The Ultimate In Style & Performance

Owner’s Manual

Unit 106, Heyford Park Camp Road

Upper Heyford, Oxfordshire OX25 5HA

www.pridemobility.com

PrideMobilityProductsLtd.

INFMANU2713/RevD/November2005

SAFETY GUIDELINES

NOTE: This owner’s manual is compiled from the latest specifications and product information avail-

able at the time of publication. We reserve the right to make changes as they become necessary. Any

changes to our products may cause slight variations between the illustrations and explanations in this

manual and the product you have purchased.

Thesymbolsbelowareusedthroughoutthisowner'smanualandonthescootertoidentifywarningsandimportant

information.It isveryimportantfor youtoread themandunderstandthem completely.

WARNING! Indicates a potentially hazardous condition/situation that can cause personal

injury, equipment and/or property damage.

MANDATORY! These actions should be performed as specified. Failure to perform

mandatory actions can cause injury to personnel and/or damage to equipment.

PROHIBITED! These actions are prohibited; do not perform at any time or in any situation.

Performing a prohibited action can cause personal injury and/or equipment damage.

Pleasefilloutthefollowinginformationforquickreference:

Pride Dealer:______________________________________________________________________

Purchase Date:______________________________________________________________________

Address:___________________________________________________________________________

Phone Number:______________________________________________________________________

Serial Number:_______________________________________________________________________

Go-GoUltra www.pridemobility.com

CONTENTS

I. INTRODUCTION......................................................................................................................... 4

II. SAFETY ......................................................................................................................................... 5

III. SPECIFICATIONS ................................................................................................................... 16

IV. YOUR SCOOTER...................................................................................................................... 18

V. BATTERIES AND CHARGING ............................................................................................ 21

VI. OPERATION............................................................................................................................... 25

VII. COMFORT ADJUSTMENTS................................................................................................ 27

VIII.DISASSEMBLY AND ASSEMBLY ..................................................................................... 29

IX. BASIC TROUBLESHOOTING ............................................................................................. 32

X. CARE AND MAINTENANCE ................................................................................................ 34

XI. WARRANTY................................................................................................................................36

4www.pridemobility.com Go-GoUltra

I. INTRODUCTION

SAFETY

Welcome to Pride MobilityProducts Ltd. (Pride). The product you havepurchased combinesstate-of-the-art

componentswith safety,comfortandstylingin mind.Weare confident thedesignfeatures will provideyouwith

theconveniencesyouexpect during your daily activities. Understandinghowtosafelyoperate and careforthis

productshouldbring you years oftroublefreeoperationsandservice.

Readandfollowallinstructions,warningsandnotesin thismanualandall otheraccompanyingliterature before

attemptingtooperate this product for thefirst time.Inaddition,yoursafetydepends upon you, as wellasyour

dealer,careror healthcareprofessionalinusinggoodjudgement.

Ifthereis any information in thismanualwhichyoudonot understand or if yourequireadditionalassistancefor

setuporoperation, please contact your authorised PrideDealer.Failuretofollow the instructions,warnings

andnotesinthismanualandthoselocatedonyourPrideproductcanresultinpersonalinjuryorproduct

damageandwillvoidPride’sproductwarranty.

PURCHASER’S AGREEMENT

Byacceptingdeliveryofthisproduct,youpromisethatyouwillnotchange,alterormodifythisproductorremove

orrender inoperableorunsafeany guards,shieldsorother safetyfeaturesofthis product;fail,refuseorneglectto

installanyretrofit kits from time totimeprovidedbyPridetoenhance or preserve thesafeuseofthisproduct.

INFORMATION EXCHANGE

Wewanttohearyourquestions, comments and suggestionsaboutthismanual.We would also liketohearabout

thesafetyandreliabilityofyournewscooterandabouttheserviceyoureceivedfromyourauthorisedPrideDealer.

Pleasenotifyusof anychangeofaddress,sowecan keepyouapprisedofimportantinformationabout safety,new

productsandnewoptionsthatcan increase your ability to use and enjoy your scooter.Pleasefeelfreetocontact

usattheaddress below:

PrideMobility Products Ltd.

Unit106, Heyford Park Camp Road

UpperHeyford,OxfordshireOX255HA

NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact

us and we will be glad to send you a new one immediately.

Go-GoUltra www.pridemobility.com

PRODUCT SAFETY SYMBOLS

Thesymbolsbelow are used on thescootertoidentifywarnings,mandatory actions, and prohibitedactions.Itis

veryimportantfor youtoreadand understand themcompletely.

