StarTech.com IPUSB2VGA2 Bedienungsanleitung

Manual Revision: 10/27/2016

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IPUSB2VGA2

VGA over IP Extender - 1920 x 1200

*actual product may vary from photos

Quick start guide

FCC compliance statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of trademarks, registered trademarks, and other protected names and symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Quick start guide

Table of Contents

Overview ....................................................................................................... 1

About this product.........................................................................................................................................1

Packaging contents........................................................................................................................................1

System requirements.....................................................................................................................................1

Front view..........................................................................................................................................................2

Rear view............................................................................................................................................................2

Software installation ................................................................................... 3

Software installation for Windows computers.....................................................................................3

Software installation for Mac computers (USB mode only).............................................................4

Hardware installation.................................................................................. 4

Hardware installation for USB mode........................................................................................................4

Hardware installation for Ethernet mode ..............................................................................................4

Basic conguration ...................................................................................... 5

Basic conguration for Windows computers........................................................................................5

USB mode.....................................................................................................................................................5

Ethernet mode ...........................................................................................................................................5

Basic conguration for Mac computers..................................................................................................6

Technical Support ........................................................................................ 7

Warranty Information.................................................................................. 7

Quick start guide

Overview

About this product

This VGA over IP extender gives you two options to interface your computer with a VGA

display and 2-port USB peripheral set.

In Ethernet mode: (Windows only)

You can connect a VGA display and two USB peripherals to your network, creating a remote

console that can interface with any Windows computer on your network. This mode enables

you to extend or mirror the desktop of your Windows computer over long distances using

your wireless or wired NIC.

In USB mode: (Windows or Mac)

You can connect your computer to a VGA display and two USB peripherals using a USB port

on your computer. This mode enables you to extend or mirror the desktop of your computer

over a short distance using your USB controller.

Packaging contents

• 1 x VGA over IP extender

• 1 x USB cable

• 1 x CAT5 cable

• 1 x universal power adapter (NA / EU / UK / AU)

• 1 x mounting bracket

• 1 x mounting screw kit

• 1 x rubber foot set

• 1 x quick start guide

System requirements

• VGA enabled display device with cabling

• Computer with:

Minimum CPU: Intel® or AMD® 2.4 GHz single core

Minimum RAM: 1GB

Microsoft® Windows® (32 or 64 bit) 10 , 8 or 8.1 , 7, Vista

(USB mode only) Apple OSX El Capitan (10.11), Yosemite (10.10), Mavericks (10.9)

Mountain Lion (10.8), Lion (10.7), Snow Leopard (10.6)

System requirements are subject to change. For the latest requirements, please visit

www.startech.com/IPUSB2VGA2

Quick start guide

Front view

Rear view

1. VGA output port

2. USB 2.0 peripheral ports

3. Audio line in

4. Audio line out

1. Power adapter port

2. LAN port

3. USB host port

4. Factory reset button

Quick start guide

Software installation

To use the video adapter in USB mode, ensure the software installation steps have been

completed before you connect the adapter to your computer.

Software installation for Windows computers

Note: you will need to restart your computer during the software installation process.

Please be sure to save any unsaved material before you install the software.

1. Download the latest software from the StarTech.com website:

http://www.startech.com/IPUSB2VGA2

2. The software will be compressed in a .zip folder. Extract the contents of the folder to a

location on your computer that’s easy to access, such as your Desktop or Downloads

folder.

3. Once the les have been extracted, open the Windows folder, and launch the Driver-

Setup(.exe) le, to install the DisplayLink drivers.

4. Follow the on-screen prompts to complete the installation steps and when instructed to do

so, restart your computer.

Note: If you’re using the video adapter in USB mode only, the software installation steps

have now been completed. Please proceed to Hardware installation for USB mode.

5. Once your computer has restarted, install the USB Server software to operate the video

adapter in Ethernet mode. Reopen the Windows folder, followed by the APP folder, and

launch the Setup(.exe) le.

6. Follow the on-screen prompts to complete the installation steps and when instructed to do

so, restart your computer.

7. Once your computer has restarted, the software installation is complete.

Quick start guide

Software installation for Mac computers (USB mode only)

Note: you may need to restart your computer during the software installation process. Please

be sure to save any unsaved material before you install the software.

