Manual STP1 pumps

thermostat

Operating principle

The thermostat is designed to control water

circulation pump C.O. The task of the thermostat

is switching on the pump if the temperature

exceeds required value, and disable it when the

boiler cools down (due to extinction).Prevents

unnecessary operation of the pump, which saves

electric energy (savings, depending on the degree

of utilization of the boiler, reaching up to 60%) and

extend pump life. This increases the reliability

and decrease costs associated with the operation.

The temperature pump start is controlled

potentiometer (range 10˚C-90˚C). The pump stops

when the actual temperature drops by 5˚C below

the temperature set point (potentiometer set).

Start and stop the pump after about 30 seconds.

Prevents the constant switching of the pump in

case of rapid changes temperature.

The thermostat has two switches. The first one is

used to switching on the thermostat (this is

indicated by the glowing red LED’s). The second is

used for manual pump operation (indicated by

green). Green LED indicates the operation of the

pump with automatic control of pump. The

regulator has a protection in the form of reusable

polymer fuse (inside the housing of the plate).

Connecting the pump C.O.

1. To terminal wire yellow - green

2. To terminal Nwire blue

3. To terminal Lwire brown

WIRING DIAGRAM

1. Potentiometer

2. Temperature sensor

3. Manually switch the pump mode

4. The power switch

5. Power cord

6. Pump power cord

7. LED for operation of the pump

8. LED indicating power on.

DANGER: Do not Touch electrical Components or

circuits. Isolate mains electricity supply before

starting any work and observe all relevant safety

precautions. Installation should be made by a

person with adequate electrical power!

TECHNICAL DATA

Temperature range

10°C - 90°C

Hysteresis

5°C

Supply voltage

230/50Hz +/-10%

Power

<2W

Temperature operating

-10°C-50°C

Section of connecting

cables

3x0,75mm

Sensor cable length

1,2m\

Output load current

180W

Dimensions

(72x50x132)

Warranty

Salus Controls warrants that this product will be

free from Any defekt In materials or workmanship,

and shall perform in accordance with its

specification, for a period of two years from the

date of installation. Salus Controls sole liability for

breach of this warranty will be (at its option) to

repair or replace the defective product.

Customer Name:…………………………………………………………..

Customer Address:………………………………………………………..

Post Code:…………………………………………………………………

Tel No:………………………………………………………………………..

Email:……………………………………………………………………….

Engineers Company:………………………………………………….

Tel No:……………………………………………………………………..

Email:……………………………………………………………………….

Installation Date:…………………………………………………..

Engineers Name:…………………………………………………..

Engineers Signature:……………………………………………..

SALUS Controls plc

Dodworth Business Park South,

Whinby Road, Dodworth, Barnsley,

S75 3SP UK
