Norac UC4+ TA 1200 Bedienungsanleitung
Top Air (TA 1200/1600 80/90-ft Boom 2006+)
Installation Manual
Spray eight Controller
Improving the competitiveness of Industry and
Agriculture through Precision Measurement
Printed in Canada
Copyright 2005-08 by NORAC Systems International Inc
Reorder P/N: UC4+BC+TA1-INST Rev E (Top Air)
NOTICE
NORAC Systems International Inc reserves the right to improve products and their specifications without notice and without the requirement to update
products sold previously Every effort has been made to ensure the accuracy of the information contained in this manual The technical information in
this manual was reviewed at the time of approval for publication
TABLE OF CONTENTS
1
INTRODUCTION..................................................................................................................................................1
2
GENERAL SYSTEM DESCRIPTION ..................................................................................................................2
3
PARTS LISTS ......................................................................................................................................................3
4
INSTALLATION PROCEDURE ...........................................................................................................................8
4.1
EXISTING SYSTEM CHECK ...............................................................................................................................8
4.2
BOOM SPEED TEST........................................................................................................................................8
4.3
WING SENSOR INSTALLATION.......................................................................................................................10
4.4
MAIN LIFT SENSOR INSTALLATION................................................................................................................13
4.5
ROLL SENSOR INSTALLATION.......................................................................................................................14
4.5.1
Boom Roll Sensor Mounting 15
4.5.2
Chassis Roll Sensor Mounting 15
4.5.3
Inverted Roll Sensor Mounting 16
4.5.4
Temperature pro e 16
4.
HYDRAULIC INSTALLATION ...........................................................................................................................17
4.6.1
Valve Assem ly 17
4.6.2
Valve Mounting 18
4.6.3
Hydraulic Plum ing 20
4.7
ELECTRICAL INSTALLATION ..........................................................................................................................21
4.8
COMPLETING THE INSTALLATION ..................................................................................................................25
5
ELECTRICAL REFERENCE – CABLE DRAWINGS........................................................................................2
5.1
ITEM C02: 44 8 – SENSOR BRANCH CABLE...............................................................................................2
5.2
ITEM C02B: 44 4 – CABLE UC4 CAN NODE DUAL....................................................................................2
5.3
ITEM C03: 44 5 D – CABLE VALVE VARIABLE RATE DT..............................................................................27
5.4
ITEM C10: 44 50-35 – POWER CABLE GENERIC PULL-TYPE ........................................................................28
5.5
ITEM C11: 44 51-03 – EXTENSION CABLE VALVE GENERIC .........................................................................29
5.
ITEM C12: 44 58-38 – ALL INTERFACE CABLE ............................................................................................30
5.7
ITEM C1 : 44 58-39 – BYPASS INTERFACE CABLE ......................................................................................31
1
1
INTRODUCTION
Congratulations on your purchase of the NORAC UC4+ Spray Height Controller This system is
manufactured with top quality components and is engineered using the latest technology to provide
operating features and reliability unmatched for years to come
When properly used the system can provide protection from sprayer boom damage, improve sprayer
efficiency, and ensure chemicals are applied correctly
Please take the time to read this manual completely before attempting to install the system A thorough
understanding of this manual will ensure that you receive the maximum benefit from the system
YOUR INPUT CAN HELP MAKE US BETTER! If you find issues or ha e suggestions regarding
the parts list or the installation procedure, please don’t hesitate to contact us ia the information
gi en below:
Phone: 1-800-667-3921 Canada (Toll Free)
1-866-306-6722 United States (Toll Free)
(+33) 06 03 87 80 78 Europe
1-306-664-6711 all other regions
E-mail: ser [email protected]
Website: www.norac.ca
2
2
GENERAL SYSTEM DESCRIPTION
Figure 1 depicts the general system layout of the UC4+ Spray Height Control system
Figure 1 – System Components and General Location
NOTICE:
Every effort has been made to ensure the
accuracy of the information contained in this
manual All parts supplied are selected specially
to fit the sprayer to facilitate a complete
installation However, NORAC cannot
guarantee all parts fit as intended due to the
variations of the sprayer by the manufacturer
Please read this manual in its entirety before
attempting installation.
ATTENTION:
When installing the UC4+ Spray Height Control
system please be aware that at a point in the
installation your sprayer booms will be
inoperative until the installation is complete
Any installation procedure requiring boom
mo ement will need to be done first. Once the
hydraulics have been disconnected you must
complete the electrical installation before the
booms become operative
3
3
PARTS LISTS
The parts that come with your UC4+ Sprayer Boom System are listed in Table 1. The item number on
the left side of this table references each part
Please ensure that all parts in your kit are present before proceeding with your installation.
