Panasonic KX-TD816 Benutzerhandbuch

Digital Super Hybrid System

KX-TD816

KX-TD1232

Installation Quick Guide

for

KX-TD7590CE

Table of Contents

1.0DECT Programming (PS Registration)........................................................................3

2.0Site Survey.................................................................................................................7

Note

This guide shows you the additional features for the DECT Portable Station (KX-TD7590)

Please refer to this guide in addition to the current installation Manual.

1.0 DECT programming

[650] PS Registration

Description

Assigns a registration number and an extension number to each PS. Display PT and the PS

whose registration number is to be set are required for this programme.

Selection

(With a display PT)

• PS registration number:

KX-TD816 – 01 through 16

KX-TD1232 – 01 through 64

• PS extension number: 2 through 4 digits

(With a PS)

• DECT system number: 1 through 4

•PSpassword:4 through 8 digits

• System lock password: 1 through 4 digits

Default

All PSs – Not Stored

Programming

[Registering for the first time]

(With a display PT)

1. Enter 650.

Display: PS Registration

2. Press NEXT.

Display: PS NO?

3. Enter the PS registration number.

Display example: PS01:Not Stored

4. Enter the PS extension number.

Display example: PS01:Ext 281

5. Press STORE.

Display (If enabled): Executing

Continue programming from step 6 with a PS within five minutes.

Display (If disabled): Rejected

The Cell Station (CS) may not be connected or not working. After connecting the CS

or resetting the PBX, wait for at least one minute and try again from the beginning.

6. Press the POWER button for a while (about 5 seconds).

7. Press the FUNCTION button.

8. Press the FUNCTION button again.

Or Press the UP/DOWN button repeatedly until “PROGRAM” is selected and then press the

SELECT button.

9. Press the UP/DOWN button repeatedly until the display below is selected.

Display: INITIAL SETTING

10.Press the SELECT button.

11.Press the UP/DOWN button repeatedly until the display below is selected.

Display: REGISTRATION

12.Enter the SELECT button.

13.Press the UP/DOWN button repeatedly until the desired DECT system number is

selected.

Display example:REGISTRATION

DECT-SYS 1

DECT-SYS 2

14.Press the SELECT button.

15.Enter the PS password.

16.Press the AUTO/OK button.

You will hear a confirmation tone and the display changes as follows.

Display example: DECT-SYS LOCK

ENABLE

DISABLE

17.Enter the UP/DOWN button to select “DISABLE” or “ENABLE” for the System Lock.

Display example: DECT-SYS LOCK

(With a PS)

Display example: ENTER PASSWORD

=--------

Display example: ENTER PASSWORD

=****----

Display: EXECUTING

ENABLE

DISABLE

18.Press the SELECT button.

Display example:

19.If you select "ENABLE" in step 17, enter a System Lock password.

20.Press the AUTO/OK button.

21.Enter the System Lock password again.

22.Press the AUTO/OK button.

23.To programme another PS, press NEXT or PREV, or SELECT and the desired PS

registration number.

24.Repeat steps 4 through 22.

25.Press END.

[Re-registering] (e.g. when changing the DECT system)

1. Repeat steps 1 through 8 of the “Registering for the first time” programming.

2. Press the UP/DOWN button repeatedly until the display below is selected.

Display: PS-PROGRAM

3. Press the SELECT button.

4. Press the UP/DOWN button repeatedly until the display below is selected.

Display: DECT-SYS SETTING

5. Press the SELECT button.

If a System Lock password is registered before, the display below will appear.

(if disabled):

(if enabled) :

UNLOCKED

ENTER PASSWORD

=----

Display: ENTER PASSWORD

=****

Display: REENTER PASSWORD

=----

Display: REENTER PASSWORD

=****

Display: LOCKED

(With a display PT)

Display example: DECT-SYS LOCK

PASSWORD =----

6. Enter a System Lock password and press the AUTO/OK button, if required.

Display: DECT-SYS LOCK

PASSWORD =****

7. Go to steps 11 through 25 of the “Registering for the first time” programming.

Conditions

• You can assign an extension number to each PS also in programme, [671] PS Extension

Number Set.

• The PS password can be assigned in programme [672] PS Password Set.

• One PS must have only one registration number. It is not possible to assign the different

registration number for one PS.

