Q-See QT17DVR4C Bedienungsanleitung

QSDR174RTC

User’s Manual

Digital Peripheral Solutions, Inc.

8015 E. Crystal Drive

Anaheim, CA 92807

Website:

http://www.Q-See.com

Customer Service:

Phone: 877-998-3440 x 538

Email:cs@dpsi-usa.com

Tech Support:

Phone: 877-998-3440 x 539

Email:ts@dpsi-usa.com

Fax:

714-998-3509

Revised 11/6/2009

QSDR174RTC User Manual

CONTENTS

Chapter 1: DVR Features....................................................................................................................2

Chapter 2: Layout ...............................................................................................................................3

2.1: Front Panel...................................................................................................................................................................3

2.2: Rear Panel ...................................................................................................................................................................4

2.2.2: Remote Control .....................................................................................................................................................5

2.2.3 Mouse Operation....................................................................................................................................................5

Chapter 3: DVR Installation................................................................................................................6

3.1: Hard Drive Installation..................................................................................................................................................6

3.2: Connecting Your DVR to Cameras and a Monitor .......................................................................................................6

3.3: Connecting the Power Supply......................................................................................................................................6

Chapter 4: DVR Boot up.....................................................................................................................7

4.1: System Initialization .....................................................................................................................................................7

4.2: Main Interface...............................................................................................................................................................7

4.3: Pop-Up Menu...............................................................................................................................................................7

Chapter 5: DVR Menu .........................................................................................................................8

5.1: Main Menu At-a-Glance ...............................................................................................................................................8

5.2: Main Menu....................................................................................................................................................................9

5.2.1: Camera Setup .......................................................................................................................................................9

5.2.2: Record Setup.......................................................................................................................................................10

5.2.3: Network Setup..................................................................................................................................................... 11

5.2.3.1: DHCP............................................................................................................................................................ 11

5.2.3.2: PPPoE .......................................................................................................................................................... 11

5.2.3.3: STATIC..........................................................................................................................................................12

5.2.3.4: Port Forwarding............................................................................................................................................13

5.2.3.5: Pop-Ups & ActiveX Controls.........................................................................................................................14

5.2.4: Recording Search................................................................................................................................................15

5.2.5: Backup Recorded Files .......................................................................................................................................16

QSDR174RTC User Manual

5.2.6: Multi Player..........................................................................................................................................................17

5.2.7: Device Management............................................................................................................................................19

5.2.7.1: HDD Management........................................................................................................................................19

5.2.7.2: Alarm Set......................................................................................................................................................20

5.2.7.3: PTZ Setup.....................................................................................................................................................21

5.2.7.4: Mobile Setup.................................................................................................................................................22

5.2.7.5: Mobile Phone Access ...................................................................................................................................22

5.2.7.6: Motion Detect................................................................................................................................................27

5.2.8: System Function..................................................................................................................................................27

5.2.8.1: Time Set........................................................................................................................................................27

5.2.8.2: Password......................................................................................................................................................28

5.2.8.3: Video Setup ..................................................................................................................................................28

5.2.8.4: Language......................................................................................................................................................28

5.2.8.5: Info................................................................................................................................................................28

5.2.8.6: System Maintenance....................................................................................................................................28

5.3: Menu Lock..................................................................................................................................................................29

5.4: Video Search..............................................................................................................................................................29

5.5: PTZ Control................................................................................................................................................................29

5.6: Record........................................................................................................................................................................30

5.7: Stop Recording...........................................................................................................................................................30

Chapter 6: Net-Viewer Program.......................................................................................................31

6.1: Enable Plug-Ins and Log-In to Net-Viewer.................................................................................................................31

6.2: Main Interface of Net-Viewer......................................................................................................................................31

6.2.1: Menu....................................................................................................................................................................32

6.2.1.1: Live ...............................................................................................................................................................32

6.2.1.2: Replay...........................................................................................................................................................32

