Panasonic FP7 Series Bedienungsanleitung

PROGRAMMABLE CONTROLLER

FP7 Analog Output Unit

User's Manual

WUME-FP7AOH-01

2013.3 panasonic.net/id/pidsx/global

Safety Precautions

Observe the following notices to ensure personal safety or to prevent accidents.

To ensure that you use this product correctly, read this User’s Manual thoroughly before use.

Make sure that you fully understand the product and information on safety.

This manual uses two safety flags to indicate different levels of danger.

WARNING

If critical situations that could lead to user’s death or serious injury is assumed by

mishandling of the product.

-Always take precautions to ensure the overall safety of your system, so that the whole

system remains safe in the event of failure of this product or other external factor.

-Do not use this product in areas with inflammable gas. It could lead to an explosion.

-Exposing this product to excessive heat or open flames could cause damage to the lithium

battery or other electronic parts.

CAUTION

If critical situations that could lead to user’s injury or only property damage is

assumed by mishandling of the product.

-To prevent excessive exothermic heat or smoke generation, use this product at the values

less than the maximum of the characteristics and performance that are assured in these

specifications.

-Do not dismantle or remodel the product. It could cause excessive exothermic heat or smoke

generation.

-Do not touch the terminal while turning on electricity. It could lead to an electric shock.

-Use the external devices to function the emergency stop and interlock circuit.

-Connect the wires or connectors securely.

The loose connection could cause excessive exothermic heat or smoke generation.

-Do not allow foreign matters such as liquid, flammable materials, metals to go into the inside

of the product. It could cause excessive exothermic heat or smoke generation.

-Do not undertake construction (such as connection and disconnection) while the power

supply is on. It could lead to an electric shock.

-This manual and its contents are copyrighted.

-You may not copy this manual, in whole or part, without written consent of Panasonic

Industrial Devices SUNX Co., Ltd.

-Windows is a registered trademark of Microsoft Corporation in the United States and other

countries.

-All other company names and product names are trademarks or registered trademarks of

their respective owners. PLC_ORG

Introduction

Thank you for buying a Panasonic product. Before you use the product, please carefully read

the installation instructions and the users manual, and understand their contents in detail to

use the product properly.

Types of Manual

•

There are different types of users manual for the FP7 series, as listed below. Please refer to a relevant

manual for the unit and purpose of your use.

•

The manuals can be downloaded on our website:

http://industrial.panasonic.com/ac/e/dl_center/manual/ .

Unit name or purpose of

use Manual name Manual code

FP7 Power Supply Unit

FP7 CPU Unit FP7 CPU Unit Users Manual

(Hardware) WUME-FP7CPUH

Instructions for Built-in

COM Port

FP7 Extension

(Communication)

Cassette

FP7 CPU Unit Users Manual

(COM Port Communication) WUME- FP7COM

Instructions for Built-in

LAN Port FP7 CPU Unit Users Manual

(LAN Port Communication) WUME-FP7LAN

FP7 Digital Input/Output Unit FP7 Digital Input/Output Unit Users Manual WUME-FP7DIO

