Siemens Wireless Room Sensor Solution Bedienungsanleitung

Wireless Room Sensor Solution

User Guide

Table of Contents

About This User Guide ............................................................................................ 5

Chapter 1–Quick Start ............................................................................................ 7

Chapter 2–About the Wireless Room Sensor Solution ...................................................... 8

Why Use Wireless Room Temperature Sensor Communications? ................................... 8

Hardware Components .................................................................................... 8

Room Sensor Transceiver (RSX) .................................................................... 9

Wireless Room Sensor (WRS)..................................................................... 10

Revision History .......................................................................................... 13

Security.................................................................................................... 13

Chapter 3–Preparing for Wireless Communications....................................................... 14

WRS Limits................................................................................................ 14

RSX Location ............................................................................................. 14

RSX Antenna Mounting.................................................................................. 15

WRS Location............................................................................................. 16

Site Survey Guidelines................................................................................... 16

Chapter 4–Setting Up the WRS/RSX Pair..................................................................... 17

Before You Begin......................................................................................... 17

Binding the WRS/RSX Pair.............................................................................. 17

Binding Using WRS HMI Commands.............................................................. 18

Binding Using Auto-Binding Cable................................................................. 18

Conﬁguring WRS/RSX Parameters .................................................................... 19

Verifying WRS/RSX Communications.................................................................. 22

WRS Points ............................................................................................... 23

Point Commands .................................................................................... 24

Command Priority.................................................................................... 24

Revision Date: July 10, 2008 (563-068) 1

Siemens Building Technologies, Inc.

APOGEE Wireless User Guide

Point Status .......................................................................................... 25

Diagnostic Points (Communication Status and Battery Voltage) ............................... 25

Chapter 5–Modifying the WRS/RSX Pair ..................................................................... 26

Replacing WRS Battery.................................................................................. 26

Enabling/Disabling Automatic Channel Changing .................................................... 27

Replacing an Existing WRS ............................................................................. 28

Replacing an Existing RSX ............................................................................. 28

Viewing WRS and RSX Default Values ................................................................ 29

Restoring WRS and RSX Default Values .............................................................. 30

Appendix A–Troubleshooting (Advanced Users) ........................................................... 31

Verifying RSX/TEC Communications................................................................... 31

Viewing WRS/RSX Communication Quality ........................................................... 31

Viewing WRS/RSX Reporting and Status Values..................................................... 34

Pinging an RSX (PING).................................................................................. 34

Viewing Diagnostics (DIAG)............................................................................. 35

Testing Wireless Communication Quality (TEST) .................................................... 36

Viewing All Data (INFO) ................................................................................. 37

Clearing Diagnostic Counts (CLEAR) .................................................................. 38

Checking RF Energy Levels (ENERGY)............................................................... 38

Appendix B–Powering RSX Using 9 Vdc Battery........................................................... 39

Appendix C–Wireless TEC Commissioning and Balancing............................................... 40

Appendix D– Wireless Channels............................................................................... 40

Overview .................................................................................................. 40

Automatic Channel Changing .......................................................................... 41

2Revision Date: July 10, 2008

Siemens Building Technologies, Inc.

Wireless Room Sensor Solution

Rev. AA, July 10, 2008

NOTICE

The information contained in this document is subject to change without notice and should not be construed

as a commitment by Siemens Building Technologies, Inc. Siemens Building Technologies, Inc. assumes no

responsibility for any errors that may appear in this document.

All software described in this document is furnished under a license and may be used or copied only in accordance

with the terms of such license.

FCC NOTES

This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. The device may not cause harmful interference.

2. The device must accept any interference received, including interference that may cause undesired operation.

Changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s

authority to operate the equipment.

To comply with FCC’s RF exposure limits for general population/uncontrolled exposure, the antenna(s) used for

this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not

be co-located or operating in conjunction with any other antenna or transmitter.

FCC Interference Statement (Part 15.105 (b))

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Industrie Canada Certiﬁcation:

This device has been designed to operate with an antenna having a maximum gain of 5dBi. An antenna having a

higher gain is strictly prohibited per regulations of Industry Canada. The required antenna impedance is 50Ω.

Revision Date: July 10, 2008 3

Siemens Building Technologies, Inc.

APOGEE Wireless User Guide

To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the

equivalent isotropically radiated power (EIRP) is not more than that required for successful communication.

This equipment is to be installed or replaced by professional installation personnel only.

NCC Interference Statement (Taiwan)

經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設

計之特性及功能。低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停

用，並改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機

須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。

According to "Administrative Regulations on Low Power Radio Waves Radiated Devices" without permission

granted by the NCC, any company, enterprise, or user is not allowed to change frequency, enhance transmitting

power or alter original characteristic as well as performance to approved, low power radio-frequency devices. The

low power radio-frequency devices shall not inﬂuence aircraft security and interfere legal communications; if found,

the user shall cease operating immediately until no interference is achieved. The said legal communications means

radio communications is operated in compliance with the Telecommunications Act. The low power radio-frequency

devices must be susceptible with the interference from legal communications or ISM radio wave radiated devices.