6.2.1.3: Setup ............................................................................................................................................................32

6.2.1.4: Logging Out of Net-Viewer ...........................................................................................................................34

6.2.2: PTZ and Live Play Controls.................................................................................................................................34

Chapter 7: Specifications.................................................................................................................35

Chapter 8: Appendix.........................................................................................................................36

QSDR174RTC User Manual

8.1: Operation Function Table...........................................................................................................................................36

8.2: Setting up Alarm Record Mode ..................................................................................................................................37

8.3: Troubleshooting..........................................................................................................................................................38

8.4: System Connections ..................................................................................................................................................39

8.5: Accessories Included .................................................................................................................................................40

Q-See Product Warranty...................................................................................................................41

Customer Information Card .............................................................................................................42

QSDR174RTC User Manual

Safety Instructions

1. Use proper power source.

Do not use this product with a power source that applies more than specified voltage (100-240V AC).

2. Never insert anything metallic into the DVR case.

Putting something into the DVR case can be a source of dangerous electric shock.

3. Do not operate in wet & dusty area or use near water.

Avoid places like a damp basement or dusty hallway.

4. Do not expose this product to rain or use near water.

If this product accidentally gets wet, unplug it and contact an authorized dealer immediately.

5. Keep product surfaces clean and dry.

To clean the outside case of the DVR, use a cloth lightly dampened with water (no solvents).

6. Provide proper ventilation.

This DVR has a built in fan that properly ventilates the system.

7. If there are any unusual sounds or smells coming from the DVR, unplug it immediately and contact

Q-See.

Warning: You may be subjected to severe electrical shock if you remove the cover of the DVR.

8. Handle DVR box carefully.

If you accidentally drop your DVR on any hard surface, it may cause a malfunction. If the DVR doesn’t work

properly due to physical damage, contact an authorized dealer for repair or exchange.

9. Use standard lithium cell battery (preinstalled).

The standard lithium cell 3v battery located on the mother board should be replaced if the time clock resets during

a power outage. Warning! Unplug the DVR before replacing battery or you may be subjected to severe electrical

shock. Properly dispose of old batteries.

10. Make sure there is good air circulation around the unit.

This DVR system uses a hard drive for video storage which generates heat during operation. Do not block air

holes (bottom, upper, sides and back) of the DVR as they are designed to cool down the system while running.

Install or place this product in an area where there is good air circulation.

QSDR174RTC User Manual

Chapter 1: DVR Features

Function Brief Description

Real-Time

Monitoring Supports Real-Time Surveillance via Monitor

Save Files DVR Saves Real-Time Recording of Image Files to HDD

Backup Files Supports DVR Backup of Recorded Image Files via USB Flash Drive and Hard Drive

Playback Files

Supports DVR single CH and Multiple CH Playback of Recorded Files

Network

Operation Supports Remote Surveillance by Multiple Users Simultaneously

Alarm Setting Supports HDD & video input alarm management and external alarm signal inputs.

Mouse

Operation Supports Mouse Operation for Faster Menu Navigation.

PTZ Control Supports PTZ camera operations through RS-485.

Other Features:

•H.264 Video Compression Format; Supports CIF, D1 and HD1 Resolution

•ADPCM Audio Compression Format

•Windows Graphics Interface

•Menu Status Notification

•Multiple Operation (Preview, Recording, Backup, Network Surveillance and Mobile Phone Monitoring Simultaneously)

•Supports Double Encoded Bit Network Transmission

•Supports Remote Live Viewing Via 3G Mobile Networks

•Supports Zoom In/OutAnd Dwell Time Display

•Adjustable Video Package Time

•Multiple Alarm Record Mode

•Rear USB 2.0 Ports For Back-Up, Upgrade and Mouse Operation

•IR Remote Control Operation

•Multiple Language OSD (On Screen Display)

•Supports Auto Maintenance

QSDR174RTC User Manual

Chapter 2: Layout

2.1: Front Panel

Device

Item

Number

Button

Name/Symbol

Function

LCD

1 ON/OFF On: The LCD screen is displayed in a basic activation status;

Off: The LCD screen enters into sleep mode.