Pinch/Crush points created during assembly.

Corrosive chemicals are contained in batteries. Use only AGM or Gel-Cell batteries

to reduce the risk of leakage or explosive conditions.

Read and follow the information in the owner’s manual.

Maximum weight capacity.

Place unit on level ground and stand behind or to one side when changing from

drive mode to freewheel mode or freewheel mode to drive mode.

Locked and in drive mode.

Unlocked and in freewheel mode.

Do not use a cell phone, walkie/talkie, laptop, or other radio transmitter while

operating.

II. SAFETY

6www.pridemobility.com Go-GoUltra

EMI-RFI- This product has been tested and passed at an immunity level of 20 V/m.

Front-to-rear plug orientation.

Do not remove anti-tip wheels.

Avoid exposure to rain, snow, ice, salt, or standing water whenever possible.

Maintain and store in a clean and dry condition.

Removal of grounding prong can create electrical hazard. If necessary, properly

install an approved 3-pronged adapter to an electrical outlet having 2-pronged plug

access. Failure to heed could result in personal injury and/or property damage.

Prevent personal injury and equipment damage. Do not connect an extension lead

to the AC/DC converter or the battery charger.

II. SAFETY

Contact with tools can cause electrical shock.

Use only AGM or Gel-Cell batteries.

Go-GoUltra www.pridemobility.com

II. SAFETY

GENERAL

Yourscooterisa state-of-the-artlife-enhancementdevice designedtoincreasemobility.Prideprovidesan exten-

sivevarietyof products tobestfittheindividual needsofthescooteruser. Pleasebeawarethat the finalselection

andpurchasingdecision regarding the type of scooter tobe usedistheresponsibilityofthe scooter user who is

capableofmakingsuchadecision.

There are certain situations, including some medical conditions, where the scooter user will need to practice

operatingthescooterinthepresenceof atrainedattendant.Atrainedattendantcan bedefinedasafamilymember

orhealthcareprofessionalspeciallytrainedinassistingascooteruserinvariousdailylivingactivities.

Asyoubegin usingyourscooterduring daily activities,youwillprobably encountersituationsinwhichyou will

needsomepractice. Simply take your timeand youwillsoonbein full and confident controlas youmaneuver

throughdoorways,onandoffof lifts, up and down ramps, and over moderate terrain.

Belowaresomeprecautions,tips,andothersafetyconsiderationsthatwillhelpthe user become accustomed to

operatingthescooter safely.

MODIFICATIONS

Pridehas designedandengineeredyour scootertoprovidemaximum mobilityandutility.Awiderangeofacces-

soriesisavailablefromyourauthorisedPrideDealertofurthercustomise your scooter to better suit your needs

and/orpreferences.However, under no circumstances should you modify,add,remove, or disable any feature,

part,orfunctionofyourscooter.

WARNING! Do not modify your scooter in any way not authorised by Pride. Unauthorised

modifications may result in personal injury and/or damage to your scooter.

REMOVABLE PARTS

WARNING! Do not attempt to lift or move your scooter by any of its removable parts.

Personal injury and damage to the scooter may result.

WARNING! Do not operate your new scooter for the first time without completely reading

and understanding this owner’s manual.

8www.pridemobility.com Go-GoUltra

II. SAFETY

PRE-RIDE SAFETY CHECK

Gettoknowthefeelofyourscooteranditscapabilities.Priderecommendsthatyouperformasafetycheckbefore

eachusetomakesureyourscooteroperatessmoothlyand safely.

Performthefollowinginspections priortousingyourscooter:

!Checkfor propertyreinflation(ifequippedwithpneumatic tyres).

!Checkallelectricalconnections.Makesure they are tight and not corroded.

!Checkallharnessconnections.Makesuretheyaresecuredproperly.

!Check the brakes.

!Checkbatterycharge.

Ifyoudiscovera problem, contact your authorised PrideDealerforassistance.

TYRE INFLATION

Ifyour scooter is equipped with pneumatictyres,youshould check or have the airpressurecheckedregularly.

Properinflation pressureswillprolong thelifeof yourtyresand helpensurethe smoothoperationof yourscooter.

