MIM2-A2-GZ40-00 October 2004 1

MIM-2E1

Installation Instructions

Document Number MIM2-A2-GZ40-00

October 2004

Contents

Software and Firmware License Agreement ...................................................... 1

Product Documentation Online .......................................................................... 3

Unpacking and Inspecting the Equipment ......................................................... 3

Installing the MIM-2E1 ....................................................................................... 3

Connecting the E1 Line ..................................................................................... 4

E1 RJ45 Pinouts ................................................................................................ 5

E1 Default Settings ............................................................................................ 5

E1 Parameter Configuration .............................................................................. 6

LED Indicators ................................................................................................... 7

Regulatory Notices ............................................................................................ 7

Warranty, Sales, Service, and Training Information ........................................... 8

Software and Firmware License Agreement

The terms and conditions of this License Agreement (the “Agreement”) will apply

to the software and/or firmware (individually or collectively the “Software”)

incorporated into the Paradyne product (the “Product”) purchased by you and any

derivatives obtained from the Software, including any copy of either. If you have

executed a separate written agreement covering the Software supplied to you

under this purchase, such separate written agreement shall govern.

Paradyne Corporation (“Paradyne”) grants to you, and you (“Licensee”) agree to

accept a personal, non-transferable, non-exclusive, right (without the right to

ONCE YOU HAVE READ THIS LICENSE AGREEMENT AND AGREE TO ITS

TERMS, YOU MAY USE THE SOFTWARE AND/OR FIRMWARE INCORPORATED

INTO THE PARADYNE PRODUCT. BY USING THE PARADYNE PRODUCT YOU

SHOW YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE AGREEMENT.

IN THE EVENT THAT YOU DO NOT AGREE WITH ANY OF THE TERMS OF THIS

LICENSE AGREEMENT, PROMPTLY RETURN THE UNUSED PRODUCT IN ITS

ORIGINAL PACKAGING AND YOUR SALES RECEIPT OR INVOICE TO THE

LOCATION WHERE YOU OBTAINED THE PARADYNE PRODUCT OR THE

LOCATION FROM WHICH IT WAS SHIPPED TO YOU, AS APPLICABLE, AND YOU

WILL RECEIVE A REFUND OR CREDIT FOR THE PARADYNE PRODUCT

PURCHASED BY YOU.

2October 2004 MIM2-A2-GZ40-00

sublicense) to use the Software, solely as it is intended and solely as incorporated

in the Product purchased from Paradyne or its authorized distributor or reseller

under the following terms and conditions:

1. Ownership: The Software is the sole property of Paradyne and/or its licensors.

The Licensee acquires no title, right or interest in the Software other than the

license granted under this Agreement.

2. Licensee shall not use the Software in any country other than the country in

which the Product was rightfully purchased except upon prior written notice to

Paradyne and an agreement in writing to additional terms.

3. The Licensee shall not reverse engineer, decompile or disassemble the

Software in whole or in part.

4. The Licensee shall not copy the Software except for a single archival copy.

5. Except for the Product warranty contained in the manual, the Software is

provided “AS IS” and in its present state and condition and Paradyne makes

no other warranty whatsoever with respect to the Product purchased by you.

THIS AGREEMENT EXPRESSLY EXCLUDES ALL OTHER WARRANTIES,

WHETHER EXPRESS OR IMPLIED, OR ORAL OR WRITTEN, INCLUDING

WITHOUT LIMITATION:

a. Any warranty that the Software is error-free, will operate uninterrupted in

your operating environment, or is compatible with any equipment or

software configurations; and

b. ANY AND ALL IMPLIED WARRANTIES, INCLUDING WITHOUT

LIMITATION IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS

FOR A PARTICULAR PURPOSE AND NON-INFRINGEMENT.

Some states or other jurisdictions do not allow the exclusion of implied

warranties on limitations on how long an implied warranty lasts, so the above

limitations may not apply to you. This warranty gives you specific legal rights,

and you may also have other rights which vary from one state or jurisdiction to

another.

6. In no event will Paradyne be liable to Licensee for any consequential,

incidental, punitive or special damages, including any lost profits or lost

savings, loss of business information or business interruption or other

pecuniary loss arising out of the use or inability to use the Software, whether

based on contract, tort, warranty or other legal or equitable grounds, even if

Paradyne has been advised of the possibility of such damages, or for any

claim by any third party.

