Opticon OPL 2724 ZAPPER Bedienungsanleitung

Wireless Barcode Scanner

OPL 2724

The OPL 2724 scanner uses wireless Bluetooth 1.2

technology. Scanned data is transferred to the

designated device via wireless communication. Specifications Manual

Opticon

OPL 2724

Specifications Manual

All information subject to change without notice.

Document History

Model Number: OPL 2724 Specification Number: SS07003

Edition: 1A Original Spec Number: SS05066

Date: 2006-09-15

This manual may not, in whole or in part, be copied, photocopied, reproduced, translated or converted to any electronic or

machine readable form without prior written consent of Opticon.

Limited Warranty and Disclaimers

PLEASE READ THIS MANUAL CAREFULLY BEFORE INSTALLING OR USING THE

PRODUCT.

Serial Number

A serial number appears on all Opticon products. This official registration number is directly related to the device

purchased. Do not remove the serial number from your Opticon device. Removing the serial number voids the warranty.

Warranty

Unless otherwise agreed in a written contract, all Opticon products are warranted against defects in materials and

workmanship for two years after purchase. Opticon will repair or, at its option, replace products that are defective in

materials or workmanship with proper use during the warranty period. Opticon is not liable for damages caused by

modifications made by a customer. In such cases, standard repair charges will apply. If a product is returned under

warranty and no defect is found, standard repair charges will apply. Opticon assumes no liability for any direct, indirect,

consequential or incidental damages arising out of use or inability to use both the hardware and software, even if Opticon

has been informed about the possibility of such damages.

Packaging

The packing materials are recyclable. We recommend that you save all packing material to use should you need to

transport your scanner or send it for service. Damage caused by improper packaging during shipment is not covered by

the warranty.

Trademarks

Trademarks used are the property of their respective owners.

Opticon Inc. and Opticon Sensors Europe B.V. are wholly owned subsidiaries of OPTOELECTRONICS Co., Ltd., 12-17,

Tsukagoshi 4-chome, Warabi-shi, Saitama, Japan 335-0002. TEL +81-(0) 48-446-1183; FAX +81-(0) 48-446-1184

SUPPORT

USA Europe

Phone: 800-636-0090

Email: support@opticonusa.com Email: [email protected]

Web: www.opticonusa.com Web: www.opticon.com

Opticon

OPL 2724

Specifications Manual

Contents

1. Abstract....................................................................................................................................... 6

2. Overview...................................................................................................................................... 6

3. Physical Features....................................................................................................................... 7

3.1. Dimensions ......................................................................................................................... 7

3.2. Weight ................................................................................................................................. 7

3.3. Color.................................................................................................................................... 7

4. Environmental Specifications ................................................................................................... 7

4.1. Operating Temperature and Humidity................................................................................. 7

4.2. Storage Temperature and Humidity .................................................................................... 7

4.3. Ambient Light Immunity....................................................................................................... 8

5. Controls....................................................................................................................................... 9

6. Electrical Specifications ............................................................................................................ 9

6.1. Absolute Maximum Ratings ................................................................................................ 9

6.2. Electrical Characteristics: Current Consumption................................................................. 9

6.3. Main Battery ........................................................................................................................ 9

6.4. Battery Operating Time and Charging Time ....................................................................... 9

6.5. Operating Indicators.......................................................................................................... 10

7. Optical Specifications.............................................................................................................. 11

7.1.1. Tilt of Laser Scan Line .............................................................................................................11

7.1.2. Curvature of Scan ....................................................................................................................11

8. Technical Specifications.......................................................................................................... 12

8.1. Print Contrast Signal (PCS) .............................................................................................. 12

8.2. Minimum Resolution.......................................................................................................... 12

8.3. Scan Area and Resolution ................................................................................................ 13

8.3.1. Depth of Field...........................................................................................................................13

8.4. Pitch, Skew, and Tilt.......................................................................................................... 14

8.4.1. Pitch Angle...............................................................................................................................14

8.4.2. Skew Angle and Dead Zone ....................................................................................................15

8.4.3. Tilt Angle ..................................................................................................................................16

8.5. Curvature .......................................................................................................................... 17

9. Interface Specifications ........................................................................................................... 17