WARNING! It is critically important that 2-2.4 bar (30-35 psi) tyre pressure be maintained

in pneumatic tyres at all times. Do not underinflate or overinflate your tyres. Low pressure

may result in loss of control, and overinflated tyres may burst. Failure to maintain 2-2.4

bar (30-35 psi) tyre pressure in pneumatic tyres at all times may result in tyre and/or wheel

failure, causing serious personal injury and/or damage to your scooter.

WARNING! Inflate your scooter tyres from a regulated air source with an available pressure

gauge. Inflating your tyres from an unregulated air source could overinflate them, resulting

in a burst tyre and/or personal injury.

WEIGHT LIMITATIONS

Yourscooterisrated foramaximumweight capacity. Refertothespecifications tableforinformation.

WARNING! Exceeding the weight capacity voids your warranty and may result in personal

injury and damage to your scooter. Pride will not be held responsible for injuries and/or

property damage resulting from failure to observe weight limitations.

WARNING! Do not carry passengers on your scooter. Carrying passengers may result in

personal injury and/or property damage.

INCLINE INFORMATION

Moreand more buildings have rampswithspecifieddegrees of inclination, designed foreasyandsafe access.

Somerampsmay have turning switchbacks(180-degreeturns)thatrequireyou to have goodcorneringskillson

yourscooter.

!Proceedwithextremecautionasyouapproachthedowngrade of a ramp or other incline.

!Take wide swingswithyourscooter around any tight corners.Ifyoudo that, the scooter’s rear wheels will

followawidearc,notcut the corner short, and not bump into orgethunguponanyrailingcorners.

!Whendrivingdownaramp,keepthescooter’sspeedadjustmentsettotheslowestspeedsettingtoensurea

safelycontrolleddescent.

!Avoidsudden stops and starts.

Go-GoUltra www.pridemobility.com

II. SAFETY

Figure 1. Maximum Recommended Incline Angles

When climbing an incline, try to keep your scooter moving. If you must stop, start up again slowly, and then

acceleratecautiously.When drivingdownanincline, do so bysettingthespeed adjustment dial to theslowest

settinganddrivingintheforwarddirectiononly.Ifyourscooterstartsto move down the incline faster than you

anticipatedordesired, allow it to come toa completestop byreleasingthethrottlecontrollever.Then push the

throttlecontrol leverforwardslightlytoensureasafely controlleddescent.

WARNING! Any attempt to climb or descend a slope steeper than what is shown in figure 1 may

put your scooter in an unstable position and cause it to tip, resulting in personal injury.

WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the

incline. Drive your scooter straight up the incline. This greatly reduces the possibility of a

tip or a fall. Always exercise extreme caution when negotiating an incline.

WARNING! Do not drive your scooter across the side of an incline or diagonally up or down

an incline; do not stop, if possible, while driving up or down an incline.

WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas

covered with snow, ice, cut grass, or wet leaves).

WARNING! When on any sort of an incline or decline, never place the scooter in freewheel

mode while seated on it or standing next to it.

WARNING! Even though your scooter is capable of climbing slopes greater than those

illustrated in figure 1, do not, under any circumstances, exceed the incline guidelines or

any other specifications presented in this manual. Doing so could cause instability in your

scooter, resulting in personal injury and/or damage to your scooter.

Handicap public access ramps are not subject to government regulation in all countries, and therefore do not

necessarilyshare thesamestandarddegree ofslope.Otherinclinesmaybenatural or, ifman-made, notdesigned

specificallyforscooters. Figure1illustrates yourscooter’s stabilityanditsabilityto climb gradesundervarious

weightloadsandundercontrolledtestingconditions.

Thesetestswereconducted with the scooter’sseatinthe highest position and adjustedrearwardontheseatbase

toitsfarthest rearward position.Usethisinformationas a guideline.Yourscooter’s abilitytotravelupinclines is

affectedby your weight, your scooter’s speed, your angle of approach to the incline, and your scooter setup.

113 kg/

18 stone

(250 lbs.)

10.5%

91 kg/

14 stone

(200 lbs.)

12.3%

68 kg/

11 stone

(150 lbs.)

14.1%

10 www.pridemobility.com Go-GoUltra

II. SAFETY

Figure 2. Normal Driving Position

CORNERING INFORMATION

Excessivelyhigh cornering speeds can createthepossibility of tipping. Factors whichaffectthe possibility of

tippinginclude, butarenot limitedto,corneringspeed,steeringangle(howsharplyyouareturning),unevenroad

surfaces,inclinedroadsurfaces,ridingfromanareaoflowtractiontoanareaofhightraction(suchaspassingfrom

a grassy area to a paved area – especially at high speed while turning), and abrupt directional changes. High

cornering speeds are not recommended. If you feel that you may tip over in a corner, reduce your speed and

steeringangle(i.e., lessen thesharpnessoftheturn) topreventyourscooterfrom tipping.

