Model MT5634MU

Portable USB Modem

Quick Start Guide

MT5634MU Quick Start Guide

Quick Start Guide

82097005L Revision F

MultiMobile

USB

(Model MT5634MU)

This publication may not be reproduced, in whole or in part, without prior expressed

Patents & Trademarks

This Product is covered by one or more of the following U.S. Patent Numbers:

5.301.274; 5.309.562

;

5.355.365; 5.355.653; 5.452.289; 5.453.986

. Other

Patents Pending. MultiMobileUSB is a trademark and the Multi-Tech logo is a

registered trademark of Multi-Tech Systems, Inc. Windows® and Windows 2000®

are registered trademarks of Microsoft.

Record of Revisions

Rev. D 03/18/03 Changed information about the kit contents. Added

installation of Windows XP drivers.

Rev. E 04/02/04 Changed the format and removed the Contents list from the

cover page.

Rev. F 05/03/07 Revised tech support listing

World Headquarters

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, Minnesota 55112 U.S.A.

(763) 785-3500 or (800) 328-9717

U. S. FAX 763-785-9874

Technical Support (800) 972-2439

Internet Address: http://www.multitech.com

Technical Support

Country By Email By Phone

France: support@multitech.fr +(33) 1-64 61 09 81

Europe, Asia

and Africa: support@multitech.co.uk +(44) 118 959 7774

U.S., Canada

and all others: support@multitech.com (800) 972-2439

or (763) 717-5863

Introduction

Safety Warnings

1. Never install telephone wiring during a lightning storm.

2. Never install a telephone jack in wet locations unless the jack is

specifically designed for wet locations.

3. This product is to be used with UL and cUL listed PCs.

4. Never touch uninsulated telephone wires or terminals unless the

telephone line has been disconnected at the network interface.

5. Use caution when installing or modifying telephone lines.

6. Avoid using a telephone (other than a cordless type) during an

electrical storm. There may be a remote risk of electrical shock

from lightning.

7. Do not use a telephone in the vicinity of a gas leak.

8. To reduce the risk of fire, use only 26 AWG telecommunication

line cord.

Introduction

This Quick Start Guide will help you unpack, install, test, and use your

Multi-Tech MT5634MU modem.

Product Description

The MT5634MU is a V.90 Plug-and-Play data/FAX modem that transmits

56kbps downstream and 33.6 kbps upstream. It can be automatically

configured for operation in nearly any country’s phone system with Multi-

Tech’s Global Wizard.

Figure 1. MT5634MU

A detailed MT5634MU User Guide is provided with your unit and at http:/

/www.multitech.com. From the MTS homepage, click Support |Manuals

|MultiMobileUSB and choose MT5634MU to download the .pdf file.

MT5634MU Quick Start Guide

Unpacking your MT5634MU

MADEINU.S.A

Quick Start Guide

Four USB V.90 Modems

rio

Software

Figure 2. Unpacking

Installation Steps

Step 1: Connecting the Modem to Your System

Connect the MT5634MU to your computer’s USB port and connect the

telephone line to your MT5634MU and a telephone wall jack.

Figure 3. Modem connections

USB Connection

Plug the USB cable connector on the modem into a USB port

connector on your computer.

Line Connection

Plug one end of the phone cable into the modem’s LINE jack, and

the other end into a phone line wall jack.

Note: The Federal Communications Commission (FCC), and

Industry Canada impose certain restrictions on equipment

connected to public telephone systems. See the User Guide for

more information.

Installation

Step 2: Installing the Modem

The MT5634MU is compatible with Windows XP, 2000, ME, 98, and

some versions of Windows 95.

Installation in Windows XP

1. Power up your Windows XP system.

2. If you have not already done so, make all the necessary

connections, including connecting the modem to an available

USB port.

3. Insert the MultiModem USB CD into your CD drive.

4. Windows will detect that the new modem is present and launch

the Update Device Driver Wizard dialog box.

5. Choose Install from a list or specific location (Advanced),and

click Next.

Select Don’t Search. I will choose the driver to install,and click

Next.

7. Click the Have disk button. Browse to x:\Drivers\WinXP. Select

the file there and click OK. (

denotes your CD drive letter).