9.1. Wireless Interface ............................................................................................................. 17

Opticon

OPL 2724

Specifications Manual

9.1.1. Frequency Band.......................................................................................................................18

10. Default Settings ........................................................................................................................ 19

10.1. Set Default Interface ......................................................................................................... 19

10.2. Default Settings 1: Readable Codes ................................................................................. 19

10.3. Default Settings 2: Read Options, Trigger, Buzzer ........................................................... 21

10.4. Default Settings 3: Communication Options ..................................................................... 21

10.5. Default Settings 4: Bluetooth Options ............................................................................... 21

11. Serial Number and Labeling.................................................................................................... 22

12. Packaging Specifications ........................................................................................................22

12.1. Individual Packaging Specification.................................................................................... 22

12.2. Accessory Specifications .................................................................................................. 22

13. Durability................................................................................................................................... 23

13.1. Static Electricity................................................................................................................. 23

13.2. Shock ................................................................................................................................ 23

13.2.1. Drop Test (without packaging).................................................................................................23

13.3. Dust and Drip Proof........................................................................................................... 23

14. Reliability................................................................................................................................... 24

15. Regulatory Compliance ...........................................................................................................24

15.1. Laser Safety ...................................................................................................................... 24

15.2. Product Safety................................................................................................................... 24

15.3. EMC .................................................................................................................................. 24

15.4. RoHS................................................................................................................................. 24

15.5. R&TTE .............................................................................................................................. 25

15.6. Radio Law ......................................................................................................................... 25

15.7. State of California: Perchlorate Best Management Practices ........................................... 25

16. Safety......................................................................................................................................... 26

16.1. Shock ................................................................................................................................ 26

16.2. Temperature Conditions.................................................................................................... 26

16.3. Foreign Materials .............................................................................................................. 26

16.4. Other ................................................................................................................................. 26

17. Mechanical Drawing................................................................................................................. 27

Opticon

OPL 2724

Specifications Manual

Table of Figures

Figure 1: Ambient light immunity .................................................................................................. 8

Figure 2: Laser scan tilt and curvature ........................................................................................11

Figure 3: Depth of field ............................................................................................................... 13

Figure 4: Pitch ............................................................................................................................ 14

Figure 5: Skew and dead zone................................................................................................... 15

Figure 6: Tilt angle ...................................................................................................................... 16

Figure 7: Curvature..................................................................................................................... 17

Figure 8: Serial number diagram ................................................................................................ 22

Figure 9: Mechanical drawing..................................................................................................... 27

Opticon

OPL 2724

Specifications Manual

1. Abstract

This document provides master specifications on the OPL 2724 wireless barcode scanner

(hereafter referred to as “scanner”).

2. Overview

This scanner uses wireless barcode technology. Scanned data is transferred to the designated

device via wireless communication (Bluetooth V1.2). Short-wavelength red laser beams

enhance the visibility of scanning lines for easier aiming under adverse lighting conditions.

To start a scan, press the trigger switch. Do not allow the scanner to directly touch the surface

of a barcode when scanning. Code options, read options, and communication settings can be

configured by sending commands or by reading barcode labels.

If the OPL 2724 is disconnected because it is out of range or the Bluetooth device is not

available, scanned data will be saved in the built-in scanner memory. The OPL 2724 uses two

AAA alkaline batteries as its power supply.

This product complies with RoHS.

Supported symbologies:

Linear (1D) Postal 2D

JAN/UPC/EAN, incl. add-on Chinese Post Composite Codes

Codabar/NW-7 Korean Postal Authority Code MicroPDF417

Code 11 PDF417

Code 39

Code 93

Code 128

GS1-128 (EAN-128)

GS1 Databar (RSS)

IATA

Industrial 2of5

Interleaved 2of5

ISBN-ISMN-ISSN

Matrix 2of5

MSI/Plessey

S-Code

Telepen

Tri-Optic

UK/Plessey

Opticon

OPL 2724

Specifications Manual

3. Physical Features

3.1. Dimensions

W 96 x D 40 x H 22 mm

3.2. Weight

50 g max. (excluding the weight of the battery)