• If the PS extension number or the PS password is changed after registering, the PS cannot

be used until it is registered again in this programme.

• After pressing the AUTO/OK button in step 16, do not press END before you hear a

confirmation tone, or it may not registered correctly.

• To re-assign the PS, which is set the System Lock, to the other DECT system, it is required

to cancel the System Lock first in PS Programming, “DECT System Lock Password Set.”

• Register the PS from a manager DPT connected only to the master cabinet.

2.0 Site survey

Assigning the Cell Station ID Number to the PS

1. Keep pressing , and until following message will be displayed.

Display: FUNCTION (0-4)?

2. Press .

• When the Cell Station ID Number is assigned, it is displayed on the bottom line.

Display example: CS-ID SET

CS NO.(0-7)?

3. Enter the Cell Station number (0 through 7).

Display example: CS-ID SET

CS NO.(0-7)? 0

4. Press .

Display example: CSID0=

----->

5. Enter the Cell Station ID Number (0 through 9 and A through F).

• To erase a ID Number or letter, press .

• To enter letters, press the following buttons.

Display example: CSID0=

----->9005301234

6. Press .

• The assignment is completed.

Display example: CS-ID SET

CS NO.(0-7)?

7. Repeat steps 3 through 6 to assign other Cell Station ID numbers.

8. Press to return to the initial display.

Display: FUNCTION (0-4)?

199

ABC

CLR

(Flexible CO)

D (Intercom)

E (Auto/OK)

(Function)

(Flexible CO)

INT'

Note

• To return to the previous display, press .

Deleting the assigned Cell Station ID Number on the PS

1. Keep pressing , and until following message will be displayed.

Display: FUNCTION (0-4)?

2. Press .

Display example: CS-ID CLEAR

CS NO.(0-7)?

(#=ALL CLEAR)

3. Enter the Cell Station number (0 through 7).

Display example: CS-ID CLEAR

CS NO.(0-7)? 0

(#=ALL CLEAR)

4. Press .

• If you pressed # (ALL CLEAR) on step 3, the display return to the initial display.

Display example: CS-ID0=9005301234

ARE YOU SURE?

Y=TALK N=CANCEL

5. Press .

6. Repeat steps 3 through 5 to delete other Cell Station ID numbers.

7. Press to return to the initial display.

Display: FUNCTION (0-4)?

Note

• To return to the previous display, press .

199

DEF

Unplugging the Cable from the Cell Station

After assigning the Cell Station ID number to the PS, unplug the cable from the Cell Station

once.

DIP-Switch Setting

After unplugging the Cell Station once, set the DIP-Switch as follows.

1. Switch the Radio Signal Test Switch from OFF to ON.

2. Set the Channel Number Switches as desired.

Channel 1

1234

Channel 4

1234

Channel 7

1234

Channel 2

1234

Channel 5

1234

Channel 8

1234

Channel 3

1234

Channel 6

1234

Channel 9

1234

DIP-Switch

123456

OFF

Radio Signal

Test Switch

Channel Number Switch

(Default: Channel 0)

Note

• To see the signal strength of more than one Cell Station, the channel for each Cell Station

needs to be set.

• Up to eight Cell Stations can be surveyed at the same time. If more than one Cell Station is

in Radio Signal Test mode, each DIP-Switch channel must be different.

Connecting the AC Adaptor to the Cell Station

After setting the DIP-Switch, connect the AC Adaptor (KX-A11BS1: 230 VAC, 50 Hz) to the

Cell Station.

Note

Only use the AC Adaptor for the Site Survey.

Radio Signal Test using the PS

After locating the Cell Station(s) temporarily, execute the Radio Signal Test using the PS.

The PS scanswhether there is a Cell Station that canlink with on channel 0 right after entering

the Radio Signal Test mode. The channel to be scanned can be changed by pressing the

appropriate 0 through 9 keys.

1. Keep pressing , and until following message will be displayed.

Display: FUNCTION (0-4)?

2. Press .

•To survey other slots, scroll by pressing (Previous) or (Next).

•To survey other channels, enter the channel number (0 through 9).

Display: RADIO STRENGTH

<<<MEASURING>>> <--flashing while testing

Note

• To return to the previous display, press .

199