8. When the pop-up window comes up explaining that the driver is

not digitally signed, click Continue anyway to finish the

installation.

NOTE:

This Microsoft operating system searches for a digital signature

when you install any new hardware. If a "Digital Signature Not Found"

screen appears, simply click the YES button to continue installation.

Although Multi-Tech submits all eligible products to Microsoft for

certification, the turn-around time is subject to many factors. Not having

a digital signature does not affect product performance in any way.

Installation in Windows 2000

1. Power up your Windows 2000 system.

2. If you have not already done so, connect the MT5634MU to

your computer’s USB port and connect the telephone line to

your MT5634MU and a telephone wall jack.

3. Windows will detect that the new modem is present, indicate

that it's in the process of installing, and then launch the Found

New Hardware Wizard. The Welcome screen appears first.

Click Next.

MT5634MU Quick Start Guide

4. The Install Hardware Device Drivers screen appears indicating

that the wizard will install the hardware device drivers. Verify that

the "Search for a suitable driver for my device (recommended)" is

selected, and then click Next >.

5. The Locate Driver Files screen appears asking where you want

Windows to search for driver files.

Verify that the “Specify a location” option is the

only

one selected,

place the MT5634MU Installation CD into your CD drive, and click

Next.

6. The next screen tells you to “Insert the manufacturer’s installation

disk into the drive selected and then click OK.” Click the

Browse button (when prompted to insert a disk into drive A:\,

click Cancel). Navigate to your computer’s CD drive.

Select the folder DRIVERS\WIN 2000.

Select the file MDMMTUSB.INF and click Open.

7. Then the Driver Files Search Results screen appears indicating

that Windows has found the proper driver from the MT5634MU

CD. Click Next to install the selected driver.

8. The Digital Signature Not Found dialog box is displayed. Click

Yes to continue with the installation.

NOTE:

This Microsoft operating system searches for a digital

signature when you install any new hardware. If a "Digital

Signature Not Found" screen appears, simply click the YES button

to continue installation. Although Multi-Tech submits all eligible

products to Microsoft for certification, the turn-around time is

subject to many factors. Not having a digital signature does not

affect product performance in any way.

9. A Copying Files screen appears briefly. After the files have

been copied to your PC, a Found New Hardware Wizard

screen appears indicating that Windows has finished installing

the driver. Click Finish to complete the installation and exit the

wizard.

After installation is complete, you should test the operation of your

new MT5634MU by registering it. Key in the URL given below and

follow the on-line instructions at: http://www.multitech.com/register

Installation

Installation in Windows ME

The MT5634MU driver files for Windows ME are installed in two

groups, as described below. The installation wizard begins by

installing certain driver files. At that point, Windows ME detects the

modem as a new device. Then the installation wizard runs again to

install the remaining driver files.

1. Power up your Windows ME computer.

2. Connect the MT5634MU to your computer’s USB port. Then

connect one end of the provided telephone line cord to your

MT5634MU and the other end to a telephone wall jack.

3. Windows ME will detect that the new modem is present and

launch the Add New Hardware Wizard.

Place the MT5634MU CD into the CD drive of your PC. The

first Add New Hardware Wizard screen displays the message

“What would you like to do?” Choose “Specify the location of the

driver (Advanced)” and click Next.

4. At the Add New Hardware Wizard screen “Windows will search

for new drivers ...”, uncheck the “Removable Media” button (if

necessary) and check “Specify a location.”

5. Click the Browse button and navigate to the Windows ME

subfolder of the Drivers folder on the MT5634MU CD. Then

click OK. Click Cancel if it prompts you for a floppy disk.

6. The Add New Hardware Wizard the “Windows driver file

search ...” screen appears. Click Next.

7. Transient progress screens will appear while files are being

copied. After the files have been copied to your PC, an Add

New Hardware Wizard screen will appear indicating that

Windows has finished installing this the first of two drivers.

Click Finish. The wizard will close.

8. Windows ME will now detect an “Unknown Device” and begin

another Add New Hardware Wizard,again asking “What would

you like to do?” Choose “Specify the location of the driver

(Advanced)” and click Next.

9. At the next screen (Add New Hardware Wizard “Windows will

search for new drivers...” screen), uncheck the “Removable

Media” button and check “Specify a location.” Click Next.