SERVICE STATEMENT

Control devices are combined to make a system. Each control device is mechanical in nature, and all mechanical

components must be regularly serviced to optimize their operation. Siemens Building Technologies, Inc. branch

ofﬁces and authorized distributors offer Technical Support Programs that will ensure continuous, trouble-free

system performance.

TO THE READER

Your feedback is important to us. If you have comments about this manual, please submit them to:

SBT_technical.editor.us.sbt@siemens.com.

CREDITS

BACnet is a registered trademark of the American Society of Heating, Refrigeration and Air-Conditioning

Engineers, Inc.

Product or company names mentioned herein may be the trademarks of their respective owners.

For further information, contact your nearest Siemens Building Technologies, Inc. representative.

4Revision Date: July 10, 2008

Siemens Building Technologies, Inc.

Wireless Room Sensor Solution

About This User Guide

This user guide is written for System Specialists, Service Specialists, Technical Engineers, and District

Automation Specialists who want to plan, design, and maintain the Wireless Room Sensor Solution.

How This Guide Is Organized

This user guide is organized as follows:

•Chapter 1–Quick Start provides quick start steps for getting the Wireless Room Sensor Solution

operating.

•Chapter 2–About the Wireless Room Sensor Solution provides information about the Wireless

Room Sensor Solution.

•Chapter 3–Preparing for Wireless Communications provides recommendations and guidelines for

designing the Wireless Room Sensor Solution.

•Chapter 4–Setting Up the WRS/RSX Pair provides details for starting up and conﬁguring the

Wireless Room Sensor Solution.

•Chapter 5–Modifying the WRS/RSX Pair provides procedures for modifying setup and operation of

the Wireless Room Sensor Solution.

•Appendix A–Troubleshooting (Advanced Users) provides helpful procedures for troubleshooting

the Wireless Room Sensor Solution.

•Appendix B–Powering RSX Using 9 Vdc Battery provides details on using a 9 Vdc battery to power

theRSXwhenperformingsitesurveys.

•Appendix C–Wireless TEC Commissioning and Balancing provides information on using the

wireless WRS/RSX communications link to conﬁgure the TEC device using a tool.

•Appendix D– Wireless Channels provides details on how channels are selected on the wireless link

and how the automatic channel changing feature works for the Wireless Room Sensor Solution.

Document Conventions

The following table lists conventions to help you use this user guide in a quick and efﬁcient manner.

Convention Example

Numbered Lists (1,2,3…) indicate a procedure with

sequential steps. 1. Turn OFF power to the ﬁeld panel.

2. Start the device.

The arrow symbol signiﬁes a one-step procedure.

Click Start.

Revision Date: July 10, 2008 5

Siemens Building Technologies, Inc.

APOGEE Wireless User Guide

Convention Example

Actions that you should perform are speciﬁed in boldface

font.

Type Ffor ﬁeld panel.

Error and system messages are displayed in Courier

New font.

The message Report Definition successfully

renamed appears in the status bar.

Brackets and italics [ ] indicate text that can vary based

on your selection.

In the Computer name ﬁeld of the Identiﬁcation tab, type

[your computer name].

Symbols

The following table shows symbols that may be used in this document to draw your attention to important

information.

Notation Symbol Meaning

WARNING: Indicates that personal injury or loss of life

may occur to the user if a procedure is not

performed as speciﬁed.

CAUTION: Indicates that equipment damage or loss of

data may occur if the user does not follow

a procedure as speciﬁed.

Note Provides additional information or helpful

hints that need to be brought to the reader’s

attention.

Tip Suggests alternative methods or shortcuts

that may not be obvious, but can help the

user better understand the capabilities of

the product.

Getting Help

For further information about Wireless Room Sensor Solution, contact the Wireless Solutions team

in Buffalo Grove.

6Revision Date: July 10, 2008

Siemens Building Technologies, Inc.

Wireless Room Sensor Solution

Chapter 1–Quick Start

To quickly get your Wireless Room Sensor Solution up and running, follow these steps:

1. Install and power up Room Sensor Transceiver (RSX) device. To do this, see Room Sensor Transceiver

Installation Instructions.

2. Install and power up Wireless Room Sensor (WRS) device. To do this, see Wireless Room Sensor

Installation Instructions.

3. At the TEC, verify that the ROOM TEMP, RM STPT DIAL, and DI OVRD SW points are not overridden

(such as by WCIS, Database Mate, the ﬁeld panel, workstation software, etc.). If points are overridden,

then release the points so the RSX can update them with WRS values.

4. If your RSX and WRS devices are not bound (normally performed during WRS installation), bind the

WRS device with the RSX device. To do this, see Binding the WRS/RSX Pair.

5. (Optional) If using Sensing Only or Sensing with Display WRS model, set RM STPT DIAL point (point

4) to desired value (see second note under Command Priority for details).

6. If desired, change RSX and WRS conﬁguration settings. To do this, see Conﬁguring WRS/RSX

Parameters.

