Oregon Scientific THGR122NX Bedienungsanleitung

Remote Thermo-Hygrometer Sensor

Model: THGR122NX

USER MANUAL

INTRODUCTION

Thank you for selecting the Oregon Scientific™ Remote

Thermo-Hygrometer Sensor (THGR122NX). This

product is compatible various wireless weather station

products, such as the BAR628HG and BAR629HG.

Keep this manual handy as you use your new product.

It contains practical step-by-step instructions, as well

as technical specifications and warnings you should

know.

CONTENTS

Introduction ............................................................. 1

Product Overview ................................................... 2

Remote Sensor (THGR122NX) ........................... 2

Getting Started ........................................................ 3

Batteries .............................................................. 3

Table Stand or Wall Mount .................................. 3

Remote Sensor (THGR122NX) ............................... 3

Setup Sensor ....................................................... 3

Safety and Care ....................................................... 5

Warnings .................................................................. 5

Troubleshooting ...................................................... 5

Specifications .......................................................... 5

Remote Sensor Dimensions ............................... 5

Temperature ........................................................ 5

Remote Sensor (THGR122NX) ........................... 6

Power .................................................................. 6

About Oregon Scientific ......................................... 6

EC-Declaration of Conformity ................................ 7

THGR122NX_EN_R2 12/02/2004, 11:301

PRODUCT OVERVIEW

REMOTE SENSOR (THGR122NX)

1. LCD display

2. LED status indicator

1. Wall mount hole

2. RESET hole

3. CHANNEL number (1-3)

4. Battery compartment

(Battery compartment cover not shown)

THGR122NX_EN_R2 12/02/2004, 11:302

GETTING STARTED

BATTERIES

Remote unit 2 x UM-4 (AAA) 1.5V batteries

Insert batteries before first use, matching the polarity

(+ and -) as shown in the battery compartment. For best

results, install batteries in the remote sensor before the

main unit. Press RESET after each battery change.

NOTE Do not use rechargeable batteries.

shows when batteries are low.

NOTE It is recommended that you use alkaline batteries

with this product for longer performance.

TABLE STAND OR WALL MOUNT

To use the remote sensor stand or wall mount:

REMOTE SENSOR (THGR122NX)

SETUP SENSOR

1. Open the remote sensor battery compartment with

a small Phillips screwdriver.

2. Insert the batteries, matching the polarity (+ and -)

as shown in the battery compartment.

THGR122NX_EN_R2 12/02/2004, 11:303

SWITCH OPTION

Channel Channel 1-3. If you are using more than

one sensor, select a different channel for

each sensor.

3. Set the channel. The switch is located in the battery

compartment.

4. Place the sensor near the main unit. Press RESET

on the sensor. Then, press the appropriate main unit

button (as specified in the main unit manual) to

initiate signal sending between the sensor and the

main unit. The reception icon on the main unit will

blink for approximately 3 minutes while it is searching

for the sensor.

5. Close the remote sensor battery compartment.

6. Secure the sensor in the desired location using the

wall mount or table stand.

For best results:

•Insert the batteries and select the channel before

you mount the sensor.

•Place the sensor out of direct sunlight and

moisture.

•Do not place the sensor more than 30 metres

(98 feet) from the main (indoor) unit.

•Position the sensor so that it faces the main

(indoor) unit, minimizing obstructions such as

doors, walls, and furniture.

•Place the sensor in a location with a clear view

to the sky, away from metallic or electronic

objects.

•Position the sensor close to the main unit during

cold winter months as below-freezing

temperatures may affect battery performance and

signal transmission.

You may need to experiment with various locations to

get the best results.

THGR122NX_EN_R2 12/02/2004, 11:304

SAFETY AND CARE

Clean the product with a slightly damp cloth and

alcohol-free, mild detergent. Avoid dropping the product

or placing it in a high-traffic location.

WARNINGS

This product is designed to give you years of service if

handled properly. Oregon Scientific will not be

responsible for any deviations in the usage of the

device from those specified in the user instructions or

any unapproved alterations or repairs of the product.

Observe the following guidelines:

•Never immerse the product in water. This can

cause electrical shock and damage the product.

•Do not subject the product to extreme force,

shock, or fluctuations in temperature or humidity.

• Do not tamper with the internal components.

•Do not mix new and old batteries or batteries

of different types.

•

Do not use rechargeable batteries with this product.

•Remove the batteries if storing this product for

a long period of time.

•Do not scratch the LCD display.

NOTE The technical specification of this product and

contents of this user guide are subject to change

without notice. Images not drawn to scale.

TROUBLESHOOTING

PROBLEM SYMPTOM REMEDY

Remote Cannot locate Check batteries

sensor remote sensor Check location

Cannot change Check sensors. Only

channel one sensor is

working

Data does not Initiate a manual

match main unit sensor search

SPECIFICATIONS

REMOTE SENSOR DIMENSIONS

L x W x H 92 x 60 x 20 mm

(3.6 x 2.4 x 0.79 inches)

Weight 63 grams (2.22 ounces)

without battery

TEMPERATURE

Unit ˚C

Outdoor range -20˚C to 60˚C

Resolution 0.1˚C

THGR122NX_EN_R2 12/02/2004, 11:305

ABOUT OREGON SCIENTIFIC

Visit our website (www.oregonscientific.com) to learn

more about Oregon Scientific products such as digital

cameras; MP3 players; children’s electronic learning

products and games; projection clocks; health and

fitness gear; weather stations; and digital and conference

phones. The website also includes contact information

for our customer care department in case you need to

reach us, as well as frequently asked questions and

customer downloads.

We hope you will find all the information you need on

our website, however if you’d like to contact the Oregon

Scientific Customer Care department directly, please

visit:

www2.oregonscientific.com/service/support

Call 949-608-2848 in the US.

For international enquiries, please visit:

http://www2.oregonscientific.com/about/international/

default.asp

REMOTE SENSOR (THGR122NX)

RF frequency 433 MHz

Range 30 metres (98 feet) with

no obstructions

Transmission Every 40 seconds

Channel No. 1 - 3

POWER

Sensor batteries 2 x UM-4 (AAA) 1.5V

NOTE It is recommended that you use alkaline batteries

with this product for longer performance.

THGR122NX_EN_R2 12/02/2004, 11:306

EC-DECLARATION OF CONFORMITY

Hereby, Oregon Scientific, declares that this Remote

Thermo-Hygrometer Sensor is in compliance with the

essential requirements and other relevant provisions of

Directive 1999/5/EC.

A copy of the signed and dated Declaration of Conformity

is available on request via our Oregon Scientific

Customer Service.

COUNTRIES RTTE APPROVAL COMPLIED

All EC countries, Switzerland

and Norway

THGR122NX_EN_R2 12/02/2004, 11:307

Remote Thermo-Hygrometer Sensor

Model: THGR122NX

USER MANUAL

THGR122NX_EN_R2 12/02/2004, 11:308

086-003640-029

THGR122NX_EN_R2 12/02/2004, 11:309