2 MENU Press once to display LCD main menu. Press again to exit LCD main menu.

3 + Increase and confirm setting value

4 - Decrease and confirm setting value

DVR

5 MENU Press once to display DVR main menu. Press again to exit DVR main menu.



When pressed while the Main Menu is not displayed, the down

arrow button allows you

to scroll th

rough the video feeds transmitted from each camera hooked up to your

system.

When pressed while the Main Menu is displayed, the down arrow button allows you to

navigate the Main Menu Interface and select the icon of the program you wish to access.



When pressed while the Main Menu is not displayed, the right arrow button allows you to

scroll through the video feeds transmitted from each camera hooked up to your system.

When pressed while the Main Menu is displayed, the right arrow button will

allow you to

navigate the Main Menu Interface and select the icon of the program you wish to access.

8 ENTER When pressed while the Main Menu is displayed, the ENTER

button will allow you to

enter into the sub-menu of the program you wish to access.

QSDR174RTC User Manual

2.2: Rear Panel

Item Number Name/Symbol Description Function

1 VIDEO INPUT

1-4 Video Input Ch1-4 (BNC Interface) Connection

2 AN1, AN2,

AN3, AN4 Audio Input CH1-4 Audio Signal Input (RCA Interface) Connection

3 AUDIO

OUTPUT Audio Output Audio Signal Output (RCA Interface) Connection

4 USB Port USB Device (Flash Drive, Hard Drive) Connection

5 DC12V

Power Port Power Supply - DC12V 3A

6 USB Port USB Mouse Connection

7 LAN Ethernet Port Intranet and Internet Connection (RJ-45 Interface)

8 RS485Alarm

Port RS485 Interface

9 Alarm Sensor

Port Alarm Sensor Interface

Alarm Port Alarm Interface

11 Power Switch Power On and Off

12 VIDEO

OUTPUT Video Output

Connection Video Out Connection

 O

QSDR174RTC User Manual

2.2.2: Remote Control

1 1-8 Channel Select 1-8 ; Numeric key

2 9,0 Numeric Key

3 ALL Preview all Channels

4 MENU Enter/Exit Main Menu

5 ▲Up Key

6 ▼Down Key

◄/►

Left / Right Key

8 SEL Select Key/ Edit Key

9 

Rewind

►

Play Recorded Events

11 

Forward Key

●

Manual Recording



Pause / Frame Play

■

Manually Stop Recording or Playback

15 AUDIO PlayAudio from Selected Camera

16 MUTE Mute Audio

2.2.3 Mouse Operation

For your convenience, your Q-See DVR System can also be operated by a mouse in addition to the front panel

controls and remote control.

Action Function

Left Click

With your DVR in Menu Unlock mode, left clicking on your mouse opens a pop-up dialog menu

that allows you to access your programming and configuration settings. Some of the options

available by left clicking include :

•Edit your record settings.

•Playback recorded files.

•Access a pull-down menu.

•Control color and volume settings.

•Choose your system’s language settings.

•Double clicking the left key of your mouse maximizes the screen view.

Right Click

With your DVR in Live Display mode, right clicking will display a pop-up menu (See Picture 3)

which allows you to:

•Exit system programming and configuration mode.

•Close all configuration menu dialog boxes.

Sliding Mouse

•

In Motion set mode, sliding the mouse will select the area of motion you wish to choose.

•In Color Set mode, sliding the mouse allows you to access and adjust the color control

bar and the volume control bar.

QSDR174RTC User Manual

Chapter 3: DVR Installation

3.1: Hard Drive Installation

Caution：NEVER Install or remove the hard drive while the DVR is running!

