StarTech.com PCI1S950DV Bedienungsanleitung

16950 RS-232 Dual Voltage / Dual Profile Serial Card

PCI1S950DV

PCI2S950DV

Instruction Manual

Actual product may vary from photo

1 Port PCI 16950 RS-232 Dual Voltage / Dual Profile Serial Card

2 Port PCI 16950 RS-232 Dual Voltage / Dual Profile Serial Card

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd

ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and

do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company in

question. Regardless of any direct acknowledgement elsewhere in the body of this

document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

TTaabblleeooffCCoonntteennttss

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installing the Serial card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Installing the drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Maximize data transfer rates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Accessory Products from StarTech.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Instruction Manual

IInnttrroodduuccttiioonn

Thank you for purchasing a StarTech.com 16950 RS-232 Dual Voltage Serial Card. This

PCI I/O card allows you use DB-9 cables to connect various serial devices, to any

computer with an available PCI expansion slot.

FFeeaattuurreess

• Two high performance 16C950 UART channels

• Maximum data transfer rate of 460 Kbps

• PCI 2.2 and PCI Power Management 1.0 compliant

• 128-byte deep FIFO per transmitter and receiver

• Automated in-band software flow control using programmable Xon/Xoff in both

directions

• Automated out-of-band hardware flow control using RTS / CTS and/or DSR / DTR

BBeeffoorreeYYoouuBBeeggiinn

System Requirements

• A computer with an available PCI port

• A computer running Windows NT4, 95 / 98 / ME / 2000 / XP, and Linux

• A CD-ROM, DVD-ROM, or other compatible optical drive (for software installation)

• Pentium class PC or higher with an available PCI or PCI-X slot

• A standard DB9-M Serial Cable for each port (Please see Accessory Products)

Contents

This package should contain:

• PCI / PCI-X Serial Card (1)

• Low Profile Bracket (1)

• Instruction Manual (1)

• Driver CD (1)

Instruction Manual

IInnssttaallllaattiioonn

Installing the Serial Card

1. Shut down all power connected to the computer, as well as all devices connected to

the computer peripherally (i.e. Printers, Monitors, Scanners etc.). As an added step to

ensure safe installation, unplug the power supply from the computer.

2. Remove the computer cover. For more detailed instruction on how to perform this

step, please refer to the documentation that was included with your computer at the

time of purchase.

3. Locate an empty PCI slot, removing the metal bracket covering the accompanying

empty port/socket.

4. Position the serial card above the open PCI slot, ensuring that the card is aligned with

the entire slot. Insert the card firmly into the slot, distributing force evenly across the

length of the board. Once inserted, secure the card into the adjoining socket

(previously covered by metal bracket), using the correct size screw (please consult

documentation that accompanied purchase of computer).

5. Replace the computer cover and re-connect all power to the computer.

Installing the drivers

Windows

Upon rebooting the computer for the first time following the installation of the serial card,

Windows will notify you that new hardware has been detected. At this time, you will be

prompted for driver installation.

1. Select Install from a specific location, insert the Driver CD and click Next.

Instruction Manual

2. At the screen that follows, select

Search for the best drivers in

these locations, and place a

checkmark next to Include this

location in the search. Ensure

that the proper file path has been

specified, then click Next.

Instruction Manual

4. Windows will then

proceed with installing the

serial card. When

complete, you will be

notified that the wizard

has finished installation.

Please click Finish.

3. Windows will then notify you that

the software being installed has

not passed the Windows Logo

testing process. Please

disregard this warning, and click

Continue Anyway:

New port

Adapter

5. Once the card has been installed, Windows will require that the same steps be

followed in order to install the serial ports. As such, to complete installation, please

repeat steps #1-4. For PCI2S950DV, the second serial port will require installation,

which will automatically launch following installation of the first port. As such, if you

are installing PCI2S950DV, you will be required to follow steps #1-4 a third time.

6. Following installation,

please right-click on My

Computer, and click

Manage. Click on

Device Manager to view

installed components.

Here, you will find the

newly installed adapter

and ports:

Please note: PCI2S950DV

installation will result in two

ports being displayed in

Device Manager

Maximize data transfer rates

Once installation is complete, you will be able to configure the port(s) provided by the

card, as you would any other serial port. To do so, browse through the following path:

Start > Control Panel > System > Hardware (tab) > Device Manager

To maximize the port data transfer capability, right-click on one of the newly installed

ports, and select Properties. Once the Properties window opens, click on the Data Rate

tab. Here you will see a button labelled Detect Crystal Frequency. Click on the button

to automatically detect the port data transfer capability. Please note that while

PCI1S950DV only requires one such configuration, PCI2S950DV will require

configuration for each separate port.

Instruction Manual

SSppeecciiffiiccaattiioonnss

AAcccceessssoorryyPPrroodduuccttssffrroommSSttaarrTTeecchh..ccoomm

Contact your local StarTech.com dealer or visit www.startech.com for cables or other

accessories that will help you get the best performance out of your new product.