Table 1 – Top Air Spray Height Control system Parts
Item Part Number Name Quantity
B05 44706-01 KIT CABLE TIE BLACK 10 PCS 21 IN 150 PCS 7 5 IN 1
B10 44700-06 BRACKET VALVE MOUNTING STD 1
B11 44743 MOUNTING BRACKET MAIN LIFT SENSOR UC4 PLUS 1
B13 44728 MOUNTING BRACKET COMPLETE UC4 BREAKAWAY EXTENDED 2
C02 44668 CABLE UC3 SENSOR BRANCH 1 AMP RECEPT 3 AMP PLUG BC 1
C02B 44664 CABLE UC4 CAN NODE DUAL 1
C03 44656D CABLE VALVE VARIABLE RATE DT 1
C10 44650-35 CABLE POWER GENERIC PULL-TYPE 1
C11 44651-03 CABLE EXTENSION VALVE GENERIC 1
C12 44658-38 CABLE INTERFACE UC4 BC C12 DIN ALL 1
C16 44658-39 CABLE INTERFACE UC4 BC C16 DIN 1
E01 4461BC+ UC4 PLUS BOOM CONTROL PANEL 1
E02 44631 UC4 ULTRASOUND SENSOR 3
E03 44641 UC4 PLUS ROLL SENSOR W TEMPERATURE PROBE 1
E04 44642 UC4 PLUS ROLL SENSOR 1
H03 44863-16 HOSE ASSEMBLY 122R2-06 32 IN L 6FJX90 6FJX90 1
H04 44863-06 HOSE ASSEMBLY 122R2-06 40 IN L 6FJX 6FJX90 1
H20 44865-31 HYDRAULICS FITTING KIT - TA1 1
M01 446BC+MAN7 OPERATOR MANUAL UC4+ SPRAY HEIGHT CONTROL 1
M10 UC4+BC+TA1-INST MANUAL INSTALLATION UC4+ TOP AIR 1
V01 44963D VALVE BLOCK ASSEMBLY 2 STATION CC/LS PROP DT 4 BOLT 1
4
Substitution parts will in no way affect the operation of the system pro ided that they are installed
as directed.
Item V01 – 2 Station Val e Block (44963D) may be substituted with:
Item Part Number Name Quantity
V01 44933D VALVE BLOCK ASSEM UC4-BC 2-STATION CC/LS VARIABLE RATE 1
The 44933D is a direct replacement for the 44963D Both valve blocks function the same The blocks
are identifiable by the filter cap shape and by the part number stamped on the side
The A and B ports are opposite on each al e block so erify that the hoses are being connected to
the correct port. The raise lines always go to the “B” port and the lower lines go to the “A” port.
44933D Val e Block Shown Alongside 44963D Val e Block
Filter Cap Part Number
(44933D)
Filter Cap Part Number
(44963D)
5
Table 2 – 44865-31 - Hydraulics Fittings Kit
Item Part Number Name Quantity
F02 103839 TEE ADAPTER - 6FJXR 6MJT 2
F03 104634 CAP - 6FJCN 2
F04 105626 UNION 8FJX 2
F05 103312 MALE ADAPTER - 6MB 6MJ 4
F06 104369 PLUG - 6MBP 2
F07 44928 ORIFICE INSERT 047 IN ONE WAY 2
F08 42997-01 MALE ADAPTER - 8MB 8MJ - 1/32 ORIFICE 2
6 M B - 6 M OR X 90
SIZE IN
1/16TH'S
GENDER: MA E
OR FEMA E
90
°
ANG E
SWIVE
TYPE
GENDER
SIZE
TYPE:
B - ORB
J - JIC
OR - F AT
FACE
P - PIPE
Fitting Name
Example:
The use of dielectric grease is not recommended on any NORAC electrical connections.
To ensure all stainless steel hardware does not gall or seize apply a light coating of the supplied
Permatex Anti-seize grease to all threaded parts upon installation. Permatex Anti-seize lubricant is
preferred, but other similar anti-seize products may be used.
6
The parts that come with your UC4+ Spray Height Control system are shown below in their general
installation configuration.
Figure 2 – UC4+ Spray Height Control Components
7
Figure 3 – Hydraulic Components
