USB/VGA Cat 5 UTP Long

Range Console Extender

SV565UTPUL

Instruction Manual

*actual product may vary from photos

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide rea-

sonable protection against harmful interference in a residential installation. This equip-

ment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio com-

munications. However, there is no guarantee that interference will not occur in a particu-

lar installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an en-

dorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this doc-

ument, StarTech.com hereby acknowledges that all trademarks, registered trademarks,

service marks, and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

Instruction Manual

Table of Contents

Introduction ..................................................................... 1

Features ..................................................................................1

System Requirements .............................................................1

Package Contents ...................................................................2

Connecting Your KVM Extender..................................... 3

Preparing Your Site....................................................................3

Installing the Host Unit .............................................................4

Installing the Remote Unit ........................................................5

Mask Hotkey Switch ..................................................................5

Video Calibration (Remote Unit only) ........................... 6

Using the KVM Extender ................................................ 8

Using the Host Unit ...................................................................8

Using the Remote Unit..............................................................12

Alternative Hot-Key Control......................................................14

Speciﬁcations.................................................................. 15

RJ-45 Connector Pinout ..........................................................15

Accessory Products from StarTech.com ...................... 16

Technical Support........................................................... 17

Warranty Information...................................................... 17

Instruction Manual

Introduction

Thank you for purchasing a StarTech.com KVM extender. This product

allows a computer to control a host system from a remote location

at a distance of up to 984 feet (300 meters). For ease of installation,

this product uses standard Category 5, 5E, or 6 network cabling that

ﬁts easily into almost any existing network infrastructure. For added

versatility, the KVM extender supports either PS/2 or USB computer

interfaces. Console support is provided using standard USB and VGA

connectors.

Features

• Can be used with a single computer or connected to an existing KVM

switch

• Easy installation using industry-standard UTP network cable

• Intuitive hotkey commands

• Supports auto-switching between host and remote users or dedicated

control

• USB computers are supported at the host and remote locations (USB

keyboard and mouse required for remote console)

System Requirements

• 1 x StarTech.com integrated KVM cable for each, the host (included)

and remote (optional) computer connections. If necessary,

longer cables are available, StarTech.com ID: SVECONx (PS/2),

SVECONUSx (USB)

• Unshielded Category 5/5e/6 twisted pair (UTP) straight-through

network cable terminated at each end with RJ-45 connectors (if using

surface cabling)

• Unshielded Category 5/5e/6 twisted pair (UTP) straight-through

network cable terminated at each end in a wall-mounted outlet, with a

standard Category 5/5e/6 patch cable, at both locations (if using

premises cabling)

NOTE: The total length of cable between the Host and Remote Units

Instruction Manual

cannot exceed 984 feet (300 meters), including patch cables (if used).

Category 5e and 6 cabling is compatible with this product and may

improve performance.

NOTE: Long cable lengths between the Host and Remote Units may

adversely affect image quality at high resolutions and refresh rates. If you

need to run your remote displays at high resolutions and frequencies, use

as little cabling between locations as possible and avoid practices such as

“coiling” unused cable in a ceiling.

This product will also control a KVM switch, allowing you to manage more

than one computer remotely. In this conﬁguration, you can connect the

KVM extender’s Host Unit to the “console” ports on the KVM. You must

use the provided power adapters if using this conﬁguration. You should

set the Host Unit to Compatibility Mode before connecting it to a KVM that

uses the [Ctrl] key as its hotkey sequence; see page 8 for details.

Package Contents

1 x Host Unit

1 x Remote Unit

1 x Instruction Manual

1 x Power adapter

2 x 6 ft. 2-in-1 USB VGA KVM cable

2 x Set of rubber mounting feet

Instruction Manual

Connecting Your KVM Extender

Preparing Your Site

Before you can install the product, you need to prepare your site.

1. Determine where the Host computer will be located and set up the

computer.

2. Determine where the console devices (mouse, keyboard, monitor) will

be located and place them appropriately.

3. a) If you are using surface cabling, ensure you have enough Category

5 unshielded twisted pair (UTP) network cabling to connect the Host

Unit to the Remote Unit’s location, and that each end is terminated with

a RJ-45 connector. The cabling should not go through any networking

equipment (i.e. router, switch).

b) If you are using premises cabling, ensure that the Category 5

unshielded twisted pair (UTP) network cabling between the Host Unit

and the Remote Unit has been properly terminated in a wall outlet in

each location and there is a patch cable long enough to connect the

Remote Unit and the Host Unit to their respective outlets. The cabling

should not go through any networking equipment (i.e. router, switch).