7. The rights granted under this Agreement may not be assigned, sublicensed or

otherwise transferred by the Licensee to any third party without the prior

written consent of Paradyne.

8. This Agreement and the license granted under this Agreement shall be

terminated in the event of breach by the Licensee of any provisions of this

Agreement.

9. Upon such termination, the Licensee shall refrain from any further use of the

Software and destroy the original and all copies of the Software in the

possession of Licensee together with all documentation and related materials.

10. This Agreement shall be governed by the laws of the State of Florida, without

regard to its provisions concerning conflicts of laws.

MIM2-A2-GZ40-00 October 2004 3

Product Documentation Online

Complete documentation for Paradyne products is available at

www.paradyne.com. Select Support →Technical Manuals.

To order a paper copy of a Paradyne document, or to speak with a sales representative,

please call 1-727-530-2000.

Unpacking and Inspecting the Equipment

HANDLING PRECAUTIONS FOR

STATIC-SENSITIVE DEVICES

This product is designed to protect sensitive components from damage

due to electrostatic discharge (ESD) during normal operation. When

performing installation procedures, however, take proper static control

precautions to prevent damage to equipment. If you are not sure of the

proper static control precautions, contact your nearest sales or service

representative.

If there is any visible damage, do not attempt to install the MIM-2E1; contact your

sales representative.

Installing the MIM-2E1

The MIM-2E1 Micro Interface Module provides additional uplink ports for the

AµD8000 ADSL Micro DSLAM or BSX8000-5 Broadband Services Switch.

NOTE: All MIMs are hot swappable, although removal of a MIM disengages the

upstream network connection for the DSLAM.

Procedure

1. Using a flat-head screwdriver to loosen the fastening screws, remove the

cover plate from the MIM port on the front of your AµD8000 or BSX8000.

CAUTION: The cover plate should be stored for possible future use: if the MIM

is removed from your AµD8000 or BSX-8000, it must be replaced with either

another MIM or a cover plate. Do not operate an AµD8000 or BSX8000 with

an open MIM port.

2. Align the MIM-2E1 with the module guides inside the MIM port.

3. Slide the MIM-2E1 firmly into place. Do not use excessive force.

4. Secure the MIM-2E1 by tightening the fastening screws on the MIM faceplate

with a flat-head screwdriver.

4October 2004 MIM2-A2-GZ40-00

Connecting the E1 Line

A primary feature of the MIM-2E1 is loop bonding capability, though the module

can function with a single E1 connection as well.

NOTE: A MIM-2E1 must be connected with E1 provider equipment; a connection

between the MIM-2E1 and E1 subscriber equipment will not function.

Loop Bonded Connection

Using two E1 lines for one network connection (loop bonding ) will net twice the

speed and data passing capability as a single E1 connection. A second E1 line

also provides backup should one of the lines become disabled. A MIM-2E1 can

only establish loop bonded connections with other loop bonding capable E1

provider equipment; refer to the E1 Loop Bonding Product to Product Feature

Compatibility list (Document Number COMP-A2-GK43 ).

Procedure

1. If a ferrite choke is supplied with your MIM:

— Open the ferrite choke.

— Make a loop at the end of your cables and close them in the ferrite choke.

Position the choke as close as possible to the RJ45 connectors.

— Snap shut the ferrite choke.

2. Plug your E1 cables into the E1 RJ45 ports (Port 1 and Port 2) on the

MIM-2E1 faceplate; the order of connection is not important.

3. Verify both connections: the Port 1 and Port 2 Lnk LEDs on the MIM-2E1

faceplate will flash green to indicate the connections are established and

operational.

Single E1 Connection

A single line connection may be established between a MIM-2E1 and Paradyne’s

E1 provider equipment (stand-alone or IP DSLAM module), regardless of loop

bonding capability.

04-17593

MIM2-A2-GZ40-00 October 2004 5

Procedure

1. If a ferrite choke is supplied with your MIM:

— Open the ferrite choke.

— Make a loop at the end of your cable and close it in the ferrite choke.

Position the choke as close as possible to the RJ45 connector.

— Snap shut the ferrite choke.

2. Plug your E1 cable into one of the two E1 RJ45 ports on the MIM-2E1. Either

port may be used.

3. Verify the connection: the E1 link LED on the front of the MIM will flash green

to indicate the connection is established and operational.

E1 RJ45 Pinouts

If you are using a shielded E1 cable for your network connection, it must be

grounded through pins 3, 6, 7, and 8.

