COMSPHERE

6700 SERIES NETWORK

MANAGEMENT SYSTEM

REMOTE MONITOR FEATURE

USER’S GUIDE

Document No. 6700-A2-GB23-10

October 1998

Printed on recycled paper

A 6700-A2-GB23-10

October 1998

Printed in U.S.A.

Notice

This publication is protected by federal copyright law. No part of this publication may be copied or distributed,

transmitted, transcribed, stored in a retrieval system, or translated into any human or computer language in any form

or by any means, electronic, mechanical, magnetic, manual or otherwise, or disclosed to third parties without the

express written permission of Paradyne Corporation, 8545 126th Ave. N., Largo, FL33773.

Paradyne Corporation makes no representation or warranties with respect to the contents hereof and specifically

disclaims any implied warranties of merchantability or fitness for a particular purpose. Further, Paradyne Corporation

reserves the right to revise this publication and to make changes from time to time in the contents hereof without

obligation of Paradyne Corporation to notify any person of such revision or changes.

Changes and enhancements to the product and to the information herein will be documented and issued as a new

release to this manual.

Warranty, Sales, and Service Information

Contact your local sales representative, service representative, or distributor directly for any help needed. For

additional information concerning warranty, sales, service, repair, installation, documentation, training, distributor

locations, or Paradyne worldwide office locations, use one of the following methods:

Via the Internet: Visit the Paradyne World Wide Web site at http://www.paradyne.com

Via Telephone: Call our automated call system to receive current information via fax or to speak with a

company representative.

— Within the U.S.A., call 1-800-870-2221

— Outside the U.S.A., call 1-727-530-2340

Document Feedback

We welcome your comments and suggestions about this document. Please mail them to Technical Publications,

Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773, or send e-mail to [email protected]. Include

the number and title of this document in your correspondence. Please include your name and phone number if you

are willing to provide additional clarification.

Trademarks

All products and services mentioned herein are the trademarks, service marks, registered trademarks or registered

service marks of their respective owners.

6700-A2-GB23-10 October 1998

Contents

About This Guide

Document Purpose and Intended Audience iii. . . . . . . . . . . . . . . . . . . . . . . . .

Document Summary iii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Product-Related Documents iv. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1 Introduction

What is the Remote Monitor Feature? 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Feature List 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Installation and Setup

Getting Started 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Prerequisites 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Hardware Prerequisites 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Software Prerequisites 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Installation Procedure 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Network Configuration

Remote Monitor Network Configuration 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Remote Status Servers 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Remote Status Monitors 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Index

Contents

ii 6700-A2-GB23-10

October 1998

This page intentionally left blank.

iii

6700-A2-GB23-10 October 1998

About This Guide

Document Purpose and Intended Audience

This guide describes how to install and use the COMSPHERE 6700 Series

Network Management System (NMS) Remote Monitor feature.

It is assumed that you have a basic understanding of modems and their

operation, are knowledgeable about data communications, and are familiar with

Windows terminology and conventions. You or your LAN administrator should

also have knowledge of TCP/IP.

Document Summary

Section Description

Chapter 1

Introduction.

Provides an overview of the Remote Monitor

feature.

Chapter 2

Installation and Setup.

Provides instructions for installing the

Remote Monitor feature.

Chapter 3

Network Configuration.

Describes procedures for changing

the status of servers.

Glossary Refer to

COMSPHERE 6700 Series Network Management

System User’s Guide,

Document Number 6700-A2-GY31.

Index Lists key terms, acronyms, concepts, and sections in

alphabetical order.