MC3MF

3 ft. AT Modem Cable DB9F-DB25M

MC6MF

6 ft. AT Modem Cable (male to female)

MXT100

6 ft. 9-pin Straight Through Cable (male to female)

MXT100_25

25 ft. 9-pin Straight Through Cable (male to female)

AT925FF

Adapter DB9F to DB25F

AT925FM

Adapter DB9F to DB25M

AT925SFM

Slimline Adapter DB9F to DB25M

SCNM925FM

10 ft. Cross Wired Serial/Null Modem Cable DB9F to DB25M

SCNM9FF

10 ft. Cross Wired Serial/Null Modem Cable DB9 F/F

SCNM9FF25

25 ft. Cross Wired Serial/Null Modem Cable DB9 F/F

SCNM9FM

10 ft. Cross Wired Serial/Null Modem Cable DB9 F/M

MXT100FF

6 ft. Modem Cable DB9F-DB9F

Instruction Manual

Bus Type PCI 5V / PCI-X 3.3V

Connectors

PCI1S950DV - 1 x DB9 Male RS-232 Serial Connector

PCI2S950DV - 2 x DB9 Male RS-232 Serial Connector

Data Transfer Rate (Max.) 460 Kbps

Chipset OX16PCI952

OS Support Supports Windows NT4, 95 / 98 / ME / 2000 / XP, and Linux

TTeecchhnniiccaallSSuuppppoorrtt

StarTech.com’s lifetime technical support is an integral part of our commitment to provide

industry-leading solutions. If you ever need help with your product, visit

www.startech.com/support and access our comprehensive selection of online tools,

documentation, and downloads.

WWaarrrraannttyyIInnffoorrmmaattiioonn

This product is backed by a lifetime warranty. In addition, StarTech.com warrants its

products against defects in materials and workmanship for the periods noted, following

the initial date of purchase. During this period, the products may be returned for repair, or

replacement with equivalent products at our discretion. The warranty covers parts and

labor costs only. StarTech.com does not warrant its products from defects or damages

arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their

officers, directors, employees or agents) for any damages (whether direct or indirect,

special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,

or any pecuniary loss, arising out of or related to the use of the product exceed the

actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in this statement

may not apply to you.

Instruction Manual

Revised: 17 November 2006 (Rev. A)

AAbboouuttSSttaarrTTeecchh..ccoomm

StarTech.com is “The Professionals’ Source for Hard-to-Find Computer

Parts”. Since 1985, we have been providing IT professionals with the

quality products they need to complete their solutions. We offer an

unmatched selection of computer parts, cables, server management

solutions and A/V products and serve a worldwide market through our

locations in the United States, Canada, the United Kingdom and Taiwan.

Visit www.startech.com for complete information about all our products

and to access exclusive interactive tools such as the Parts Finder and the

KVM Reference Guide. StarTech.com makes it easy to complete almost

any IT solution. Find out for yourself why our products lead the industry in

performance, support, and value.

Andere Handbücher für PCI1S950DV

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere StarTech.com PCI-Karte Handbücher

StarTech.com

StarTech.com PCI2S232485I Bedienungsanleitung

StarTech.com

StarTech.com PEXUSB311A1C Bedienungsanleitung

StarTech.com

StarTech.com PCIUSB7 Bedienungsanleitung

StarTech.com

StarTech.com PEX1TO16R Bedienungsanleitung

StarTech.com

StarTech.com 8P6G-PCIE-SATA-CARD Bedienungsanleitung

StarTech.com

StarTech.com PCIIDE2 Bedienungsanleitung

StarTech.com

StarTech.com PCISOUND5LP Bedienungsanleitung

StarTech.com

StarTech.com PEX1000MMSC Bedienungsanleitung

StarTech.com

StarTech.com PEXUSB312C3 Bedienungsanleitung

StarTech.com

StarTech.com PEX2S5521P Bedienungsanleitung

StarTech.com

StarTech.com PEXSATA22I Bedienungsanleitung

StarTech.com

StarTech.com PEX1000SFP2 Bedienungsanleitung

StarTech.com

StarTech.com PCI2S1P2 Bedienungsanleitung

StarTech.com

StarTech.com PCI1PM Bedienungsanleitung

StarTech.com

StarTech.com PEX4M2E1 Bedienungsanleitung

StarTech.com

StarTech.com PEXUSB311AC2 Bedienungsanleitung

StarTech.com

StarTech.com PCI420USB Bedienungsanleitung

StarTech.com

StarTech.com PEX4S952 Bedienungsanleitung

StarTech.com

StarTech.com PEX1P Bedienungsanleitung

StarTech.com

StarTech.com PCI1S550 Bedienungsanleitung

StarTech.com

StarTech.com PEXUSB3S4V Bedienungsanleitung

StarTech.com

StarTech.com PCIESATA2I Bedienungsanleitung

StarTech.com

StarTech.com USB2HDCAPM Bedienungsanleitung

StarTech.com

StarTech.com PEXUS313AC2V Bedienungsanleitung

Beliebte PCI-Karte Handbücher anderer Marken

ERMA

ERMA SSI 1417 Bedienungsanleitung

SIIG

SIIG CyberSerial Dual PCI Montageanleitung

Moxa Technologies

Moxa Technologies CP-102E Bedienungsanleitung

I-Bus

I-Bus IBC2602 Bedienungsanleitung

Exsys

Exsys EX-60102 Bedienungsanleitung

Chelsio Communications

Chelsio Communications T5 Series Bedienungsanleitung

Conrad Electronic

Conrad Electronic 97 46 71 Bedienungsanleitung

Micro Innovations

Micro Innovations USB650A Bedienungsanleitung

KTI Networks

KTI Networks KF-310 Bedienungsanleitung

Asus

Asus SpaceLink WL230 Bedienungsanleitung

SIIG

SIIG SC2475 Bedienungsanleitung

TRENDnet

TRENDnet TEW-703PI Bedienungsanleitung

Belkin

Belkin F5D7000F Bedienungsanleitung

Pericom

Pericom PI7C7100 Bedienungsanleitung

ADLINK Technology

ADLINK Technology cPCI-3548 Bedienungsanleitung

Digium

Digium TE200 Series Bedienungsanleitung

Allo.com

Allo.com 2nd Gen E1/T1/J1 Bedienungsanleitung

Western Digital

Western Digital FireWire PCI Adapter Bedienungsanleitung