E1 Default Settings

No configuration is necessary for the MIM-2E1 to operate at default settings:

Speed: Adaptive. The MIM-2E1 determines timeslot and bandwidth

configurations via communication with the remote E1 equipment to which it is

connected. Each E1 connection has the capability of receiving data across all

31 channels at 1,984 kbps.

Frame Type: Cyclic Redundancy Check (CRC)

Line Code: High Density Binary 3 (HDB3)

Timing: Adaptive. The MIM-2E1 determines clock source via communication

with the remote E1 equipment to which it is connected.

PIN CONNECTION

1RxRing

2RxTip

3 not used

4TxRing

5TxTip

6 not used

7 not used

8 not used

6October 2004 MIM2-A2-GZ40-00

E1 Parameter Configuration

MIM-2E1 parameters may be configured the web-based Network Management

System (NMS). Configurations for E1 Port 1 apply to E1 Port 2 as well; the two

ports cannot be configured independently. Refer to the NMS User’s Guide

(Document Number NMS-A2-GB20) for more detailed instructions.

Frame Type

Frame type is the E1 data encapsulation method. A frame consists of 248 bits

(8-bit samples of each of the 31 E1 data channels) plus 8 bits of overhead

transmitted at a rate of 8,000 frames per second (1.984 kbps) across the E1 line.

Cyclic Redundancy Check (Default) – Cyclic Redundancy Check (CRC)

scrutinizes data integrity across the E1 line by appending a hexadecimal

checksum to the end of each E1 frame (calculated from the previous E1 frame

contents). The remote modem then makes a similar calculation upon receipt of

each E1 frame and compares it to the checksum of the ensuing E1 frame.

No Cyclic Redundancy Check – NMS offers an option to disable the Cyclic

Redundancy Check function.

Line Code

Line code is the E1 mode of transmission. The two line code options outlined

below both fall within the International Telecommunication Union -

Telecommunication Standardization Sector (ITU-T) G.703 Standards for

Transmission Facilities.

High Density Binary 3 (Default) – High Density Binary 3 (HDB3) is used to

accommodate the minimum ones density requirement in the European public

network. HDB3 line encoding helps prevent loss of synchronization between

the MIM-2E1 and remote E1 equipment by using bipolar violations to

guarantee the presence of pulses in the E1 line.

Alternate Mark Inversion – Alternate Mark Inversion (AMI) simply alternates

positive and negative pulses. Although AMI links typically encounter long

strings of zeros which can potentially cause loss of synchronization between

units, Paradyne products meet the European minimum ones density

requirement internally such that loss of synchronization is prevented between

the MIM-2E1 and remote E1 equipment with AMI just as it is with HDB3.

MIM2-A2-GZ40-00 October 2004 7

LED Indicators

Regulatory Notices

UNITED STATES – EMI NOTICE:

This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to Part 15 of the FCC rules. These limits

are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

The authority to operate this equipment is conditioned by the

requirements that no modifications will be made to the equipment

unless the changes or modifications are expressly approved by

Paradyne Corporation.

Table 1. LEDs

LED STATE INDICATION ADDITIONAL INFORMATION

E1 Connections

(Port 1 Lnk and

Port 2 Lnk)

Flashing Green* E1 connection is established and

active.

Traffic is flowing.

Solid Green Problematic E1 connection. A connection exists but there is

indication of a problem with the E1 line.

No Illumination Loss of Synchronization

(LOS)The incoming connection

to the MIM-2E1 has been lost;

no data is being received.

If the outgoing connection from the

MIM-2E1 has also been lost then the

remote E1 equipment to which the MIM

is connected will have LOS as well.

E1 Alarms (Port 1

Alm and Port 2

Alm)

No Illumination E1 is operational. An established E1 link is operational

and has no alarm indications unless the

E1 Lnk LED remains unlit as well, in

which case the MIM-2E1 has LOS.

Solid Amber Remote Alarm Indication (RAI).

The outgoing connection from

the MIM-2E1 has been lost; no

data is being transmitted.

The remote E1 equipment has lost its

incoming connection and has LOS.

Pulsing Amber* Alarm Indication Signal (AIS). An

indirect connection has been

lost; the MIM-2E1 may no longer

be receiving data from the

remote E1 equipment.

The remote E1 equipment has lost a

connection with an intermediate device

and has LOS or RAI.

*A pulsing LED blinks steadily at a rate of once per second. A flashing LED blinks at a more rapid,

less constant rate.

