StarTech.com DRW110SAT Bedienungsanleitung

Removable Hard Drive Enclosure

DRW110SAT, DRW110SATBK

DRW113SAT, DRW113SATBK

DRW115SAT, DRW115SATBK

Instruction Manual

Actual product may vary from photo

Removable Drive Enclosure with Shock Absorbers

for 3.5” SATA Hard Drives

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd

ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installing the Hard Drive in the Caddy . . . . . . . . . . . . . . . . . . . . . . . . .2

Installing the Bay in the PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Installing the Swap Manager software . . . . . . . . . . . . . . . . . . . . . . . . .4

Converting a dynamic disk to a basic disk . . . . . . . . . . . . .4

Installing the Swap Manager software . . . . . . . . . . . . . . . .4

Using the Swap Manager software . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Troubleshooting Swap Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Monitoring your Hard Disk Drive and Drawer . . . . . . . . . . . . . . . . . . . .6

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Instruction Manual

IInnttrroodduuccttiioonn

FFeeaattuurreess

BBeeffoorreeYYoouuBBeeggiinn

Instruction Manual

Thank you for purchasing a StarTech.com removable Serial ATA (SATA) hard drive

enclosure with shock absorbers. Now, you can quickly add and remove SATA hard drives

from your PC without having to open your computer. Whether for hot swapping hard

drives, using multiple operating systems, making high speed, high capacity backups, or

minimizing downtime on mission-critical PCs, StarTech.com’s removable drive enclosures

provide the ultimate in reliability and convenience. The sturdy all-aluminum design gives

you extra durability and heat dissipation and the front caddy-mounted ball-bearing fan(s)

keep your hard-working drive cool.

• Shock absorbers keep hard drive protected

• Compatible with all 3.5 inch SATA hard drives

• Locking mechanism controls power to the drive so that the disk cannot be

accidentally removed while in operation

• Ball-bearing fan(s) keeps hard drives running cool

System Requirements

• An IBM-PC or Mac computer with an SATA Hard Drive interface

• Swap Manager software (DRW113SAT/DRW113SATBK/DRW115SAT/DRW115SATBK

ONLY) requires Windows XP/2000/Me/98SE/98/95

• Allows “hot-swapping” of drives through Swap Manager software

• One drive connection cable

• One internal power cable

Contents

This package should contain:

• 1 x drive caddy

• 1 x drive bay

• 2 x keys to lock/unlock the drive

• Screw kit

• 1 x Swap Manager software CD (DRW113SAT/DRW113SATBK/DRW115SAT/

DRW115SATBK ONLY)

IInnssttaallllaattiioonn

Installing the Hard Drive in the Caddy

1. Remove the caddy from the bay by lifting the handle and sliding the caddy out of the

bay.

2. Remove the top panel from the caddy by pressing the cover release button and sliding

the lid towards the back of the caddy.

3. Connect the SATA ribbon to the hard drive, making sure that the red wire is on Pin 1.

NOTE: If you are unsure of the location of Pin 1, contact your hard drive manufacturer.

4. Attach the power connector to the hard drive.

5. Gently place the hard drive in the caddy, making sure that the screw-holes on the

bottom of the hard drive line up with the holes in the caddy.

6. Firmly hold the hard drive to the shock absorber plate and use the four 6-32 x

1/4”(coarse thread) screws to mount your hard drive to the drawer from underneath.

7. Replace the top panel of the caddy.

Instruction Manual

*Note: Mount screws to underside of drawer

Installing the Bay in the PC

1. Make sure your system is unplugged and you are grounded.

2. Remove the side covers from your system and remove the front cover from an

available 5 1/4” drive bay (see your computer’s user manual for details, if necessary).

3. Insert the bay into the 5 1/4” bay slot, making sure that the screw-holes on the side of

the bay line up with the holes in the bay slot.

4. Connect your computer’s cable ribbon to the connector on the back of the bay,

NOTE: Only drives that are connected to the secondary SATA controller can be

hotswapped with Swap Manager software (DRW113SAT / DRW113SATBK /

DRW115SAT / DRW115SATBK ONLY). It is not possible to hot-swap the C: or any other

drives on the primary controller.

5. Plug a connector from your computer’s power supply into the power port on the back

of the bay.

