. Attaching the PC Card to your laptop computer

3. Setting up the IDSN line connection

Safety Warnings

 Never install telephone wiring during a lightning

storm.

 Never install telephone jacks in wet locations unless

the jack is specifically designed for wet locations.

 This product is to be used with UL and cUL listed

computers.

 Never touch uninsulated telephone wires or terminals

unless the telephone line has been disconnected at the

network interface.

 Use caution when installing or modifying telephone

lines.

Introduction

2 Update–Firmware v. 4.101

 Avoid using a telephone (other than a cordless type)

during an electrical storm. There may be a remote risk

of electrical shock from lightning.

 Do not use the telephone to report a gas leak in the

vicinity of the leak.

Windows 95/98 Installation—

VCOMM & CAPI

Before you startIn Windows 95, you MUST install

the drivers before attaching the PC Card to your laptop.

If you install the PC Card first, the operating system

will not recognize the device.

1. Click Start èSettings èControl Panel è

Add/Remove Programs. Then click Install.

2. The Install Program From Floppy Disk or CD-

ROM dialog box appears. Insert the MT128ZLX

Disk 1 and click Next.

3. The Run Installation Program dialog box appears.

Click Finish.

4. The Setup dialog box appears and informs you that

the Configuration Utility Setup is preparing the

InstallShield Wizard (which guides you through the

setup process).

5. The Welcome dialog box appears. Click Next.

6. The Choose Destination Location dialog box

appears. Click Next to install to the destination

folder listed in the dialog box. (Click Browse to

install to a different folder.)

7. The Select Program Folder dialog box appears.

Select a folder or type a new folder name. Then

click Next.

VCOMM & CAPI Installation (Win95/98)

Update–Firmware v. 4.101 3

8. The Start Copying Files dialog box appears. Click

Back to review or change settings. To begin copying

files, click Next.

9. As the files copy, the Setup Needs The Next Disk

dialog box appears and, in sequence, requests Disk 2,

Disk 3, and Disk 4 (key disk). Insert each requested

disk and click OK. The driver installs with each disk.

10. The Configuration Utility window and the Com

Port Change dialog box appear. Make appropriate

changes in the Com Port Change dialog box, if

necessary, and then click OK.

11. The Microsoft ISDN Accelerator Pack 1.1 dialog

box appears and asks if you want to install the

accelerator pack. (This dialog box does not appear in

Windows 98, which includes the Accelerator Pack.)

If it is not already installed on your computer, click

Yes and follow dialog box instructions; otherwise,

click No and close the Configuration Utility

window.

12. The Setup Complete dialog box appears. Make

sure Yes, I want to restart my computer now is

selected, then remove the Configuration Utility disk

and click Finish. The computer reboots.

13. As the computer is rebooting, insert the

MultiMobile into the computers PC Card slot with

the 68-pin connector facing the PC card slot and the

label facing up.

14. Plug the 15-pin connector into the 15-pin socket of

the PC card. On the other end of the 15-pin cable,

leave the RJ-45 receptacle exposed until ISDN

connection is made. Hardware installation now is

VCOMM & CAPI Installation (Win95/98)

4 Update–Firmware v. 4.101

complete. The MultiMobile is powered directly

from the PC.

15. Connect the MultiMobile to the network by

plugging the (supplied) RJ-45 cable into the

MultiMobile cables RJ-45 receptacle. Plug the

other end of the RJ-45 cable into an available ISDN

outlet.

Windows 95/98 Installation—NDIS

1. Click Start èSettings èControl Panel; then

double-click the Network icon.

2. Click Add. Then click Add Adapter. Scroll down

the list in the Manufacturers text box and select

Multi-Tech. MultiMobile MT128ZLX then

appears in the Models text box. Click OK.

3. The ISDN Configuration dialog box appears. Click

Next.

4. The ISDN Configuration dialog box appears. Set

the switch type and click Next.

5. The ISDN Configuration dialog box appears.

Type the directory numbers and SPIDs numbers, if

necessary, and click Next. Then click Finish. The

NDIS interface now is installed successfully.

Note: The switch type and phone number

must be the same as Multi-Tech’s configu-

ration utility setting. If they are different,

the ISDN configuration setting overwrites

NDIS Installation (Win95/98)

Update–Firmware v. 4.101 5

Manual PC Card Installation (NT)

Multi-Tech’s configuration setting.

Note: If you enter Multi-Tech’s Configura-

tion utility to change the switch type and

phone number, the new settings overwrite

the ISDN configuration utility.

6. To complete setup, reboot your computer.

Windows NT Installation

Since Windows NT 4.x does not feature Plug and Play,

users must install the PC Card manually.

Note: Windows NT4.x only works with CAPI. The

ISDN AT command emulation also is available

through CAPI. Other API modes, such as NDIS

and VCOMM, will be supported by a later release.

1. Run Windows NT.

2. Plug the PC Card into your laptops PCMCIA slot.

3. Insert the Windows NT driver disk and click Start

èSettings èControl Panel; then double-click

PC Card (PCMCIA). Note the resources that NT

allocates for I/O range, IRQ, Memory, etc. You will

need this information when you check the Adapter

Settings in step 7 below. Then click Network.

4. The Network dialog box appears. Open the

Adapters tab and click Add.

5. In the next dialog box, click Have Disk. Enter the

driver path and click OK.

6. The Select OEM Option dialog box appears with

the device name (e.g. 56K Modem + ISDN Adapter

for CAPI) in the text box. Click OK.

7. The Setup dialog box appears. Make sure the

settings for the Adapter Setting and the Line

6 Update–Firmware v. 4.101

Setting below match the settings you noted in step

3 above .

Adapter Setting

I/O Base: Not used by any other devices

Interrupt: IRQ does not conflict with any

other device

Mem: Setting is for PCMCIA attribute

memory use. (Select one of the settings.)

Pcmcia: Select CARDBUS if the PC Card is

seated in the CardBus slot. Select 365

COMP for the non-CardBus PCMCIA slot.

If necessary, check the laptop user manual

for information on your PCMCIA slots.

Line Setting

Switch type: Select the ISDN switch type or

D-channel protocol

Modem I/O: Specify the I/O for analog

applications

Modem choice: Select the analog applications

Analog encoder: Select the encoding scheme

for your analog applications, modem over

ISDN, modem over PSTN, or ISDN Phone

(voice). This setting should be consistent

with the ISDN Voice Encoding in ISDN

folder in RVS COMMCenter (refer to RVS-

COM Lite for details)

Phone number: Enter the ISDN phone

number(s)

SPID number: For North American use

only

8. When finished, click Close.

Manual PC Card Installation (NT)

Update–Firmware v. 4.101 7

Manual PC Card Installation (NT)

9. Reboot your computer.

10. To make sure the PC Card driver is installed

correctly:

a. Click Start èPrograms è

Administrative Tools (Common) è

Windows NT Diagnostics.

b. Open the Services tab and click the

Devices button. Scroll down the Device

list to locate the PC Card. If the status is

Running, the PC Card is installed

correctly. If the status displays Stopped,

double-check the settings in step 7 above.

11. Install the CAPI-based application program, RVS-

COM Lite.

12. Your MultiModem PC Card is now installed. To

trace ISDN connection status when making ISDN

connections, open status.exe at the system32

subdirectory (e.g., c:\winnt\system32\status.exe).

To change the I/O, IRQ, Mem, Pcmcia, Switch

Type, ISDN phone number (required in RVS-

COM), click My Computer èControl Panel è

Network, then open the Adapters tab. Scroll down

the Device list to select the device name. Click

Properties to change parameters. After making any

setting changes, reboot the NT system.