1. Download the latest software from the StarTech.com website:

http://www.startech.com/IPUSB2VGA2

2. The software will be compressed in a .zip folder. Extract the contents of the folder to a

location on your computer that’s easily to access, such as your Desktop.

3. Once the les have been extracted, open the MAC OS folder, followed by the folder that

corresponds with your version of Mac OSX, and launch the DisplayLink installer le.

4. Follow the on-screen prompts to complete the installation steps and when instructed to do

so, restart your computer.

5. Once your computer has restarted, the software installation is complete.

Hardware installation

Hardware installation for USB mode

1. Connect a VGA cable (not included) to the video adapter’s VGA output port to your VGA

display.

2. Connect the included power adapter to an AC outlet and to the video adapter’s power

adapter port.

3. Connect the included USB cable to the video adapter’s USB host port, to a USB port on the

your computer system.

4. Your computer will automatically detect the USB drivers for the video adapter and install

them.

5. (Optional) You can connect up to two USB devices to video adapter’s USB 2.0 peripheral

ports.

Note: In order for your computer to recognize the USB peripherals that you’ve connected,

the drivers for any connected USB device must be installed on your computer before you

connect the USB peripherals to the video adapter.

6. Hardware installation for USB mode is now completed.

Hardware installation for Ethernet mode

1. Connect a VGA cable (not included) to the video adapter’s VGA output port to your VGA

display.

Quick start guide

2. Connect the included power adapter to an AC power outlet and to the video adapter’s

power adapter port.

2. Connect the CAT5 cable (included) to the video adapter’s LAN port and to an Ethernet port

on your network, such as a router or NIC on your computer.

3. (Optional) You can connect up to two USB devices to the video adapter’s USB 2.0 peripheral

ports.

Note: In order for your computer to recognize the USB peripherals that you’ve connected,

the drivers for any connected USB device must be installed on your computer before you

connect the USB peripherals to the video adapter.

4. Hardware installation for Ethernet mode is now completed.

Display conguration

Display conguration for Windows computers

USB mode

1. Click the DisplayLink icon that appears in your Windows system tray after you’ve completed

the Hardware Installation for USB mode steps.

2. When the DisplayLink menu opens, click Video Setup to launch the Windows display

settings.

3. Congure the monitor to your desired settings, including resolution and orientation.

Ethernet mode

1. Double-click the Launch USB Server icon on your desktop, to open the USB server

software.

Quick start guide

2. The USB Server software will now display a list of connected devices. If your network

supports DHCP (assigns IP addresses automatically) the video adapter will be listed below

the Devices column along with your display below it and the status of your display will be

listed as Free and you can continue to step 3.

If your network does not support DHCP (such as when the adapter is connected directly

to your computer, without a router) your VGA adapter and display will be listed below

the Devices column, but with a ?icon on the adapter and display, and the status for each

device may be listed as Dierent Network Segment with Error.

If your network does not support DHCP the adapter and your computer will need to have

dierent IP addresses assigned on the same subnet, in order to detect each other. The VGA

adapters default IP address is 192.168.1.50.

Change your computer’s IP address

If your computer’s IP address can be changed to any subnet, if for example the computer

is connected directly to the VGA adapter, the easiest solution is likely assigning your

computer a (static) IP address of 192.168.1.51. For information on how to do this, visit

Microsoft’s Conguring a DHCP server static IP address TechNet article or contact your

network administrator.

Quick start guide

Change the VGA adapter’s IP address

If your computer’s IP address can not be changed, if for example your entire network is on a

non-DHCP network with dierent subnet than the VGA adapter’s default IP address, you can

follow the steps below to congure the VGA adapter to match your network’s subnet.

a) With the USB server application open, right-click on the main VGA video adapter device

and select Server Conguration.

b) Uncheck the Use DHCP option and manually enter an IP address and Subnet Mask that

matches your network settings.

c) Click Set to save your new settings and return to the main window.

1. Your IP extender will appear in the Device list, with the connected VGA display listed below

it. Select the VGA display from the Device list, then click the Connect Device button.

