StarTech.com S352BU313R Bedienungsanleitung

Manual Revision: 07/25/2016

For the latest information, technical specications, and support for

this product, please visit www.StarTech.com/S352BU313R.

FR: Guide de l’utilisateur - fr.startech.com

DE: Bedienungsanleitung - de.startech.com

ES: Guía del usuario - es.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IT: Guida per l’uso - it.startech.com

S352BU313R

USB 3.1 Dual 3.5 in. SATA (6Gbps)

HDD Enclosure with RAID

*actual product may vary from photos

Instruction manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If

this equipment does cause harmful interference to radio or television reception, which can

be determined by turning the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help

This device complies with part 15 of the FCC Rules. Operation is subject to the following

two conditions: (1) This device may not cause harmful interference, and (2) this device must

accept any interference received, including interference that may cause undesired operation.

Changes or modications not expressly approved by StarTech.com could void the user’s

authority to operate the equipment.

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction manual

Table of Contents

Introduction............................................................................................1

Product diagram........................................................................................................................................ 1

Package contents...................................................................................................................................... 3

Requirements ............................................................................................................................................. 3

About USB 3.1 Gen 2................................................................................................................................ 3

Install a drive...........................................................................................4

Set a RAID mode.....................................................................................5

RAID modes................................................................................................................................................. 5

About LED indicators.............................................................................6

Technical support...................................................................................7

Warranty information............................................................................7

Instruction manual

Introduction

You can use the S352BU313R to create an external RAID storage setup, using two

3.5 in. SSDs or HDDS, with fast performance and USB 3.1 support. The S352BU313R

includes a solid and compact housing and oers good drive protection, making it an

ideal storage solution for your desktop computer or laptop.

Product diagram

Front

Power LED

Drive 1 LEDs

Drive 2 LEDs

Built-in fan

Power switch

Power adapter port

Fan switch

USB 3.1 port

Back

Instruction manual

Drive tray

Set RAID button

RAID mode DIP switches

Instruction manual

Package contents

• 1 x dual-bay enclosure

• 1 x universal power adapter (NA/JP, UK, EU, AU)

• 1 x USB-A to USB-B cable

• 1 x USB-C to USB-B cable

• 1 x enclosure stand

• 8 x drive screws

• 1 x quick-start guide

Requirements

• Computer system with USB port

• One or two 3.5 in. HDDs, SSDs, or SSHDs

• Phillips screwdriver

This dual-bay enclosure is OS independent and doesn’t require any additional drivers

or software.

To obtain the maximum USB throughout, you must use a system with a USB 3.1 Gen 2

(10Gbps) port.

System requirements are subject to change. For the latest requirements, please visit

www.StarTech.com/S352BU313R.

About USB 3.1 Gen 2

USB 3.1 Gen 2 connectivity standard oers speeds up to 10Gbps. The S352BU313R is

backwards compatible and supports USB 2.0 and USB 3.1 Gen 1 (5Gbps).

Instruction manual

Install a drive

Warning! Drives should be handled carefully, especially when they’re transported.

If you’re not careful with your drives, you may lose data as a result. Always handle

storage devices with caution. Make sure that you’re properly grounded by wearing an

anti-static strap when you install any computer component. If an anti-static strap isn’t

available, touch a large, grounded metal surface for several seconds to discharge any

built-up static electricity.

1. Use a Phillips screwdriver to remove the four screws in the back panel of the dual-

bay enclosure.

Note: If you’re using the dual-bay enclosure for the rst time, you don’t need to remove

any screws because the dual-bay enclosure ships without the screws installed.

2. Slide the back panel away from the dual-bay enclosure to reveal the drive tray.

3. Place the drive tray on its side with the green Set RAID button facing upwards.

4. Gently slide a 3.5 in. HDD, SSD, or SSHD into one of the drive trays so that the SATA

connector on the drive lines up with the corresponding connector on the drive

tray. The connector on your drive is keyed so that it only ts in the drive tray one

way.

5. To secure the drive in place, use a Phillips screwdriver to insert two of the provided

screws into each side of the drive tray the drive is in, and tighten the screws in

place.

6. To install a second drive, repeat steps 4 and 5.

7. Set a RAID mode. For more information about how to do this, see the“Set a RAID

mode” section.

8. Slide the drive tray back into the dual-bay enclosure.

9. Use a Phillips screwdriver to insert the four screws into the back panel, and tighten

the screws in place.

10. Connect the universal power adapter to the Power adapter port on the dual-bay

enclosure and a power outlet.

11. Connect one of the provided USB cables to the USB 3.1 port on the dual-bay

enclosure and a USB port on your computer.

12. Move the Power switch on the dual-bay enclosure to the ON position.

13. Use the Fan switch on the dual-bay enclosure to turn on the fan.

Instruction manual

Set a RAID mode

To congure a RAID mode, you need to use the RAID mode DIP switches and the green

set RAID button located on the inside of the dual-bay enclosure.

1. Move the Power switch on the dual-bay enclosure to the OFF position.

2. Remove the drive tray from the dual-bay enclosure.

3. Move the RAID mode DIP switches to the correct position for the RAID mode that

you want to set. For more information about the switch positions, see the “RAID

modes” section.

4. Connect the universal power adapter to the Power adapter port on the dual-bay

enclosure and a power outlet.

5. Move the Power switch on the dual-bay enclosure to the on position.

6. Press and hold the green Set RAID button for 10 seconds, until the drive LEDs

begin to blink.