WARNING!

When cornering sharply, reduce your speed. When using your scooter at higher

speeds, do not corner sharply. This greatly reduces the possibility of a tip or fall. To avoid

personal injury or property damage, always exercise common sense when cornering.

Whenyou approachanincline, itisbesttoleanforward.Seefigures2and2A.Thisshiftsthecentreof gravityof

youandyourscootertoward the front of the scooter for improvedstability.

NOTE: When negotiating ramps, if the throttle control lever is released while moving forward, the

poweredscooter may"rollback"approximately 30.5cm (1 foot)before thebrakeengages. If thethrottle

control lever is released while moving in reverse, the powered scooter may "rollback" approximately

one meter (3 feet) before the brake engages.

BRAKING INFORMATION

Yourscooter isequippedwiththesepowerful brake systems:

!Regenerative:Uses electricitytorapidlyslow thevehiclewhenthe throttlecontrolleverreturnstothecentre/

stopposition.

!DiscParkBrake:Activates mechanically after regenerative braking slows the vehicle to near stop, or when

powerisremovedfrom the system for any reason.

Figure 2A. Increased Stability Driving Position

Inhaltsverzeichnis

Andere Pride Roller Handbücher

Pride

Pride Hurricane PMV Bedienungsanleitung

Pride

Pride Hurricane Bedienungsanleitung

Pride

Pride BAJA MOBILITY WRANGLER Bedienungsanleitung

Pride

Pride Rally shopper Bedienungsanleitung

Pride

Pride Victory Viper Bedienungsanleitung

Pride

Pride BAJA BANDIT Bedienungsanleitung

Pride

Pride Rally Bedienungsanleitung

Pride

Pride Pursuit Bedienungsanleitung

Pride

Pride CELEBRITY XL Bedienungsanleitung

Pride

Pride Hurricane Bedienungsanleitung

Pride

Pride CELEBRITY XL Bedienungsanleitung

Pride

Pride Icon Bedienungsanleitung

Pride

Pride Sundancer Bedienungsanleitung

Pride

Pride Go-Go ES8 Bedienungsanleitung

Pride

Pride Celebrity DX Sport Bedienungsanleitung

Pride

Pride Ultimate 3 CF3001 Bedienungsanleitung

Pride

Pride Sundancer Bedienungsanleitung

Pride

Pride Cyclone Bedienungsanleitung

Pride

Pride Victory XL Bedienungsanleitung

Pride

Pride DESTINY Bedienungsanleitung

Pride

Pride Go-Chair Bedienungsanleitung

Pride

Pride JAZZY Bedienungsanleitung

Pride

Pride Victory XL-4 Bedienungsanleitung

Pride

Pride Victory 10 Bedienungsanleitung

Beliebte Roller Handbücher anderer Marken

TEKTRO

TEKTRO CHEETAH Bedienungsanleitung

Douglas

Douglas Vespa Sprint Installationsanleitung

PLAYTIVE

PLAYTIVE AS-2448 Bedienungsanleitung

Ebinger

Ebinger DONKEY XL Bedienungsanleitung

Flyer

Flyer Mountain Benutzerhandbuch

BackCountry eBikes

BackCountry eBikes Storm Bedienungsanleitung

equipmed

equipmed FreeRoam II Bedienungsanleitung

Yoto

Yoto Lion Bedienungsanleitung

WESTHILL BIKES

WESTHILL BIKES LINK Bedienungsanleitung

BAnff

BAnff eProdigy series Bedienungsanleitung

Winther

Winther 475 Bedienungsanleitung

Jetson

Jetson JBZL17 Bedienungsanleitung

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Bedienungsanleitung

Carrera

Carrera impel Bedienungsanleitung

Afikim

Afikim Superlight SL-3 Bedienungsanleitung

CareCo

CareCo ZOOM Bedienungsanleitung

Douglas

Douglas Vespa G.S. Bedienungsanleitung

Gazelle

Gazelle with BOSCH System Bedienungsanleitung

Pride go-go ultra Bedienungsanleitung

Beliebte Roller Handbücher anderer Marken
