StarTech.com SV565FXDUSA Bedienungsanleitung

KVM Console Extender

USB, DVI KVM Console

Extender with Serial and Audio

over Multi-Mode Fiber - 2km

SV565FXDUSA

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.•

Increase the separation between the equipment and receiver.•

Connect the equipment into an outlet on a circuit different from that to which the receiver•

is connected.

Consult the dealer or an experienced radio/TV technician for help.•

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company

in question. Regardless of any direct acknowledgement elsewhere in the body of

this document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Table of Contents

Introduction..................................................................... 1

Packaging Contents.....................................................................1

System Requirements .................................................................1

Front View....................................................................................2

Rear View ....................................................................................2

Installation....................................................................... 3

Preparing Your Site......................................................................3

Installing the Computer Unit ........................................................4

Installing the Console Unit...........................................................4

Driver Installation.........................................................................5

Using the KVM Extender ................................................ 6

Using the Computer Unit .............................................................6

Mask Hotkey Switch ....................................................................7

Using the Console Unit................................................................9

Serial Device Setup.....................................................................11

Fiber Cable Limitations .................................................. 11

Speciﬁcations.................................................................. 12

Technical Support........................................................... 14

Warranty Information...................................................... 14

Introduction

The StarTech.com USB, DVI, serial and audio KVM Console Extender

lets you control a server, computer or multiple computers (through a

KVM switch) over a multi-mode ﬁber link, at distances of up to 2000m

(6562 ft). By transmitting the digital DVI video (or HDMI with a DVI-to-

HDMI adapter) over a multi-mode optical ﬁber link, there is no signal

loss so the video is as sharp and vivid as it would be if the monitor was

connected directly to the PC.

Packaging Contents

1 x Computer Extender Unit•

1 x Console Extender Unit•

2 x DVI, USB and Audio KVM cable•

1 x Power Adapter•

1 x Set of rubber feet•

1 x Instruction Manual•

System Requirements

USB enabled computer or KVM switch•

DVI-D enabled computer or KVM switch•

DVI-D enabled display device•

Standard 104-key wired USB keyboard•

Standard 3-button wired USB mouse•

Multi-Mode ﬁber cable (50/125 or 62.5/125)•

Available electrical outlet at both locations•

Front View

Rear View

Selection

LED Selection

button

Serial Tx/Rx

LEDs Status

LED

Console DVI

connector

Computer DVI

connector

Console USB

keyboard/mouse

connectors

Computer 3.5mm

Audio connectors

Mask Hotkey

switch

Console

Serial port

Computer

Serial port

Computer USB

connector

SC ﬁber

connectors

Console 3.5mm

Audio connectors

Installation

Preparing Your Site

Before you can install the product, you need to prepare your site.

Determine where the1. host computer will be located and set up the

computer.

Determine where the console devices (mouse, keyboard, monitor)2.

will be located and place them appropriately.

a) If you are using surface cabling, ensure you have enough Multi-3.

Mode Fiber network cabling to connect the Computer Unit to the

Console Unit’s location, and that each end is terminated with an

SC connector. The cabling should not go through any networking

equipment (i.e. router, switch).

b) If you are using premise cabling, ensure that the Multi-Mode Fiber

network cabling between the Computer Unit and the Console Unit

has been properly terminated in a wall outlet in each location and

there is a patch cable long enough to connect the Console Unit and

the Computer Unit to their respective outlets. The cabling should not

go through any networking equipment (i.e. router, switch).

Console

Unit

Computer

Unit

*optional

Local Console

(optional)

Host computer

Remote

Console

Installing the Computer Unit

Place the1. Computer Unit near the computer that needs to be

controlled.

Switch off the computer and disconnect any connected devices.2.

OPTIONAL: If you wish to have console access locally to the Host

computer, connect a USB mouse, keyboard, and DVI monitor to the

connectors marked as “Console” on the Computer Unit.

Connect the power adapter from an AC electrical outlet to the unit.3.