10. Transient screens will appear while files are being copied. The

Add New Hardware Wizard “Windows driver file search...”

screen will appear. Click Next.

MT5634MU Quick Start Guide

11. After files have been copied, a completion screen will appear.

Click Finish to complete the installation of this the second

driver. The wizard will close.

12. Remove the MT5634MU CD from the computer’s CD drive.

13. Test the operation of your modem by registering it online at

http://www.multitech.com/register.

Installation in Windows 98

1. Power up your Windows 98 system.

2. If you have not already done so, connect the MT5634MU to

your computer’s USB port and connect the telephone line to

your MT5634MU and a telephone wall jack.

3. Windows will detect that the new modem is present and launch

the Add New Hardware Wizard. The first screen indicates that

the wizard will search for a USB driver.

4. Place the MT5634MU CD into your CD drive and click Next to

proceed with the installation.

5. The Add New Hardware Wizard dialog box displays with the

message “What do you want Windows to do?” Verify that the

“Search for the best driver for your device (Recommended)”

option is selected and click Next.

6. The Add New Hardware Wizard dialog box appears with the

message “Windows will search for a new driver.. .” Verify that

the “CD-ROM drives” option is selected and click Next.

7. The Add New Hardware Wizard dialog box appears indicating

that Windows has found an updated driver for this device. Verify

that the “Updated driver (Recommended)” option is selected

and click Next.

8. The Add New Hardware Wizard dialog box appears indicating

Windows will select the proper driver from the CD and verify the

information. Click Next to install the selected driver.

9. After the files have been copied to your PC, an Add New

Hardware Wizard screen appears indicating that Windows has

finished installing the driver. Click Finish to complete the

installation and exit the wizard. The TR LED on your modem will

light when the installation is complete. Remove the CD.

After installation, you should test the operation of the MT5634MU by

registering it. Key in the URL given below and follow the on-line

instructions: http://www.multitech.com/register

Installation

Installation in Windows 95

Only certain versions of Windows 95 offer support for USB

peripherals. If you are unsure if your Win95 system supports USB, a

free USB evaluation utility is available from the Shopping Bag page

at http://www.usb.org. Just download the utility (287K) and run the

.exe application. It will determine if you have USB support.

Note: Dialog boxes for the Windows 95 installation are not shown

because they may vary depending on the version of Windows 95

being used.

If you would like to install your MT5634MU in Windows 95, perform

the following steps.

1. Insert the MT5634MU Installation CD into your CD drive.

2. If you have not already done so, connect the MT5634MU to

your computer’s USB port and connect the telephone line to

your MT5634MU and a telephone wall jack.

3. Windows will detect that the new modem is present and launch

the Update Device Driver Wizard dialog box. Click Next to

proceed with the installation.

4. The Update Device Driver Wizard dialog box appears

indicating that Windows has searched for the driver on X:\ (“X”

represents CD drive) and, when identified, displays the driver

name for verification. Verify that the correct name is displayed

and click Finish to install the driver.

5. Windows prompts you to insert a CD. Since you have already

inserted the CD, simply click OK to continue.

6. The Copy Files ... dialog box is displayed. In the Copy files

from field, choose X:\ from the drop-down list and click OK. (X

denotes the drive letter of your CD drive.)

7. When driver installation is finished, a completion message will

appear, the TR LED on your modem will light, and the wizard

will exit. At this time your installation is complete. Remove the

CD from the computer.

After installation is complete, you should test the operation of your

new MT5634MU by registering it. Key in the URL given below and

follow the on-line instructions: http://www.multitech.com/register

MT5634MU Quick Start Guide

Step 3: Installing Data Communications Software

Data communications software is designed to send and receive messages

about the operation of your modem. Multi-Tech includes PhoneTools

communications software with your modem. However, the modem will

work with most data communications software packages. To install

PhoneTools, insert the Installation CD into the CD-ROM drive and click on

the PhoneTools icon. You will be asked to choose your language. The

software will be loaded automatically onto your PC.

Step 4: Country Configuration with Global Wizard

Different countries have different requirements for how modems must

function. Therefore, before you use the modem, you must configure it to

match the defaults of the country in which you are using it. You can

configure the MT5634MU either manually using AT commands (see User

Guide), or with the Global Wizard, as described below.