7. Verify WRS communications with the RSX device. To do this, see Verifying WRS/RSX Communications.

8. (Optional) If TEC device needs to be commissioned/conﬁgured, you can connect to TEC device via

WRS HMI port connection (see Appendix C–Wireless TEC Commissioning and Balancing for details).

Revision Date: July 10, 2008 7

Siemens Building Technologies, Inc.

APOGEE Wireless User Guide

Chapter 2–About the Wireless Room Sensor Solution

Chapter 2 describes the features and overall functions of the Wireless Room Sensor Solution.

Why Use Wireless Room Temperature Sensor Communications?

Wireless communications between a room temperature sensor and TEC is a cost effective, reliable, and

ﬂexible alternative to a hard-wired solution that differentiates our solutions from our competitors. For

example, in applications where wire must be run through conduit, electrician labor is expensive, and

architecture or building materials make running a cable difﬁcult, a Wireless Room Sensor Solution is an

attractive alternative.

• Less cabling is required for room temperature sensor device installation. Low-impact installation

enables cost effective replacement of pneumatic and competitor equipment.

• Easier installation and re-conﬁguring spares facilities the difﬁculties associated with rewiring to

support new cable routing.

• Factory installation of wireless transceivers by terminal box manufacturers further reduces

electrician involvement at installation time and reduces installation costs.

Hardware Components

The Wireless Room Sensor Solution is a wireless connection between P1 or BACnet TECs and room

temperature sensors that communicate via a radio frequency (RF) link instead of a hard-wired link. For

the Wireless Room Sensor Solution, a Wireless Room Sensor (WRS) communicates via point-to-point

wireless link to a Room Sensor Transceiver (RSX) device connected to a TEC device.

WLAN0091R2

Figure 1. WRS Communicating with RSX/TEC.

8Revision Date: July 10, 2008

Siemens Building Technologies, Inc.

Wireless Room Sensor Solution

WRS and RSX devices are not supported by ﬁrst-generation Siemens Wireless Field

Level Network (WFLN) devices.

Room Sensor Transceiver (RSX)

A Room Sensor Transceiver (RSX) connects to the RTS port of a TEC device. The RSX enables the TEC

device to wirelessly communicate with a Wireless Room Sensor (WRS). Each RSX supports one TEC and

one WRS, and each WRS supports one RSX and one TEC.

Figure 2. Room Sensor Transceiver (RSX).

The RSX provides an indicator light to furnish operation and communication link status. See Table 1 to

monitor current RSX status.

In Table 1, rapid ﬂashes last .25 seconds, while slow ﬂashes last 1 second.

Table 1. RSX Indicator Light.

Indicator State RSX Status Good or Bad?

Off Powered off N/A

Solid Yellow (for 10

seconds)

Completed binding operation with WRS, or received

communication request (or “ping”) from bound WRS

Good

continued on next page...

Revision Date: July 10, 2008 9

Siemens Building Technologies, Inc.

APOGEE Wireless User Guide

Table 1. RSX Indicator Light. (continued)

Indicator State RSX Status Good or Bad?

Rapid Green Flashes RSX is communicating wirelessly with its bound and

powered WRS, and is communicating with its wired

link to a powered TEC

Good

Two Rapid Green

Flashes followed by

2 seconds OFF time

RSX is communicating wirelessly with its bound and

powered WRS, but is not communicating with its wired

link to a powered TEC

Bad

Need to check wired

link and TEC device for

problems.

Two Slow Green Flashes

followed by 2 seconds

OFF time

RSX has not communicated wirelessly with its WRS

during the last two WRS heartbeat intervals (default

of 10 minutes), but the RSX is communicating via its

wired link to a powered TEC

Bad

Need to check wireless

link and WRS device

for problems.

Slow Green Flashes RSX is not bound to a WRS or is not communicating

with bound WRS, and is not communicating with its

wired link to a powered TEC

Bad

Need to ensure RSX

is bound to WRS, then

check links (wireless

and wired) and devices

(WRS and TEC) for

problems.

Flashing Yellow Bootloader only loaded. Bad

RSX is not operational.

Need to contact Field

Support.

Solid Yellow

(Continuous)

EEPROM error. Bad

RSX is not operational.

Need to contact Field

Support.

Wireless Room Sensor (WRS)

A Wireless Room Sensor (WRS) is associated with a speciﬁc RSX/TEC. Using the wireless connection,

the WRS communicates its information to its TEC via associated RSX attached to the TEC’s RTS port.

Three WRS models are available:

•Sensing Only

•Sensing with Display – includes an LCD panel showing current room temperature, TEC occupancy

mode, TEC address, remaining WRS battery power, and wireless WRS/RSX link communication

strength(whenindiagnosticmode). Canbeconﬁgured to show room temperature in either

Fahrenheit or Celsius degrees.

•Full Featured (Sensing with Display, Override, and Setpoint) – in addition to the Sensing with

Display features, this model includes push buttons for users to override the occupancy mode

and adjust the temperature setpoint.

10 Revision Date: July 10, 2008

Siemens Building Technologies, Inc.