6. Using the M3 x 1/4” long (fine thread) screws, mount the bay into the PC.

Installing the Caddy in the Bay

1. With the handle lifted, slide the caddy into the bay until it is firmly seated. Lower the

handle to to click the caddy into its proper position.

2. Insert the key and turn clockwise to lock the drive into place and supply the drive with

power. The drive will not function if the drawer has not been locked.

Removing the Drive Drawer

1. Insert the key and turn counter-clockwise to unlock the drive drawer.

2. Lift the handle and gently pull the caddy out of the bay.

NOTE: Do not unlock the drawer when the hard drive is in use (See “Monitoring Your

Hard Disk Drive and Drawer” below). Only power down the drive when the hard drive is

Instruction Manual

idle. Once you have powered down the hard drive, wait about 15 seconds to let the hard

drive “spin down” before removing the caddy from the bay.

Installing Your Swap Manager Software

(

DRW113SAT/DRW113SATBK/DRW115SAT/DRW115SATBK ONLY

)

NOTE: Remember that Swap Manager only works on IBM or compatible computers

running Windows XP, 2000, Me, 98SE, 98, or 95.

NOTE: Windows 2000/XP/2003 Server users should be aware that Swap Manager does

not support the dynamic disk feature introduced in these versions of Windows. If you are

using the dynamic disk feature, you must convert the volume back to a basic disk to use

Swap Manager.

To convert a dynamic disk to a basic disk:

1. Back up all the data on all the volumes on the disk you want to convert to a basic disk.

2. Log on as Administrator or as a member of the Administrators group.

3. Click Start, and then click Control Panel.

4. Click Performance and Maintenance, click Administrative Tools, and then double

click Computer Management.

5. In the left pane, click Disk Management.

6. Right-click a volume on the dynamic disk that you want to change to a basic disk, and

then click Delete Volume.

7. Click Yes when you are prompted to delete the volume.

8. Repeat steps 4 and 5for each volume on the dynamic disk.

9. After you have deleted all the volumes on the dynamic disk, right-click the dynamic

disk that you want to change to a basic disk, and then click Convert to Basic Disk.

NOTE: You must right-click the gray area that contains the disk title on the left side of the

Details pane. For example, right-click Disk 1.

To install the Swap Manager Software:

1.Insert your Swap Manager CD into your CD drive. If Windows does not automatically

launch the software installation, or you encounter any errors, double-click on your CD

icon and launch the SETUP file.

2. Click Next to continue the installation.

3. Select Yes, I accept to agree to the terms in the license agreement and click Next.

4. Enter a suitable location for the Swap Manager software and click Next. Click Yes to

Instruction Manual

confirm the location of the installation.

5. Click Finish when the installation is complete and reboot your computer to allow the

changes to take effect.

Using Your Swap Manager Software

The following is intended to provide you with an introduction to your Swap Manager

software. For detailed instructions and troubleshooting tips, consult the material provided

on the Swap Manager CD.

• Start Swap Manager by double-clicking on the Swap Manager icon. This will bring up

the Swap Manager window.

• The Swap Manager window displays a list of all the drives attached to your computer.

The window also lists information about each drive’s SATA channel.

• Remember that while the window lists all drives for your computer, you can only swap

drives attached to the secondary SATA channel.

• If possible always keep the Swap Manager open if you are planning to swap drives. It

can be minimized, but it should not be closed.

• To remove a drive, bring up the Swap Manager window and click on the Swap Out

button above the drive information. Wait a few seconds then remove the drive according

to the instructions on page 5 or according to instructions provided by the drive

manufacturer. Click on the Swap All In button to refresh the Swap Manager information.

The drive information should now be removed from the Swap Manager.

• To add a drive, add your drive according to the instructions on page 5 or according to

instructions provided by your drive manufacturer. Bring up the Swap Manager window

and click on the Swap All In button to refresh the Swap Manager. It may take a few

seconds to properly register all the new information. You should now see your new drive

listed in the Swap Manager.

Troubleshooting Swap Manager

If you have installed a new drive but there is no new icon listed in Swap Manager, first

make sure that you have clicked the Swap In icon to let Swap Manager know that there

is a new drive. If that does not work, check the following:

• Make sure that the hardware is properly installed and that all cables are properly

connected and firmly seated.

• Make sure that the drive bay is connected to the secondary SATA channel. The primary

SATA channel is not accessed by Swap Manager.