The model has a Hard Disk Drive (HDD) drawer. Please use key provided to open the drawer and insert the HDD

as follows:

(1) Remove screws and open DVR upper cover carefully;

(2) Insert Power Cord and data cable securely into matching ports on hard drive;

(3) Put the upper cover back carefully, re-attach screws.

3.2: Connecting Your DVR to Cameras and a Monitor

Connect camera cable to the Video Input port of the DVR. Connect the monitor to the Video Output port of the DVR

using a BNC connector (See Rear Panel Section 2.2).

To connect a PTZ speed dome to your DVR System, connect your PTZ Camera data cables to your RS485 A & B

ports. See Chapter 5 for a more detailed account of PTZ Camera configuration instructions.

3.3: Connecting the Power Supply

Only use the power adapter supplied with your DVR System.Failure to do so may result in unforeseen system

failures.

Andere Handbücher für QT17DVR4C

Inhaltsverzeichnis

Andere Q-See DVR Handbücher

Q-See

Q-See QT SERIES Bedienungsanleitung

Q-See

Q-See QSTD501616C Bedienungsanleitung

Q-See

Q-See QT SERIES Bedienungsanleitung

Q-See

Q-See QSDR74RTS Bedienungsanleitung

Q-See

Q-See QS434 Bedienungsanleitung

Q-See

Q-See QSD2308C8-250 Bedienungsanleitung

Q-See

Q-See QSD2216C16-250 Bedienungsanleitung

Q-See

Q-See QT SERIES Bedienungsanleitung

Q-See

Q-See QR4074 Bedienungsanleitung

Q-See

Q-See QT454-403-5 Bedienungsanleitung

Q-See

Q-See H.264 NETWORK DVR Bedienungsanleitung

Q-See

Q-See QC3016-12E4-1 Bedienungsanleitung

Q-See

Q-See QSDF8204C4 Bedienungsanleitung

Q-See

Q-See QT SERIES Bedienungsanleitung

Q-See

Q-See QS434 Bedienungsanleitung

Q-See

Q-See QS494 Bedienungsanleitung

Q-See

Q-See QSNDVR8/16R and Bedienungsanleitung

Q-See

Q-See Prosumer QT528 Bedienungsanleitung

Q-See

Q-See QSDR44KRTC-320 Bedienungsanleitung

Q-See

Q-See QSC26404 QH32DVR4C Bedienungsanleitung

Q-See

Q-See Q4DVR4CM Bedienungsanleitung

Q-See

Q-See QC-SERIES Bedienungsanleitung

Q-See

Q-See QSDR04RTC Bedienungsanleitung

Q-See

Q-See QSNDVR16M Bedienungsanleitung

Beliebte DVR Handbücher anderer Marken

FLIR

FLIR M3100E Series Bedienungsanleitung

VTRACKPRO

VTRACKPRO FPRO300 Bedienungsanleitung

Swann

Swann NVR-7085 models Bedienungsanleitung

XtendLan

XtendLan DVR-1670C Bedienungsanleitung

urmet domus

urmet domus 1093/004AHD Bedienungsanleitung

Holux

Holux M1 Bedienungsanleitung

CMOS DOTCOM

CMOS DOTCOM ANX-1670 Bedienungsanleitung

Whistler

Whistler D16VRS Bedienungsanleitung

Defender Security

Defender Security 82-20235 Bedienungsanleitung

MISUMI

MISUMI MP-WF100M Bedienungsanleitung

Speco

Speco D8HU Bedienungsanleitung

UST

UST DDR-E04AA Gebrauchsanweisung

Consolidated

Consolidated Digital Video Recorder Bedienungsanleitung

Mace

Mace DVR0404RW Kurzanleitung

RCA

RCA RTD315W Bedienungsanleitung

FSM

FSM Colibri Grande PRO Bedienungsanleitung

Hauppauge

Hauppauge HD PVR 2 Bedienungsanleitung

Identivision

Identivision ICR-PH161i PIONEER Bedienungsanleitung