FP7 Analog Input Unit FP7 Analog Input Unit Users Manual WUME-FP7AIH

FP7 Analog Output Unit FP7 Analog Output Unit Users Manual WUME-FP7AOH

FP7 Positioning Unit FP7 Positioning Unit Users Manual WUME-FP7POSP

PHLS System PHLS System Users Manual WUME-PHLS

Programming Software

FPWIN GR7 FPWIN GR7 Introduction Guidance WUME-FPWINGR7

Table of Contents

1. Unit Functions and Restrictions........................................ 1-1

1.1 Unit Functions and Operation................................................................. 1-2

1.2 Basic Operation of Analog Output Processing ....................................... 1-3

1.2.1 Analog Output Processing.......................................................................1-3

1.3 Restrictions on Units Combination ......................................................... 1-4

1.3.1 Limitations on the Power Consumption...................................................1-4

2. Names and Functions of Parts .......................................... 2-1

2.1 Analog Output Unit ................................................................................. 2-2

3. Wiring................................................................................... 3-1

3.1 Wiring of Terminal Block ........................................................................ 3-2

3.2 Analog Output Connections ................................................................... 3-3

3.2.1 Voltage Output (-10 to +10, 0 to +10, 0 to +5, and +1 to +5 V) .............3-3

3.2.2 Current Output (0 to +20 and +4 to +20 mA) ..........................................3-4

4. Unit Settings and Data Writing .......................................... 4-1

4.1 Confirming the I/O Number Allocations and First Word Number............ 4-2

4.1.1 Occupied I/O Area and I/O Allocations ...................................................4-2

4.1.2 Confirming the I/O Number Allocations...................................................4-3

4.2 Configuration Settings ............................................................................ 4-4

4.2.1 Configuration of Analog Output Unit .......................................................4-4

Table of Contents

iii

4.2.2 Unit Setting and Conversion Processing Time .......................................4-6

4.3 Writing Analog Output Data .................................................................... 4-7

4.4 Timing Chart of Output Processing......................................................... 4-8

5. Conversion Characteristics of Analog Output .................5-1

5.1 Voltage Range ........................................................................................ 5-2

5.1.1 Voltage Output Range: -10 to +10 V (0.32 mV, 1/62,500)......................5-2

5.1.2 Voltage Output Range: 0 to +10 V (0.32 mV, 1/31,250) .........................5-3

5.1.3 Voltage Output Range: 0 to +5 V (0.16 mV, 1/31,250) ...........................5-3

5.1.4 Voltage Output Range: +1 to +5 V (0.16 mV, 1/25,000).........................5-4

5.2 Current Range ........................................................................................ 5-5

5.2.1 Current Output Range: 0 to +20 mA (0.64μA, 1/31,250) ........................5-5

5.2.2 Current Output Range: +4 to +20 mA (0.64μA, 1/25,000) ......................5-5

6. Option Settings for Analog Output ....................................6-1

6.1 Offset/Gain Processing Settings............................................................. 6-2

6.2 Scale Conversion Settings...................................................................... 6-4

6.3 Settings for Upper and Lower Output Clipping ....................................... 6-5

6.4 Analog Output Hold while in PROG. Mode............................................. 6-7

6.5 Configuration by Programming ............................................................... 6-8

7. What to Do If an Error Occurs ............................................7-1

7.1 What to Do If an Error Occurs ................................................................ 7-2

7.1.1 Unstable Analog Output Value................................................................7-2

7.1.2 Unchanged Analog Output Value ...........................................................7-2

Table of Contents

8. Specifications...................................................................... 8-1

8.1 Specifications ......................................................................................... 8-2

8.2 List of I/O Allocations.............................................................................. 8-4

8.3 List of Unit Memory ................................................................................ 8-5

8.3.1 List of Unit Memory Numbers..................................................................8-5

8.3.2 List of Unit Memory Specifications in Detail ............................................8-6

8.4 Dimensions............................................................................................. 8-8

Unit Functions and

Restrictions

Unit Functions and Restrictions

1-2

1.1 Unit Functions and Operation

Features of analog output unit

The analog output unit converts its internal data into analog values to be output to inverters or

other analog-driven equipment.

•

Equipped with six types of output ranges (i.e., voltage ranges of -10 to +10, 0 to +10, 0 to +5, and +1 to

+5 and current ranges of 0 to +20 and +4 to +20 mA).

Analog output unit: 4 channels

•

A D/A conversion processing speed is as high as 25 μs/channel.

•

Converts set digital values into analog data with up to 16 bit in a resolution range of 1/25,000 to

1/62,500.

1.2 Basic Operation of Analog Output Processing

1-3

1.2 Basic Operation of Analog Output Processing

1.2.1 Analog Output Processing

Analog output is processed as explained below.

Operation of analog output unit

(1) Writing digital data

A user program is used to write digital data to the output relay area (WY) on a channel-by-

channel basis so that the digital data will be output in analog form.

(2) Analog conversion processing

Data written to the unit is converted to an analog value in sequence automatically.

(3) Output to analog-driven equipment

Converted analog values are output to inverters or other analog-driven equipment.

V or I

(2)

(3)

(1)

Option settings

The following option setting functions are provided for analog output processing. Any of the

option setting functions can be set, if necessary, by writing the function to the unit memory

(UM) by using the configuration menu of the FPWIN GR7 or a user program.

•

Offset/Gain processing

•

Scale conversion

•

Upper and lower output clipping

•

Analog output hold while in PROG. mode

Unit Functions and Restrictions

1-4

1.3 Restrictions on Units Combination

1.3.1 Limitations on the Power Consumption

The FP7 analog output unit has the following internal current consumption. When the system

is configured, the other units being used should be taken into consideration, and a power

supply unit with a sufficient capacity should be used.

Name Product no. Current

consumption

FP7 analog output unit AFP7DA4H 250 mA or less