The Global Wizard configuration utility is recommended for computers

running Windows 95/98/ME/2000/XP. The Global Wizard can configure

your modem for a specific country with just a few mouse clicks.

1. Insert the MT5634MU CD into the CD-ROM drive. The Autorun

dialog box appears.

2. Click Initial Setup and Country Selection. The Global Wizard

dialog box appears. Click Next.

3. View the Global Wizard as it searches for your modem and

identifies it. Click Next.

4. Select the country in which the modem will be used, and then

click Next.

5. Review your choice of country. If it is correct, click Next to

configure the modem.

6. When Global Wizard announces that the parameters have been

set, click Finish to exit.

Andere Handbücher für MT5634MU

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Multitech Modem Handbücher

Multitech

Multitech MultiMobile MT5634ZLX/FE Bedienungsanleitung

Multitech

Multitech MTC-LAT1 Bedienungsanleitung

Multitech

Multitech MTCBA-E-U Bedienungsanleitung

Multitech

Multitech Multimodem MTCBA-G-F2 Bedienungsanleitung

Multitech

Multitech MultiModem MT9234ZPX-UPCI Bedienungsanleitung

Multitech

Multitech MT9234ZBAUSBCDC Bedienungsanleitung

Multitech

Multitech Dragonfly Nano MTQN-MNG1-B02 Anwendungshandbuch

Multitech

Multitech MultiModem MTCBA-G-F4 Bedienungsanleitung

Multitech

Multitech MultiModem II MT5600BA-V.90 Bedienungsanleitung

Multitech

Multitech Modem Module MT3334SMI Bedienungsanleitung

Multitech

Multitech MultiModem iCell Bedienungsanleitung

Multitech

Multitech MTD-H5 Bedienungsanleitung

Multitech

Multitech MultiMobile MT5634ZLX Bedienungsanleitung

Multitech

Multitech MultiConnect MicroCell MTCM-LAT3 Bedienungsanleitung

Multitech

Multitech MultiModem MTCBA?H3?U1 Bedienungsanleitung

Multitech

Multitech MultiModem MT5600DSDV2 Bedienungsanleitung

Multitech

Multitech MT1932ZDX Bedienungsanleitung

Multitech

Multitech MultiModem GPRS with Ethernet Interface Bedienungsanleitung

Multitech

Multitech MultMobile MT9234MU Bedienungsanleitung

Multitech

Multitech MultiConnect microCell MTCM2-L4G1 Bedienungsanleitung

Multitech

Multitech SocketModem Anwendungshandbuch

Multitech

Multitech MT5634ZPX-PCl Bedienungsanleitung

Multitech

Multitech MultiModem MT5634ZBA-V.92 Bedienungsanleitung

Multitech

Multitech MultiConnect microCell Bedienungsanleitung

Beliebte Modem Handbücher anderer Marken

Davicom

Davicom DM562AP Bedienungsanleitung

EpiValley

EpiValley TATA indicom SXC-1080 Bedienungsanleitung

Zte

Zte WiMAX Bedienungsanleitung

Intelimax

Intelimax MA-2060 Bedienungsanleitung

SMC Networks

SMC Networks D3CM1604V Gebrauchs- und Pflegehandbuch

Telstra

Telstra Wi-Fi 4G Advanced Pro X Bedienungsanleitung

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Bedienungsanleitung

Samsung

Samsung AceLink SAM-335A Bedienungsanleitung

Enfora

Enfora Enabler-G Kurzanleitung zur Einrichtung

iRZ

iRZ ATM2-232 Bedienungsanleitung

Zhone

Zhone 6310 Bedienungsanleitung

Paradyne

Paradyne Hotwire 7976 Bedienungsanleitung

US Robotics

US Robotics 3453C Bedienungsanleitung

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Bedienungsanleitung

Zte

Zte MF823 Bedienungsanleitung

Four-Faith

Four-Faith F1403 Bedienungsanleitung

Sierra Wireless

Sierra Wireless AIRLINK MP595W Bedienungsanleitung

Gemtek

Gemtek WiMAX WIXFBR-103 Bedienungsanleitung