About This Guide

iv 6700-A2-GB23-10

October 1998

Product-Related Documents

Document Number Document Title

3000-A2-GA31

COMSPHERE 3000 Series Carrier, Installation

Manual

3610-A2-GB46

COMSPHERE 3600 Series Data Service Units,

Models 3610 and 3611, User’s Guide

3610-A2-GB48

COMSPHERE 3600 Series Data Service Units,

Models 3610 and 3611, Time Division Multiplexer,

Multichannel Multipoint, and Digital Bridge Options

Supplement

3610-A2-GB49

COMSPHERE 3600 Series Data Service Units,

Models 3610 and 3611, Dial Backup Module Options

Supplement

3810-A2-GB30

COMSPHERE 3800 Series Modems, Models 3810,

3811, and 3820, User’s Guide

3910-A2-GN32

COMSPHERE 3900 Series Modems, Models 3910

and 3911, Point-to-Point/Multipoint, Installation and

Operation Manual

6700-A2-GB20

COMSPHERE 6700 Series Network Management

System SNMP Proxy Agent Feature User’s Guide

6700-A2-GB21

COMSPHERE 6700 Series Network Management

System Multiuser Feature User’s Guide

6700-A2-GB22

COMSPHERE 6700 Series Network Management

System Network Configuration Guide

6700-A2-GB41

COMSPHERE 6700 Series Network Management

System Security Manager Feature Supplement

6700-A2-GY31

COMSPHERE 6700 Series Network Management

System User’s Guide

Contact your sales or service representative to order additional product

documentation.

Paradyne documents are also available on the World Wide Web at:

http://www.paradyne.com

Select

Service & Support

→

Technical Manuals

1-1

6700-A2-GB23-10 October 1998

Introduction 1

What is the Remote Monitor Feature?

The COMSPHERE 6700 Series NMS Remote Monitor feature provides

innovative management support for the DSU, Dial, and APL family of modems in

a client/server environment.

The 6700 Remote Monitor feature provides the capability to monitor and perform

diagnostics from a client workstation on devices defined in other 6700 servers.

Prior to this feature, the client workstation could only be connected to one server

known as the Active Server.

The Remote Monitor feature provides the user with the ability to monitor Alerts,

Calls, and Security Events. Status Server device profiles can also be viewed.

Feature List

In addition to all the features of the 6700 Series NMS, the Remote Monitor

feature provides the following capabilities:

Platform/Network Performance Monitoring

Knowledge of more than one NMS server

User-selectable active NMS server

The interface between the client and the server is accomplished via a TCP/IP

communication stack. The NMS server manages network information.

Introduction

1-2 6700-A2-GB23-10

October 1998

This page intentionally left blank.

2-1

6700-A2-GB23-10 October 1998

Installation and Setup 2

Getting Started

This chapter provides procedures for the Remote Monitor feature installation.

Please check that your Remote Monitor feature package includes the following in

addition to this manual:

Remote Monitor server software on one or more 3 1/2″disks

One Software Abstract

Prerequisites

Before you install the software, verify that you have met the recommended

hardware and software prerequisites.

Hardware Prerequisites

The following are the hardware requirements for installation of the Remote

Monitor feature server and client software:

486 Series, 66 MHz or higher PC (or compatible computer)

16 MB of RAM (32 MB of RAM is recommended)

Hard disk with 15 MB of free space and a minimum of 14 ms access time

Super VGA (800 x 600 resolution) or higher with 256 colors

Video accelerator card

Installation and Setup

2-2 6700-A2-GB23-10

October 1998

Software Prerequisites

You must have the following software installed before you install the Remote

Monitor feature on your 6700 NMS servers or clients:

HCOMSPHERE 6700 Series Network Management System

— NMS 5.0.2 or higher with Windows 95 or Windows NT

— NMS 4.0.9 or higher with MS-DOS Release 3.3 or higher

HCOMSPHERE 6700 Series NMS Multiuser Feature

HCOMSPHERE 6700 Series NMS Network Configuration Feature

HNetwork interface:

— NDIS-compliant and NDIS driver, or

— Open Data-Link Interface (ODI) and ODI network adapter

(Ethernet, FDDI, token ring, etc.), or

— Additional serial port (PPP, SLIP, or CSLIP)

Installation Procedure

The Remote Monitor feature software must be installed on all 6700 NMS servers

and clients.

To install the Remote Monitor feature server or client software, start from the

Program Manager window.

NOTE:

NMS is designed to be the primary application program running on a

personal computer. If you use NMS with other applications, it is your

responsibility to ensure compatibility.

The following procedure refers to Drive A. Use the disk drive that is appropriate

for your PC.

"Procedure

1. Insert Disk #1 into Drive A.

2. From the Program Manager window, if you are running:

— Windows 3.1, choose Run from the File menu.

— Windows 95 or Windows NT, choose the Start button and then Run.

3. In the Command Line field, type A:\INSTALL.
