OJ Electronics ETR2 Bedienungsanleitung

ype E R2

Ice and snow melting

57654C 02/11 (MBC)

Introduction

Type ETR2 is an electronic thermostat for fully automatic, economical control of ice and snow melting systems on

small outdoor areas and in gutters. ce forms due to a combination of low temperature and moisture. ETR2

monitors both temperature and moisture, and the heating system is only activated if a possibility of snow or ice is

indicated. ETR2 is suitable for controlling electric heating cables.

Glossary

TEMP SET For setting the temperature at which heating should be activated.

T ME SET For setting the afterheat duration. The length of time the system should continue to provide heat after

the moisture/temperature signals have been eliminated by a heating cycle.

CONSTANT Allows heat to be provided constantly, independently of temperature and moisture.

English

Startup

• Connect a power supply and the LED will light green.

• Adjust TEMP SET to the temperature at which ice and snow detection should be activated. Recommended

initial setting: +3°C.

• Adjust T ME SET to the required afterheat duration (0-5 hours). Recommended initial setting: 2 hours.

• The thermostat is now set up and will begin melting ice and snow when necessary.

Mode of operation/operating instructions

ETR2 activates the heating system if the outdoor temperature falls below the temperature setpoint

(TEMP SET) and the moisture sensor simultaneously detects moisture.

When the outdoor temperature is below the temperature setpoint, the TEMP LED will light red.

When the moisture sensor detects moisture, the MO ST LED will light red.

When both preconditions (low temperature and moisture) are met, the thermostat will activate the ice and snow

melting system, and the RELAY LED will light red. After the moisture/temperature signals have been eliminated by

a heating cycle, heat will continue to be provided for the specified length of time, to ensure that all ice and snow is

completely melted.

f some ice and snow remains after the heating system has been deactivated, the afterheat duration should be

increased slightly by adjusting T ME SET. The longer the afterheat duration, the more effective and less economical

the system will be.

f ice and snow is present on the heated area, but the TEMP LED is not lit, the temperature setpoint (TEMP SET)

should be increased to the point where the TEMP LED lights red. The higher the temperature setpoint, the more

effective and less economical the system will be.

Constant heat On

n order to force ice and snow melting ON in any condition, it is possible to turn on the output relay, by turnng the

T ME SET knob to Constant. The ON led flashes as long as Constant is activated. Be aware to adjust T ME SET

back at the desired afterrun time, after all snow and ice has melted, to save energy.

Note that the CONSTANT HEAT ON setting will result in high energy consumption/costs.

Light indicator overview

ON The power is on / Constant heat on (flashing)

TEMP Sensor temperature is below TEMP SET

MO ST Moisture/snow has been detected by sensor

RELAY Output RELAY ON / HEAT ON

Fault codes

f faults occur, the thermostat disables all outputs and ceases to operate until the fault has been remedied.

TEMP LED flashes red: Temperature sensor (ETOG / ETF) has been disconnected or short-circuited.

MO ST LED flashes red: Moisture sensor in sensor (ETOG / ETOR) has been short-circuited.

RELAY LED flashes red: Heating element in sensor (ETOG / ETOR) has been short-circuited.

3344

PINK

3355

OJ Electronics A/S

Stenager 13B · DK-6400 Sønderborg

Tel.: +45 73 12 13 14

Fax: +45 73 12 13 13

[email protected] · www.ojelectronics.com