Instruction Manual

Installing the Host Unit

1. Place the Host Unit near the Host computer system.

2. Switch off the computer and disconnect any connected devices.

3. Using the provided StarTech.com integrated KVM cable (see page 16

for alternative part numbers), connect the end of the cable that has two

(USB) or three (PS/2 + VGA) connectors to the VGA Out connector

and the USB or mouse and keyboard PS/2 connectors on the Host

computer as appropriate. (The PS/2 version of the cable is color-

coded). Connect the opposite end of the cable with a single connector

to the gray-coded connector marked COMPUTER on the Host Unit of

the KVM extender.

4. If you wish to have local console access to the host computer, connect

a USB mouse, keyboard, and VGA monitor to the indicators marked as

CONSOLE on the Host Unit.

5. Connect the UTP cable connection for the Remote Unit to the

NETWORK RJ-45 connector on the Host Unit. Connect the opposite

end to a terminated wall outlet (if you are using premises cabling) or

run it directly to the Remote Unit.

NOTE: The Host Unit can draw power from the Host computer system. If

it cannot draw sufﬁcient power from the Host computer, however, a power

adapter (not included) may be required.

1 to 2

Control Direction

UTP Cable

Computer

BConsole Computer

AConsole

Remote Unit

(optional)

Host Unit (Local)

Instruction Manual

Installing the Remote Unit

1. Place the Remote Unit near the remote keyboard/mouse/monitor setup.

2. Connect the USB mouse, keyboard, and a VGA monitor to the

indicators marked as CONSOLE on the Remote Unit.

OPTIONAL: If connecting a computer system directly to the Remote

Unit, switch off the computer and disconnect any existing VGA and input

connections. Using a StarTech.com integrated KVM cable (see page 16

for part numbers), connect the end of the cable that has two (USB) or

three (PS/2) connectors to the VGA Out connector and the USB or mouse

and keyboard PS/2 connectors on the computer as appropriate. (The

PS/2 version of the cable is color-coded.) Connect the opposite end of

the cable with a single connector to the gray-coded connector marked

COMPUTER on the Remote Unit of the KVM extender.

3. Connect the UTP cable connection for Remote Unit to the NETWORK

RJ-45 connector on the Remote Unit. Connect the opposite end to a

terminated wall outlet (if using premises cabling).

4. Connect the power adapter from an electrical outlet to the Remote Unit.

CAUTION: The UTP network cables that connect the Host

and Remote Units carry electrical current and should not

be plugged in to other devices, as they may cause damage.

We strongly recommend marking the cables you are using

with this product at both locations for easy identiﬁcation.

Mask Hotkey Switch

The Mask Hotkey switch on the rear panel of both

the Host and Remote Units is a feature for use

when a KVM switch is being used. Setting the

switch to ON or OFF will Mask (disable) the units

built in hotkey detection, allowing the controls keys

to be sent directly to the KVM switch.

ONOFF

Instruction Manual

Video Calibration (Remote Unit only)

Video Calibration allows the user to adjust the equalization, gain and

RGB skew on the Remote Unit to optimize video performance based on

the length of the UTP cable being used, as well as other factors that may

affect the signal.

There are 16 levels of coarse tuning and up to 128/256 scales of

ﬁne tuning available for adjustment of the equalizer and gain. Skew

adjustment for red, green and blue colour channels come in 8 levels of

coarse adjustment and 16/32 scales of ﬁne adjustment.

NOTE: Video Calibration is only available when the UTP cable is

connected and the Remote unit has control of the Host computer system.

Before Video Calibration

After Video Calibration

Instruction Manual

To enter Video Calibration Mode:

left [CTRL] - left [CTRL] - [F11]

To enter Video Calibration Mode while in Compatibility Mode:

left [CTRL] - left [CTRL] - [E] - [F11]

When in Video Calibration mode, the Num Lock and Scroll Lock LEDs

on the keyboard will ﬂash simultaneously. Video calibration can now be

performed. Refer to the table for the different adjustment options.

Hotkey Description

[E]

Equalizer Adjustment (Sharpness):

•Num Lock and Caps Lock LEDs will ﬂash.

•Press the left or right arrow keys for coarse tuning.

•Press and hold [SHIFT] and use the left and right arrow

keys for ﬁne tuning.

