ROSE DISPLAYS ANOGRIP WITH CABLE CLIPS Bedienungsanleitung

Parts

Instruction Sheet

AnoGrip™

Step 1

Place cable onto inner channel of Cable Clip. The

cable should snap into place. Fig. 1

Step 2

Align one end of the Cable Clip with the top

channel of the AnoGrip. Insert one round end, then

press down on the other round end and slide Cable

Clip into rail. Repeat for multiple Cable Clips.

Fig. 2 & 3

Note: If using one cable, place the Clip in the center of

the holder. For two cables, place each Clip 1/3 of the

way in from each end of the holder.

Step 3

Hold the anchor so that the Cable Clips are on top,

and insert graphic into slot. Slide graphic back and

forth lightly to make sure it is all the way in the

anchor. Fig. 4

Step 4

Suspend poster.

Instructions to remove graphic

Step 5

Slide graphic out side of anchor. Fig.5

Important note:

Please save and reuse the AnoGrip, Cable Clips, and

Cable for future projects.

Instructions for Hanging

Incept- 02.02.05

AnoGrip™is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products.

Part #04INSAnoGripSS 35 Congress Street, Salem, MA 01970

Tel# 1- 800 631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

Figure 2

Figure 3 Figure 4

Figure 5

Cable Clip

06-5050

AnoGrip

12AW200

Figure 1

Cable and Saucer

16-0018SS

Parts

Instruction Sheet

AnoGrip™

Step 1

Place cable onto inner channel of Cable Clip. The

cable should snap into place. Fig. 1

Step 2

Align one end of the Cable Clip with the top

channel of the AnoGrip. Insert one round end, then

press down on the other round end and slide Cable

Clip into rail. Repeat for multiple Cable Clips.

Fig. 2 & 3

Note: If using one cable, place the Clip in the center of

the holder. For two cables, place each Clip 1/3 of the

way in from each end of the holder.

Step 3

Hold the anchor so that the Cable Clips are on top,

and insert graphic into slot. Slide graphic back and

forth lightly to make sure it is all the way in the

anchor. Fig. 4

Step 4

Suspend poster.

Instructions to remove graphic

Step 5

Slide graphic out side of anchor. Fig.5

Important note:

Please save and reuse the AnoGrip, Cable Clips, and

Cable for future projects.

Instructions for Hanging

Incept- 02.02.05

AnoGrip™is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss or

damage resulting from the use of these products.

Part #04INSAnoGripSS

Figure 2

Figure 3 Figure 4

Figure 5

Cable Clip

06-5050

AnoGrip

12AW200

Figure 1

Cable and Saucer

16-0018SS
