Pride Mobility Apex Sprint Bedienungsanleitung

Apex Sprint

32 Wedgwood Road

Bicester, Oxon OX26 4UL

Apex Sprint

Apex Sprint Apex Sprint

Model Numbers 4-wheel: SC64

Available Colors Apex Sprint Blue/Orange

Overall Length24-wheel: 44.75 in. (114 cm)

Overall Width221.5 in. (55 cm)

Total Weight Including Battery Packs 4-wheel: 187 lbs. (85 kg)

Total Weight Without Battery Packs 4-wheel: 125 lbs. (57 kg)

Heaviest Piece When Disassembled 4-wheel: front section (51.5 lbs. / 23 kg)

Turning Radius24-wheel: 50 in. (127 cm)

Speed (maximum) 1 Variable up to 4.5 mph (7.24 km/h)

Range Per Charge1Up to 20 miles (32 km) with 35 Ah batteries

Ground Clearance22.25 in. (6 cm)

Weight Capacity 300 lbs. (136 kg) Maximum

Standard Seating Type: Foldable molded plastic

Material: Black PU

Dimensions: 17 in. width (43 cm)

17in. depth (43cm)

20 in. height (51 cm)

Drive System Rear-wheel drive, sealed transaxle, with 24 volt, DC motor

Dual Braking System Electronic, regenerative, and electromechanical

Wheels 4-wheel front: aluminum mags

4-wheel rear: aluminum mags

Tires Type: pnenmatic

Front: 2 in. x 8 in. (5 cm x 20 cm)

Rear: 3 in. x 9 in. (7.6 x 23 cm)

Battery Requirements Type: (2) 12-volt, deep cycle

Size: U1 (35 Ah)

Battery pack weight: 31 lbs. (14 kg) each

Battery Charger Off-board charger

Apex Sprint Apex Sprint

LlFETIME WARRANTY

Structural frame components, including: platform, fork, seat post and frame welds.

TWO-YEAR LlMITED WARRANTY

Drivetrain, including: transaxle, motor and brake.

ONE-YEAR LlMITED WARRANTY

All electrical parts, inc1uding control1ers and battery chargers, are covered for one year under warranty .

Anya attempt to open or dismantle these parts will lead to this warranty being void .

BATTERIES

Batteries are covered by a twelve-month warranty from the original manufacturer.

NOT COVERED UNDER WARRANTY

The following are classed as wear items, which may, under normal wear and tear, require replacing .

These items are not therefore covered under warranty: tyres, lap belts, bulbs, upholstery, plastic shrouds,

motor brushes and fuses. Warranty will also be refused if damage is deemed to have been caused through

misuse or accident for which Pride Mobility Products Ltd. cannot be deemed responsible .

NOTE: Pride Mobility Products Ltd. provides parts only under warranty. Your authorised

Pride Dealer is responsible for labour and service. Please contact your authorised Pride

Dealer for information about these services and for any applicable charges.

SERVICE CHECKS AND WARRANTY SERVICE

2- YEAR LIMITED WARRANTY

Structural frame components, including:

ONE-YEAR LIMITED WARRANTY

Electronic components, including: Main frame assemblies, including:

Other components, including:

Electrical harness

Warranty service must be performed by an authorized Pride Provider. Do not return faulty parts to Pride

without prior written authorization. All transportation costs and shipping damage incurred while

submitting parts for repair or replacement are the responsibility of the purchaser. Failure to follow the

instructions, warnings, and notes in the owner’s manual and those located on your Pride product can

result in personal injury or product damage and will void Pride’s product warranty. There is no other

express warranty.

Our goods come with guarantees that cannot be excluded under the Australian Consumer law. You are entitled

to a replacement or refund for a major failure and for compensation for any foreseeable loss or damage. You are

also entitled to have the goods repaired if the goods fail to be of acceptable quality and the failure does not

amount to a major failure.

For two (2) years from the date of purchase, Pride will repair or replace at our option to the original purchaser,

free of charge, any of the following parts found upon examination by an authorized representative of Pride to

be defective in material and/or workmanship:

Main frame Seat post

For one (1) year from the date of purchase, Pride will repair or replace at our option to the original purchaser,

free of charge, any of the following parts found upon examination by an authorized representative of Pride to

be defective in material and/or workmanship:

Charger assembly Anti- tip forks Caster forks

Controller Metal seat framing Accessories

Brakes (electronic function ONLY) Motor/gearbox assembly

Bearings and bushings Front rigging mounting brackets