Gain Adjustment (Brightness):

•Caps Lock and Scroll Lock LEDs will ﬂash.

•Press the up or down arrow keys for coarse tuning.

•Press and hold [SHIFT] and use the up or down arrow

keys for ﬁne tuning.

[R]

Red Skew Adjustment:

•Num Lock LED will ﬂash.

•Press the left or right arrow keys for coarse tuning.

•Press and hold [SHIFT] and use the left and right arrow

keys for ﬁne tuning.

[G]

Green Skew Adjustment:

•Caps Lock LED will ﬂash.

•Press the left and right arrow keys for coarse tuning.

•Press and hold [SHIFT] and use the left and right arrow

keys for ﬁne tuning.

[B]

Blue Skew Adjustment:

•Scroll Lock LED will ﬂash.

•Press the left and right arrow keys for coarse tuning.

•Press and hold [SHIFT] and use the left and right arrow

keys for ﬁne tuning.

[ESC] Exit Video Calibration mode. There is also a 30 sec.

timeout based on keyboard input.

Andere Handbücher für SV565UTPUL

Inhaltsverzeichnis

Andere StarTech.com Extender Handbücher

StarTech.com

StarTech.com IPUSB2HD3 Bedienungsanleitung

StarTech.com

StarTech.com ST121HDBTL Bedienungsanleitung

StarTech.com

StarTech.com ST121DVI25 Bedienungsanleitung

StarTech.com

StarTech.com ST121R Bedienungsanleitung

StarTech.com

StarTech.com 110VDSLEXT Bedienungsanleitung

StarTech.com

StarTech.com HDBOOST4K Bedienungsanleitung

StarTech.com

StarTech.com HDBOOST4K2 Bedienungsanleitung

StarTech.com

StarTech.com SV565UTPUSA Bedienungsanleitung

StarTech.com

StarTech.com ST122UTPAGB Bedienungsanleitung

StarTech.com

StarTech.com USBthere USB204EXTFIB Bedienungsanleitung

StarTech.com

StarTech.com WIFI2VGA Bedienungsanleitung

StarTech.com

StarTech.com ST121UTP232 Bedienungsanleitung

StarTech.com

StarTech.com USBthere USB110EXT Bedienungsanleitung

StarTech.com

StarTech.com ST122UTPAL Bedienungsanleitung

StarTech.com

StarTech.com ST121UTPEP Bedienungsanleitung

StarTech.com

StarTech.com USBthere USB204EXT Bedienungsanleitung

StarTech.com

StarTech.com ST121UTPHD2 Bedienungsanleitung

StarTech.com

StarTech.com 33FT-8K-HDMI-BOOSTER Bedienungsanleitung

StarTech.com

StarTech.com USB2004EXT100 Bedienungsanleitung

StarTech.com

StarTech.com ST121SHD30 Bedienungsanleitung

StarTech.com

StarTech.com ST121R Bedienungsanleitung

StarTech.com

StarTech.com 410VDSLEXT2 Bedienungsanleitung

StarTech.com

StarTech.com SV565FXDUSA Bedienungsanleitung

StarTech.com

StarTech.com IREXT2 Bedienungsanleitung

Beliebte Extender Handbücher anderer Marken

SY HDBT-60T Bedienungsanleitung

Appsys ProAudio

Appsys ProAudio ADX-16 Bedienungsanleitung

Atlona

Atlona RS232 Bedienungsanleitung

IDK

IDK OPF-TH1000-A Bedienungsanleitung

Enable-IT

Enable-IT 824WP Bedienungsanleitung

Worx

Worx Landroid RadioLink WA0864 Technisches Datenblatt

TP-Link

TP-Link TL-WA730RE Bedienungsanleitung

Camplex

Camplex CMX-HDMI-SFPL Bedienungsanleitung

SC&T

SC&T HE03-4K Bedienungsanleitung

Marmitek

Marmitek MegaView70 Bedienungsanleitung

Samsung

Samsung SCS-26UC4 Bedienungsanleitung

Foxun

Foxun SX-GES24 Bedienungsanleitung

MuxLab

MuxLab 500771 Bedienungsanleitung

foxunhd

foxunhd SX-AEX01 Bedienungsanleitung

TERK Technologies

TERK Technologies LFIRX2 Bedienungsanleitung

Devolo

Devolo Audio Extender Handbuch

Edimax

Edimax EW-7438RPn V2 Bedienungsanleitung

Shinybow USA

Shinybow USA SB-6335T5 Bedienungsanleitung