• Make sure that the drive caddy is firmly seated in the bay and that the bay has been

locked. If the bay is not locked, no power will be supplied to the drive and Swap

Manager will not detect it.

Instruction Manual

Monitoring Your Hard Disk Drive and Drawer

The status LED is located on the right side of the drive drawer. It is your best indication

of the hard drive’s status, and is lit when the drawer is successfully inserted and locked

into the caddy.

NOTE: It is recommended that you avoid removing a drawer during hard disk activity, as

doing so could damage the drive and/or data.

Instruction Manual

TTeecchhnniiccaallSSuuppppoorrtt

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

WWaarrrraannttyyIInnffoorrmmaattiioonn

This product is backed by a one-year warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product. Some states do not allow the exclusion or limitation of

incidental or consequential damages. If such laws apply, the limitations or exclusions

contained in this statement may not apply to you.

Instruction Manual

Andere Handbücher für DRW110SAT

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere StarTech.com Gehäuse Handbücher

StarTech.com

StarTech.com SMS2BU31C3R Bedienungsanleitung

StarTech.com

StarTech.com RK2537BKM Bedienungsanleitung

StarTech.com

StarTech.com INFOSAFE IDE2510U2 Bedienungsanleitung

StarTech.com

StarTech.com S2510BPU33 Bedienungsanleitung

StarTech.com

StarTech.com S351BMU33ET Bedienungsanleitung

StarTech.com

StarTech.com 4POSTRACK25 Bedienungsanleitung

StarTech.com

StarTech.com S2510BU3PW Bedienungsanleitung

StarTech.com

StarTech.com S354UFER Bedienungsanleitung

StarTech.com

StarTech.com S2510PESAT Bedienungsanleitung

StarTech.com

StarTech.com S3510BMU33 Bedienungsanleitung

StarTech.com

StarTech.com S251BU31REMD Bedienungsanleitung

StarTech.com

StarTech.com S3510BMU33ET Bedienungsanleitung

StarTech.com

StarTech.com S251BPU31C3 Bedienungsanleitung

StarTech.com

StarTech.com HSB2535SATBK Bedienungsanleitung

StarTech.com

StarTech.com MONSTADJD Bedienungsanleitung

StarTech.com

StarTech.com HSB320SATBK Bedienungsanleitung

StarTech.com

StarTech.com S2510BPU337 Bedienungsanleitung

StarTech.com

StarTech.com 25SATSAS35HD Bedienungsanleitung

StarTech.com

StarTech.com SMS1BMU313 Bedienungsanleitung

StarTech.com

StarTech.com RK1219WALH Bedienungsanleitung

StarTech.com

StarTech.com SAT3510U2REM Bedienungsanleitung

StarTech.com

StarTech.com RK9WALM Bedienungsanleitung

StarTech.com

StarTech.com SAT2510U2REM Bedienungsanleitung

StarTech.com

StarTech.com INFOSAFE SAT2510BU2 Bedienungsanleitung

Beliebte Gehäuse Handbücher anderer Marken

SilentiumPC

SilentiumPC Armis AR5 Handbuch

Pulsar

Pulsar 17/TRP80/DSPR Bedienungsanleitung

Thermaltake

Thermaltake V150 TG Bedienungsanleitung

MSI

MSI MPG SEKIRA 500X Bedienungsanleitung

Antec

Antec Dark fleet DF-10 Bedienungsanleitung

Nexans

Nexans WTC05 Bedienungsanleitung

Peavey

Peavey DS 1502 Bedienungsanleitung

D-Link

D-Link ShareCenter Pro DNS-1550-04 Bedienungsanleitung

Rosewill

Rosewill RX82-U(JBOD) Bedienungsanleitung

QNAP

QNAP SAS JBOD CLI 1.0 Bedienungsanleitung

GAMDIAS

GAMDIAS Talos P1 Bedienungsanleitung

Auvs

Auvs KR615 Bedienungsanleitung

Digitus

Digitus DA-71114 Bedienungsanleitung

CommScope

CommScope FDH 3000 Bedienungsanleitung

FS FHD-FWME4 Bedienungsanleitung

JBL

JBL CS1215T Bedienungsanleitung

Pulsar

Pulsar ARAD-S4 Bedienungsanleitung

Pulsar

Pulsar AWO454 Bedienungsanleitung
