StarTech.com S3510BMU33T Systemhandbuch

USB 3.0 Trayless External 3.5” SATA III HDD Enclosure w/ UASP for SATA 6 Gbps – Black

StarTech ID: S3510BMU33T

The S3510BMU33T Removable Hard Drive Enclosure lets you to connect a 3.5” SATA hard drive through an

available USB 3.0 port, with a tray-less design that makes hot-swapping easy.

For universal compatibility, you can connect the enclosure through USB 3.0, with support for UASP. When

connected to a UASP compatible host port, the enclosure is capable of performance up to 70% faster than

conventional USB 3.0, making it easy to take advantage of the full speed potential of your SATA III hard drives. See

our UASP testing results below for further details.

The HDD enclosure offers a versatile solution for increasing the storage/backup capabilities of your computer, with

support for large capacity hard drives, and the ability to easily hot-swap between drives. Plus, to maximize both

durability and reliability, the enclosure features high-quality aluminum construction and is backed by a StarTech.com

2-year warranty and free lifetime technical support.

Improved Performance with UASP

UASP is supported in Windows 8, Mac OSX (10.8 or above), and Linux. In testing, UASP performs with a 70%

faster read speed and 40% faster write speed over traditional USB 3.0 at peak performance.

At the same peak in testing UASP also shows an 80% reduction in required processor resources.

Testing results were obtained using an Intel® Ivy Bridge system, a UASP-enabled StarTech.com Enclosure, and a

SATA III solid state drive.

Applications

Retrieve data from an old SATA drive, or turn the unused drive into additional external storage space

Turn a high capacity SATA hard drive into portable, external storage

Hot-swap drives using a single enclosure, instead of having to swap separate enclosures

Backup and protect important files on an external portable enclosure

Features

UASP Compliant

Compatible with USB 3.0/2.0/1.1 (5Gbps/480Mbps/12Mbps)

Trayless Aluminum Enclosure

Compatible with SATA revision I/II/III (1.5/3.0/6.0 Gbps)

Plug-and-Play and Hot-Swap Compatible

Tool-less installation

Technical Specifications

Warranty 2 Years

Chipset ID ASM1051E

Drive Installation Removable

Drive Size 3.5in

Drive Type SATA

Interface USB 3.0

Number of Drives 1

Number of internal 3.5

inch bays

Drive Connectors 1 - SATA Data & Power Combo (7+15 pin)

Host Connectors 1 - USB 3.0 B (9 pin; SuperSpeed)

Hot Swap Capability Yes

Max Drive Capacity Currently tested with up to 4TB 7200 RPM hard drive

Maximum Data Transfer

Rate

5 Gbps

Type and Rate SATA III (6 Gbps)

Type and Rate USB 3.0 - 5 Gbit/s

UASP Support Yes

OS Compatibility Windows XP (32/64-bit)/ Server 2003 (32/64-bit)/ Server 2008 R2/ Vista (32/64-bit)/ 7

(32/64-bit)/ 8 (32/64-bit)

Mac OS X

Linux

Color Black

Enclosure Type Aluminum

Product Height 1.5 in [38 mm]

Product Length 8.1 in [206 mm]

Product Weight 32.8 oz [930 g]

Product Width 5.7 in [145 mm]

LED Indicators 1 - Power/Activity

Center Tip Polarity Positive

Input Current 0.8 A

Input Voltage 100 ~ 240 AC

Output Current 2 A

Output Voltage 12 DC

Plug Type M

Power Adapter Included Yes

Humidity 20%RH ~ 80%RH

Operating Temperature 5°C to 35°C (41°F to 95°F)

Storage Temperature 5°C to 35°C (41°F to 95°F)

Shipping (Package)

Weight

2.4 lb [1.1 kg]

Included in Package 1 - USB 3.0 Enclosure

Included in Package 1 - USB 3.0 Cable

Included in Package 1 - Universal Power Adapter (NA/UK/EU)

Included in Package 1 - User Manual