8October 2004 MIM2-A2-GZ40-00

CANADA – EMI NOTICE:

This Class A digital apparatus meets all requirements of the Canadian

interference-causing equipment regulations.

Cet appareil numérique de la classe A respecte toutes les exigences du

règlement sur le matérial brouilleur du Canada.

EUROPEAN REGULATORY COMPLIANCE

The following regulatory compliance information applies to the MIM-2E1

as installed in the AµD8000 or BSX8000-5:

This Class A product complies with European Norm EN55022.

Warning: In a domestic environment this product may cause radio

interference in which case the user may be required to take adequate

measures to correct the situation.

Warranty, Sales, Service, and Training Information

Contact your local sales representative, service representative, or distributor

directly for any help needed. For additional information concerning warranty, sales,

service, repair, installation, documentation, training, distributor locations, or

Paradyne worldwide office locations, use one of the following methods:

Internet: Visit the Paradyne World Wide Web site at www.paradyne.com.

(Be sure to register your warranty at www.paradyne.com/warranty.)

Telephone: Call our automated system to receive current information by fax or

to speak with a company representative.

— Within the U.S.A., call 1-800-870-2221

— Outside the U.S.A., call 1-727-530-2340

!!.

*MIM2-A2-GZ40-00*

Inhaltsverzeichnis

Andere Paradyne Netzwerk-Hardware Handbücher

Paradyne

Paradyne Dual DSU 7511 Bedienungsanleitung

Paradyne

Paradyne COMSPHERE 3610 Bedienungsanleitung

Paradyne

Paradyne Hotwire 7995 Bedienungsanleitung

Paradyne

Paradyne iMarc SLV 9820-2M Bedienungsanleitung

Paradyne

Paradyne Comsphere 3510 Bedienungs- und Wartungshandbuch

Paradyne

Paradyne Hotwire 5620 RTU Bedienungsanleitung

Paradyne

Paradyne COMSPHERE 6700 Series Bedienungsanleitung

Paradyne

Paradyne Hotwire 8779 Bedienungsanleitung

Paradyne

Paradyne HotWire 8800 DSLAM Bedienungsanleitung

Paradyne

Paradyne Fan Tray Assembly 8820-S3-900 Bedienungsanleitung

Paradyne

Paradyne 8540 Bedienungsanleitung

Paradyne

Paradyne COMSPHERE 3550 Series Bedienungsanleitung

Paradyne

Paradyne MIM-10/100 Bedienungsanleitung

Paradyne

Paradyne ACCULINK 3161 CSU Bedienungsanleitung

Paradyne

Paradyne COMSPHERE 3610 Bedienungs- und Wartungshandbuch

Paradyne

Paradyne FrameSaver NP 64+ Bedienungsanleitung

Paradyne

Paradyne COMSPHERE 6700 Series Bedienungsanleitung

Paradyne

Paradyne COMSPHERE 3550 Series Bedienungsanleitung

Paradyne

Paradyne Jetstream CPX-1000 Betriebsanleitung

Paradyne

Paradyne 4000E Bedienungsanleitung

Paradyne

Paradyne COMSPHERE 3800PLUS Bedienungsanleitung

Paradyne

Paradyne Hotwire 5620 Bedienungsanleitung

Paradyne

Paradyne Comsphere 3510 Bedienungsanleitung

Paradyne

Paradyne ACCULINK 3163 DSU Bedienungsanleitung

Beliebte Netzwerk-Hardware Handbücher anderer Marken

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Bedienungsanleitung

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Bedienungsanleitung

Yudor

Yudor YDS-16 Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-320L Bedienungsanleitung

Samsung

Samsung ES1642dc Gebrauchsanweisung

Honeywell Home

Honeywell Home LTEM-PV Montageanleitung

evertz

evertz 7700 Series Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-343 Bedienungsanleitung

Asante

Asante AsanteBridge 1012 Bedienungsanleitung

FireBrick

FireBrick FB2700 Bedienungsanleitung

Audiovox Electronics

Audiovox Electronics ARWH2T Bedienungsanleitung

ADC

ADC DSX-1 Handbuch

NetComm

NetComm NF2 Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 5620 Bedienungsanleitung

Dell EMC

Dell EMC XC6420 Series Bedienungsanleitung

Lanner

Lanner NCA-1020A Bedienungsanleitung

Allied Telesis

Allied Telesis AT-TN121-A Bedienungsanleitung

Arista

Arista CCA-ETM-Q12 Bedienungsanleitung
