PowerWalker VFI 10000TCP 3/1 Bedienungsanleitung

Online UPS

PowerWalker VFI 10000TCP 3/1

PowerWalker VFI 10000TP 3/1

PowerWalker VFI 20000TP 3/1

Manual

EN/DE

Uninterruptible Power Supply System

CONTENT:

1. Safety ...........................................................................................................1

1.1 Installation...............................................................................................1

1.2 Operation................................................................................................2

1.3 Maintenance, Servicing and Faults ........................................................3

1.4 Transport ................................................................................................4

1.5 Storage ...................................................................................................4

1.6 Standards ...............................................................................................5

2. Description of Commonly Used Symbols................................................6

3. Introduction.................................................................................................7

3.1 System and Model Description...............................................................7

3.2 Product Specification and Performance...............................................10

4. Installation.................................................................................................13

4.1 Unpacking and Inspection....................................................................13

4.2 Input and Output Power Cords and Protective Earth Ground

Installation...................................................................................................16

4.3 Operating Procedure for Connecting with The External Battery..........21

5. Operation...................................................................................................23

5.1 Display Panel........................................................................................23

5.2 Operating Mode....................................................................................27

5.3 Turning On and Turning Off UPS .........................................................29

5.4 LCD Operation......................................................................................31

6. Special function........................................................................................40

6.1 HE Function..........................................................................................40

6.2 Converter Function...............................................................................40

6.3 Parallel Function...................................................................................41

6.4 PowerWalker VFI 10000TCP 3/1 Optional Design of Charger Current47

6.5 Backfeed Protection .............................................................................48

7. Trouble Shooting......................................................................................51

7.1 Trouble Shooting According To Warning Indication..............................51

7.2 Trouble Shooting According To Fault Indication...................................53

7.3 Trouble Shooting In Else Cases...........................................................54

8.Battery Maintenance, Replacement and Disposal.................................56

8.1 Maintenance.........................................................................................56

8.2 Replacement and Disposal of Batteries...............................................57

9. Communication Port.................................................................................60

9.1 RS232&USB Interface..........................................................................60

9.2 Intelligent Slot.......................................................................................60

9.3 AS400 Interface (Option)......................................................................60

10. Software Installation.....................................Error! Bookmark not defined.

1. Safety

Please read carefully the following user manual and the safety

instructions before installing the unit or using the unit!

1.1 Installation

★Condensation may occur if the UPS is moved directly from a

cold to a warm environment. The UPS must be absolutely dry

before being installed. Please allow an acclimatization time of

at least two hours.

★Do not install the UPS near water or in damp environment.

★Do not install the UPS where it would be exposed to direct

sunlight or near heat.

★Do not block ventilation openings in the UPS’s housing.

★Do not connect appliances or items of equipment which would

overload the UPS (e.g. laser printers, etc) to the UPS output.

★Place cables in such a way that no one can step on or trip over

them.

★UPS has provided earthed terminal, in the final installed

system configuration, equipotential earth bonding to the

external UPS battery cabinets.

★An integral single emergency switching device which prevents

further supply to the load by the UPS in any mode of operation

should be provided in the building wiring installation.

★An appropriate disconnect device as short-circuit backup

protection should be provided in the building wiring

installation.

★For three-phase equipment connection to an IT power system,

a four-pole device which disconnect all phase conductors and

the neutral conductor should be provided in the building wiring

installation.

★This is permanently connected equipment, it must be installed

by qualified maintenance personnel.

★Earth connection essential before connecting to the building

wiring terminal.

1.2 Operation

★Do not disconnect the earth conductor cable on the UPS or the

building wiring terminals in any time since this would cancel

the protective earthing of the UPS system and of all connected

loads.

★The UPS output terminal block may be electrically lived even if

the UPS system is not connected to the building wiring

terminal.

★In order to fully disconnect the UPS, turn the M1/M2/N input

breaker in the “OFF” position (for PowerWalker VFI

10000-20000 TP 3/1), turn the R/S/T/N input switch in the

“OFF” position (for PowerWalker VFI 10000TCP 3/1), then

disconnect the mains lead.

★Ensure that no liquid or other foreign objects can enter the

UPS.

1.3 Maintenance, servicing and faults

★The UPS operates with hazardous voltages. Repairs should be

carried out only by qualified maintenance personnel.

★Caution - risk of electric shock. Even after the unit is

disconnected from the mains power supply (building wiring

terminal), components inside the UPS are still connected to the

battery which are potentially dangerous.

★Before carrying out any kind of service and/or maintenance,

please disconnect the batteries. Verify that no current is

present and no hazardous voltage exists in the capacitor or

BUS capacitor terminals.

★Batteries must be replaced only by qualified personnel.

★Caution - risk of electric shock. The battery circuit is not

isolated from the input voltage. Hazardous voltages may occur

between the battery terminals and the ground. Verify that no

voltage is present before servicing!

★Batteries have a high short-circuit current and pose a risk of

shock. Take all precautionary measures specified below and

any other measures necessary when working with batteries:

－remove all jewellery, wristwatches, rings and other metal

objects

－use only tools with insulated grips and handles.

★When changing batteries, replace with the same quantity and

the same type of batteries.

★Do not attempt to dispose of batteries by burning them. It

could cause explosion.

★ Do not open or destroy batteries. Effluent electrolyte can cause

injury to the skin and eyes. It may be toxic.

★ Please replace the fuse only by a fuse of the same type and of

the same amperage in order to avoid fire hazards.

★Do not dismantle the UPS, except the qualified maintenance

personnel.

1.4 Transport

★ Please transport the UPS only in the original packaging (to

protect against shock and impact).

1.5 Storage

★ The UPS must be stockpiled in the room where it is ventilated

and dry.

1.6 Standards

* Safety

IEC/EN 62040-1

* EMI

Conducted Emission.................:IEC/EN 62040-2 Category C3

Radiated Emission...................:IEC/EN 62040-2 Category C3

*EMS

ESD........................................:IEC/EN 61000-4-2

Level 3

RS..........................................:IEC/EN 61000-4-3

Level 3

EFT.........................................:IEC/EN 61000-4-4

Level 4

SURGE....................................:IEC/EN 61000-4-5

Level 4

Low Frequency Signals.............:IEC/EN 61000-2-2

Warning: This is a product for commercial and industrial application

in the second environment-installation restrictions or additional

measures may be needed to prevent disturbances.

2. Description of Commonly Used Symbols

Some or all of the following symbols may be used in this manual. It is

advisable to familiarize yourself with them and understand their

meaning:

3. Introduction

3.1 System and model description

This Online Series is an uninterruptible power supply incorporating

double-conversion technology. It provides perfect protection

specifically for computer equipment, communication systems to

computerized instruments.

Its true online double-conversion design eliminates all mains power

disturbances. A rectifier converts the alternating current from the

utility power to direct current. This direct current powers the inverter.

On the basis of this DC voltage, the inverter generates a pure

sinusoidal AC voltage, which is constantly powering the loads.

Computers and Peripherals are thus powered entirely by the UPS. In

the event of power failure, the maintenance-free batteries power the

inverter.

This manual is applicable to the PowerWalker VFI 10000-20000 TP

3/1 models and PowerWalker VFI 10000TCP 3/1 model.

The tower 3-phase series UPS providing outstanding performance

and reliability, the UPS’s unique benefits include:

Online UPS design with pure sine wave output.

True online double-conversion technology with high power density,

utility frequency independence, and generator compatibility.

Overall high efficiency > 93%, saving the operating cost.

True three-phase power factor correction and high input power

factor (PF>0.99). Save the installation cost and reduce the

pollution back feed into upstream power system.