Using the provided StarTech.com USB, DVI, Audio KVM cable,4.

connect the Host computer system to the KVM Extender’s

“Computer” connectors. Reconnect any necessary peripheral

devices to the Host computer, removed in Step 2.

OPTIONAL: If you wish to have the Host computer to have access to

a serial device, connect a DB9 serial cable from the Host computer to

the Computer DB9 connector (DCE) on the Computer Unit. You may

connect a serial device locally, by plugging the serial device into the

Console DB9 connector (DTE).

Connect the ﬁber cable to the SC ﬁber connectors on the5. Computer

Unit. Connect the opposite end to a terminated wall outlet (if you are

using premise cabling) or directly to the Console Unit.

Power on the6. Host computer system.

Installing the Console Unit

Place the Console Unit near the remote keyboard/mouse/display.1.

Connect a USB keyboard and mouse, and a DVI monitor to the2.

connectors marked as “Console” on the Console Unit.

OPTIONAL: If the serial connection was setup on the Computer Unit,

connect the serial device to the Console DB9 connector (DTE) on the

Console Unit.

Connect the power adapter from an AC electrical outlet to the unit.3.

Connect the ﬁber cable connection to the SC ﬁber connector on the4.

Console Unit. Connect the opposite end to a terminated wall outlet

(if using premises cabling) or directly to the Computer Unit.

OPTIONAL: If connecting a computer system to the Console Unit,

switch off the computer and disconnect any existing devices. Using

the provided StarTech.com integrated USB, DVI, Audio KVM cable,

connect the computer system to the Console Unit’s “Computer”

connectors. Reconnect any necessary peripheral devices to the Host

computer, removed previously.

Driver Installation

The KVM Extender is a complete hardware solution so no software or

driver installation is required on any computer system.

Using the KVM Extender

This section details how to use your KVM extender at both the local

and remote locations.

Using the Computer Unit

The Computer Unit allows users connected to the Computer and

Console units to share control of devices (computers, KVM Switches)

connected to it.

The Computer Unit has three modes that control which user may

access the Host system (Computer A) at a given time: Auto (the KVM

extender looks for keyboard or mouse activity from both Local and

Remote and automatically accepts input from the active console), Local

(only the user seated at the Computer Unit can access the system),

and Remote (only the user at the Console Unit can access the system).

You can use either keyboard shortcuts (if there is a keyboard and

mouse attached) or the mode switch on the front of the Computer

Unit to control which user has access to devices connected to the

Computer Unit, by pressing the button in sequence.

By default, the Computer Unit operates in Auto mode, and switches to

the next mode in sequence each time the switch is pressed as follows:

Having a keyboard and mouse attached to the Console ports on the

Computer Unit is recommended, since it offers access to a number of

extended features.

LED Indicators

Mode Local Remote

Auto (Auto senses activity) Flashing Flashing

Local (User at Computer Unit has exclusive control) On (solid) Off

Remote (User at Console Unit has exclusive control) Off On (solid)

Auto Local Remote

Keyboard Shortcut Command Sequences

Standard Command With Compatibility

Mode Enabled Description

[Ctrl] - [Ctrl] - [T] [Ctrl] - [Ctrl] - [T]

Toggles control of Computer

A between Auto, Local, and

Remote modes

[Ctrl] - [Ctrl] - [Esc] [Ctrl] - [Ctrl] - [Esc] Cancels the hotkey sequence

[Ctrl] - [Ctrl] - [Alt]+[E] [Ctrl] - [Ctrl] - [Alt]+[E]

Enables (2 beeps) or disables

(1 beep) Compatibility Mode

so that the KVM extender

will work with a KVM switch

that also uses a [Ctrl] hotkey

sequence

[Ctrl] - [Ctrl] - [1] [Ctrl] - [Ctrl] - [E] - [1]

Local Mode: Allows the user

at Computer Unit Aexclusive

access to the system; remote

access from Console Unit B

is disabled

[Ctrl] - [Ctrl] - [2] [Ctrl] - [Ctrl] - [E] - [2]

Remote Mode: Allows the

console at Console Unit B

exclusive access to Computer

A; access to the computer

from the Computer Unit is

disabled

[Ctrl] - [Ctrl] - [3] [Ctrl] - [Ctrl] - [E] - [3] Auto Mode: Wait for console

activity

Mask Hotkey Switch

The Mask Hotkey switch on the rear panel

of both the Computer and Console Units is a

feature for use when a KVM switch is being

used. Setting the switch to ON or OFF will Mask

(disable) the units built in hotkey detection,

allowing the controls keys to be sent directly to

the KVM switch.