Note: if your VGA display has a built-in audio controller, the audio controller will also be

listed in the Device list, along with any attached USB peripheral devices. Each device

must be connected using the Connect Device button individually, for your computer to

recognize the device.

2. After you click the Connect Device button, the status of the device will change to locally

connected, and your computer will detect the device and automatically install the required

drivers.

Notes:

• To disconnect any device, select it from the Device list and click the Disconnect

Device button.

• When connecting an audio controller, the controller becomes the default audio

device on your computer. Windows does not allow multiple audio devices to be

used simultaneously.

3. Now that your computer has installed the drivers for your display adapter, the DisplayLink

icon will appear in your Windows system tray. Close the USB Server software and click the

DisplayLink icon.

4. Once you click the icon, a menu will open. From the menu click Video Setup, to launch the

Windows display settings.

5. Use the Windows display settings to congure the monitor to your desired settings,

including resolution and orientation.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere StarTech.com Extender Handbücher

StarTech.com

StarTech.com ST12MHDLAN2K Bedienungsanleitung

StarTech.com

StarTech.com ST121UTP Bedienungsanleitung

StarTech.com

StarTech.com ST121USBHD Bedienungsanleitung

StarTech.com

StarTech.com STUTPRXL Bedienungsanleitung

StarTech.com

StarTech.com USB2001EXT2 Bedienungsanleitung

StarTech.com

StarTech.com ST121USBHD Bedienungsanleitung

StarTech.com

StarTech.com ST121DVI25 Bedienungsanleitung

StarTech.com

StarTech.com SV565DUTPU Bedienungsanleitung

StarTech.com

StarTech.com 110VDSLEXT Bedienungsanleitung

StarTech.com

StarTech.com ST121HDBTPW Bedienungsanleitung

StarTech.com

StarTech.com ST121HDBTPW Bedienungsanleitung

StarTech.com

StarTech.com WIFI2HD2 Bedienungsanleitung

StarTech.com

StarTech.com SV565LANDUA Bedienungsanleitung

StarTech.com

StarTech.com ST121HD20L Bedienungsanleitung

StarTech.com

StarTech.com SV565FXDUSA Bedienungsanleitung

StarTech.com

StarTech.com VS321HDBTK Bedienungsanleitung

StarTech.com

StarTech.com ST121HDFXA Bedienungsanleitung

StarTech.com

StarTech.com 8STUSB2001EXTV Bedienungsanleitung

StarTech.com

StarTech.com SV565UTPDUV Bedienungsanleitung

StarTech.com

StarTech.com SV565UTPUL Bedienungsanleitung

StarTech.com

StarTech.com USB2001EXTV Bedienungsanleitung

StarTech.com

StarTech.com 8STSV565HDIP Bedienungsanleitung

StarTech.com

StarTech.com C15012-USB-EXTENDER Bedienungsanleitung

StarTech.com

StarTech.com SV565UTPUSA Bedienungsanleitung

Beliebte Extender Handbücher anderer Marken

SY HDBT-60T Bedienungsanleitung

Appsys ProAudio

Appsys ProAudio ADX-16 Bedienungsanleitung

Atlona

Atlona RS232 Bedienungsanleitung

IDK

IDK OPF-TH1000-A Bedienungsanleitung

Enable-IT

Enable-IT 824WP Bedienungsanleitung

Worx

Worx Landroid RadioLink WA0864 Technisches Datenblatt

TP-Link

TP-Link TL-WA730RE Bedienungsanleitung

Camplex

Camplex CMX-HDMI-SFPL Bedienungsanleitung

SC&T

SC&T HE03-4K Bedienungsanleitung

Marmitek

Marmitek MegaView70 Bedienungsanleitung

Samsung

Samsung SCS-26UC4 Bedienungsanleitung

Foxun

Foxun SX-GES24 Bedienungsanleitung

MuxLab

MuxLab 500771 Bedienungsanleitung

foxunhd

foxunhd SX-AEX01 Bedienungsanleitung

TERK Technologies

TERK Technologies LFIRX2 Bedienungsanleitung

Devolo

Devolo Audio Extender Handbuch

Edimax

Edimax EW-7438RPn V2 Bedienungsanleitung

Shinybow USA

Shinybow USA SB-6335T5 Bedienungsanleitung