7. Disconnect the universal power adapter from the Power adapter port on the

dual-bay enclosure and the power outlet.

8. Slide the drive tray back into the dual-bay enclosure.

9. Use a Phillips screwdriver to insert the four screws into the back panel, and tighten

the screws in place.

RAID modes

RAID mode Description Switch 1 Switch 2

JBOD/PM Just a Bunch of Disks

Allows access to both drives independently

O O

RAID 0 Stripe set

Splits data evenly across two or more

drives

On O

RAID 1 Mirror

Creates a redundant drive on the second

drive for security

O On

SPAN Spanning

Creates a large single drive volume that

consists of both drives

On On

Instruction manual

About the LED indicators

The dual-bay enclosure features three LED indicators: two drive activity LED indicators

(both blue), and one power LED indicator (green).

Situation LED status

Drive 1 activity Drive 2 activity Power

Unit is in standby

(disconnected from PC

or PC is turned o or in

standby mode)

O O Blinking three

times a second

Enclosure is online

and ready

O O On

Accessing drive 1 Blinking three

times a second

O On

Accessing drive 2 O Blinking three

times a second

Drive 1 crash

(RAID 0/1/SPAN)

LED is

illuminated and

not blinking

O On

Drive 2 crash

(RAID 0/1/SPAN)

O LED is

illuminated and

not blinking

RAID 1 drive 1

rebuilding

On Cycle of

gradually

getting brighter

and then

darkening

RAID 1 drive 2

rebuilding

Cycle of

gradually

getting brighter

and then

darkening

On On

RAID rebuild complete O O On

RAID mode changed Quickly ashes

three times

Quickly ashes

three times

Instruction manual

Technical support

StarTech.com’s lifetime technical support is an integral part of our commitment to

provide industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty information

This product is backed by a two-year warranty.

StarTech.com warrants its products against defects in materials and workmanship

for the periods noted, following the initial date of purchase. During this period,

the products may be returned for repair, or replacement with equivalent

products at our discretion. The warranty covers parts and labor costs only.

StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

ocers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation

of incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Inhaltsverzeichnis

Andere StarTech.com Gehäuse Handbücher

StarTech.com

StarTech.com SAT3510U3VP Bedienungsanleitung

StarTech.com

StarTech.com ESATCASE2 Bedienungsanleitung

StarTech.com

StarTech.com DRW110ATA Handbuch

StarTech.com

StarTech.com S351BU313 Bedienungsanleitung

StarTech.com

StarTech.com SM2E1BMU31C Bedienungsanleitung

StarTech.com

StarTech.com 8STS25SLOTR Bedienungsanleitung

StarTech.com

StarTech.com InfoSafe SAT2510BU2B Bedienungsanleitung

StarTech.com

StarTech.com SATSAS225ODD Bedienungsanleitung

StarTech.com

StarTech.com S2510BU33PW Bedienungsanleitung

StarTech.com

StarTech.com S251BPU313 Bedienungsanleitung

StarTech.com

StarTech.com S352U2RER Bedienungsanleitung

StarTech.com

StarTech.com 25SATSAS35HD Bedienungsanleitung

StarTech.com

StarTech.com 2TBT3-PCIE-ENCLOSURE Bedienungsanleitung

StarTech.com

StarTech.com S251SMU33EP Bedienungsanleitung

StarTech.com

StarTech.com InfoSafe IDECASE35U2 Bedienungsanleitung

StarTech.com

StarTech.com SATSASBAY425 Bedienungsanleitung

StarTech.com

StarTech.com SAT3520U2R Bedienungsanleitung

StarTech.com

StarTech.com IDECASE35U2B Bedienungsanleitung

StarTech.com

StarTech.com IDECASE35NAS Bedienungsanleitung

StarTech.com

StarTech.com S2510BPU337 Bedienungsanleitung

StarTech.com

StarTech.com InfoSafe UNI3510U2E Bedienungsanleitung

StarTech.com

StarTech.com INFOSAFE SAT2510U2 Bedienungsanleitung

StarTech.com

StarTech.com SLSODDU33B Bedienungsanleitung

StarTech.com

StarTech.com SAT3510U2F Bedienungsanleitung

Beliebte Gehäuse Handbücher anderer Marken

SilentiumPC

SilentiumPC Armis AR5 Handbuch

Pulsar

Pulsar 17/TRP80/DSPR Bedienungsanleitung

Thermaltake

Thermaltake V150 TG Bedienungsanleitung

MSI

MSI MPG SEKIRA 500X Bedienungsanleitung

Antec

Antec Dark fleet DF-10 Bedienungsanleitung

Nexans

Nexans WTC05 Bedienungsanleitung

Peavey

Peavey DS 1502 Bedienungsanleitung

D-Link

D-Link ShareCenter Pro DNS-1550-04 Bedienungsanleitung

Rosewill

Rosewill RX82-U(JBOD) Bedienungsanleitung

QNAP

QNAP SAS JBOD CLI 1.0 Bedienungsanleitung

GAMDIAS

GAMDIAS Talos P1 Bedienungsanleitung

Auvs

Auvs KR615 Bedienungsanleitung

Digitus

Digitus DA-71114 Bedienungsanleitung

CommScope

CommScope FDH 3000 Bedienungsanleitung

FS FHD-FWME4 Bedienungsanleitung

JBL

JBL CS1215T Bedienungsanleitung

Pulsar

Pulsar ARAD-S4 Bedienungsanleitung

Pulsar

Pulsar AWO454 Bedienungsanleitung