ONOFF

Andere Handbücher für SV565FXDUSA

Inhaltsverzeichnis

Andere StarTech.com Extender Handbücher

StarTech.com

StarTech.com 410VDSLEXT Bedienungsanleitung

StarTech.com

StarTech.com SV565UTP Bedienungsanleitung

StarTech.com

StarTech.com 33FT-8K-HDMI-BOOSTER Bedienungsanleitung

StarTech.com

StarTech.com USB2004EXTGB Bedienungsanleitung

StarTech.com

StarTech.com 110VDSLEXT Bedienungsanleitung

StarTech.com

StarTech.com COMPUTPEXTA Bedienungsanleitung

StarTech.com

StarTech.com ST121USBHD Bedienungsanleitung

StarTech.com

StarTech.com STUTPRXWLA Bedienungsanleitung

StarTech.com

StarTech.com ST121DVI25 Bedienungsanleitung

StarTech.com

StarTech.com ST121HDBTPW Bedienungsanleitung

StarTech.com

StarTech.com ST122UTPA Bedienungsanleitung

StarTech.com

StarTech.com ST121UTPDVI Bedienungsanleitung

StarTech.com

StarTech.com ST121HDFXA Bedienungsanleitung

StarTech.com

StarTech.com ST121SHD30 Bedienungsanleitung

StarTech.com

StarTech.com USB2G4LEXT2 Bedienungsanleitung

StarTech.com

StarTech.com ST121WHDS Bedienungsanleitung

StarTech.com

StarTech.com 110VDSLEXT Bedienungsanleitung

StarTech.com

StarTech.com SVIDUTPEXTA Bedienungsanleitung

StarTech.com

StarTech.com VS321HDBTK Bedienungsanleitung

StarTech.com

StarTech.com ST12MHDLAN4K Bedienungsanleitung

StarTech.com

StarTech.com ST121HDBTL Bedienungsanleitung

StarTech.com

StarTech.com ST121HD20V Bedienungsanleitung

StarTech.com

StarTech.com ST121UTPMINI Bedienungsanleitung

StarTech.com

StarTech.com 4K70IC-EXTEND-HDMI Bedienungsanleitung

Beliebte Extender Handbücher anderer Marken

SY HDBT-60T Bedienungsanleitung

Appsys ProAudio

Appsys ProAudio ADX-16 Bedienungsanleitung

Atlona

Atlona RS232 Bedienungsanleitung

IDK

IDK OPF-TH1000-A Bedienungsanleitung

Enable-IT

Enable-IT 824WP Bedienungsanleitung

Worx

Worx Landroid RadioLink WA0864 Technisches Datenblatt

TP-Link

TP-Link TL-WA730RE Bedienungsanleitung

Camplex

Camplex CMX-HDMI-SFPL Bedienungsanleitung

SC&T

SC&T HE03-4K Bedienungsanleitung

Marmitek

Marmitek MegaView70 Bedienungsanleitung

Samsung

Samsung SCS-26UC4 Bedienungsanleitung

Foxun

Foxun SX-GES24 Bedienungsanleitung

MuxLab

MuxLab 500771 Bedienungsanleitung

foxunhd

foxunhd SX-AEX01 Bedienungsanleitung

TERK Technologies

TERK Technologies LFIRX2 Bedienungsanleitung

Devolo

Devolo Audio Extender Handbuch

Edimax

Edimax EW-7438RPn V2 Bedienungsanleitung

Shinybow USA

Shinybow USA SB-6335T5 Bedienungsanleitung