3.3. Color

Off white

4. Environmental Specifications

4.1. Operating Temperature and Humidity

Temperature: -5 to 50 °C

Humidity: 30 to 80%

4.2. Storage Temperature and Humidity

Temperature: -10 to 60 °C

Humidity: 20 to 90%

Opticon

OPL 2724

Specifications Manual

4.3. Ambient Light Immunity

Scanning performance is guaranteed when the range of illumination on a barcode

surface is between zero and the following values:

Incandescent Light to 3000 lx

Fluorescent Light to 3000 lx

Sunlight to 50,000 lx

Figure 1: Ambient light immunity

Conditions

Barcode Sample: OPTOELECTRONICS Test Sample

PCS: 0.9

Resolution: 0.25 mm

Symbology: 8-digit Code 39

Quiet zone: 10 mm

N/W ratio: 1:2.5

Distance: 150 mm

Angle (see note below): α= 0° β= 15° γ= 0°

Curvature: R = ∞

Power supply voltage: 3.6 V

Direct light or specular reflection from a light source should be prevented from entering

the acceptance area.

Note: α, βand γrespectively represent pitch, skew and tilt. Please see section 8 for how

these values are defined.

Opticon

OPL 2724

Specifications Manual

5. Controls

Item Specifications Notes

CPU 16-bit CISC CPU

Clock frequency 14.74 MHz

SRAM: 32 KB For WORK/DATA

Flash ROM: 256 KB For BIOS/AP

6. Electrical Specifications

6.1. Absolute Maximum Ratings

Parameter Symbol Value Unit

Power supply voltage VCC -0.3 to 3.6 V

6.2. Electrical Characteristics: Current Consumption

Item Specifications Conditions

In standby state 1.5 mA or less No Bluetooth communication; no laser scanning

In communication 35 mA or less With Bluetooth communication; no laser scanning

Maximum current 125 mA or less With Bluetooth communication; with laser scanning

Testing conditions Power supply voltage: 3.0 V, Operating temperature: 25° C

6.3. Main Battery

The main battery power is provided by LR-03 (two AAA alkaline batteries).

6.4. Battery Operating Time and Charging Time

Parameter Specification Note

Battery life (1) About 48 hours Scanning twice every 10 seconds;

Bluetooth always ON.

Battery life (2) 30 days or longer When scanning 100 times a day. (Connect

Bluetooth only when transmitting data.)

Data retention

time

48 hours; Lithium secondary battery

(3.4 mAh)

After the discharge of main batteries.

Current

consumption

1.5 mA or less

125 mA or less

In stand-by state

In operating state

Operating

conditions

Normal temperature

Barcode sample: Code-39 (PCS:

0.9, Resolution: 0.25 mm)

Note: Battery life may be shorter than specified above when the quality of the battery

pack is degraded.

Opticon

OPL 2724

Specifications Manual

6.5. Operating Indicators

The OPL 2724 displays its operating state with LEDs and a buzzer.

Action Indicator / Buzzer Description

Start-up beep 6 short beeps (low, medium, high,

low, medium, high)

Battery is placed in OPL 2724 (start-up buzzer)

Blue LED is flashing OPL 2724 is attempting to establish a

Bluetooth connection

Blue LED is flashing slow OPL 2724 is connectable (as slave)

Blue LED on and high sound for 1

second

Bluetooth connection was (re)established

Connecting /

Connectable

When pressing trigger: High-low

sound of 0.2 seconds followed by the

blue or red LED flashing.

The user has pressed the trigger long enough

to create or break the connection. After the

signals, the user can release the trigger key.

Red LED on with low sound for 1

second

Connection attempt failed

Connection loss is detected

During ‘Auto reconnect time’ every 15 or 30

seconds (depending on connection type)

Red LED is flashing OPL 2724 is disconnecting a Bluetooth

connection

Disconnecting /

Connection

failure

Connection

lost

Red LED on and a long high-low

sound for 1.6 seconds

OPL 2724 successfully disconnected the

Bluetooth connection

Green LED and beep as configured in

the Universal Menu Book at Chapter

6.1. and 6.2

Valid barcode label read with an active

Bluetooth connection

Short green LED and beep of half the

length as configured in the Universal

Menu Book at Chapter 6.1 and 6.2

Valid barcode label read and stored in memory

(data is not transmitted; i.e., because there is

no active Bluetooth connection

Orange LED as configured in the

Universal Menu Book at Chapter 6.2

with low sound

Valid barcode label read with no active

Bluetooth connection

Barcode

reading

Short click sound Partial read beep of (Micro)PDF417 decoder

High-low sound with LED:

Green (Misc.) / Red (Disconnect) /

Blue (Connect)

Valid Bluetooth action label read (i.e., connect /

disconnect / unpair )

Orange LED on and low sound of 0.2

seconds

Bluetooth action label read that could not be

executed because OPL 2724 was already

(dis)connected

Action /

configuration

label reading

Slow beeping sound Menu book configuration mode

Very slow blinking red LED Low battery indicator

Miscellaneous Green LED flashes and 8 high short

beeps

Error correction busy of (Micro)PDF417 data

with a high error correction level

Buzzer Loudness: 70 dBA or higher (when

the scanner is set to “Loud”)

Buzzer loudness was estimated at a point 10

cm behind the scanner.

Andere Handbücher für OPL 2724 ZAPPER

Inhaltsverzeichnis

Andere Opticon Barcode-Lesegerät Handbücher

Opticon

Opticon NLV-4001 Bedienungsanleitung

Opticon

Opticon N LB 9625 Series Bedienungsanleitung

Opticon

Opticon OPR 3201 Bedienungsanleitung

Opticon

Opticon 25-WEDGE-04 Bedienungsanleitung

Opticon

Opticon OPL-9815 Bedienungsanleitung

Opticon

Opticon OPR 3201 Bedienungsanleitung

Opticon

Opticon OPR 3001 Bedienungsanleitung

Opticon

Opticon Code Reader 2.0 Bedienungsanleitung

Opticon

Opticon OPN2004 Benutzerhandbuch

Opticon

Opticon OPN2005 Bedienungsanleitung

Opticon

Opticon NFT 2200 Bedienungsanleitung

Opticon

Opticon OPR 3101 Bedienungsanleitung

Opticon

Opticon OPI 2201 Bedienungsanleitung

Opticon

Opticon OPN2003 Bedienungsanleitung

Opticon

Opticon PHL 2700 Bedienungsanleitung

Opticon

Opticon LGZ 7225 Bedienungsanleitung

Opticon

Opticon OPN2002 Gebrauchsanweisung

Opticon

Opticon RS-2006 Bedienungsanleitung

Opticon

Opticon IRU 4100 Bedienungsanleitung

Opticon

Opticon OPI 4002 Bedienungsanleitung

Opticon

Opticon OPL 972 Series Bedienungsanleitung

Opticon

Opticon CS1504 Bedienungsanleitung

Opticon

Opticon OPL 7836 Bedienungsanleitung

Opticon

Opticon 25-WEDGE-06 Bedienungsanleitung

Beliebte Barcode-Lesegerät Handbücher anderer Marken

POSMicro

POSMicro Datalogic PowerScan D7100 Bedienungsanleitung

Marson

Marson MT780 Kurzanleitung zur Einrichtung

NCR

NCR RealPOS Bedienungsanleitung

Motorola

Motorola SE3300 Kurzanleitung zur Einrichtung

Element

Element P130BT Bedienungsanleitung

Motorola

Motorola Symbol LS3008 Installations- und Betriebshandbuch

Meec tools

Meec tools OBD-II / VAG Bedienungsanleitung

SICK

SICK CLP 100 Bedienungsanleitung

Royal Tag SA

Royal Tag SA I-Read Bedienungsanleitung

Welch Allyn

Welch Allyn IMAGETEAM 3800 Bedienungsanleitung

Meteor

Meteor 8310 Bedienungsanleitung

Denso

Denso BHT-500B Bedienungsanleitung

Datalogic

Datalogic Heron HD3130 Bedienungsanleitung

Motorola

Motorola MP6000 Montageanleitung

Newland

Newland NLS-HR15-BT Bedienungsanleitung

ARTDEV

ARTDEV AS-1310 Bedienungsanleitung

Aopos

Aopos AS290 Bedienungsanleitung

ENS

ENS 367-5455 Bedienungsanleitung
