StarTech.com PEX1394B3 Bedienungsanleitung

Manual Revision: 04/07/2011

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

For the most up-to-date information, please visit: www.startech.com

PEX1394B3

3 Port 1394 PCI Express FireWire Card

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment

o and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit dierent from that to which the receiver is

connected.

Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected

names and/or symbols of third-party companies not related in any way to StarTech.com.

Where they occur these references are for illustrative purposes only and do not represent an

endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to

which this manual applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges

that all trademarks, registered trademarks, service marks, and other protected names and/or

symbols contained in this manual and related documents are the property of their respective

holders.

Instruction Manual i

Table of Contents

Introduction .......................................................................................................................................................1

Features...........................................................................................................................................................1

Before You Begin..............................................................................................................................................1

System Requirements ............................................................................................................................1

Contents.........................................................................................................................................................1

Installation............................................................................................................................................................2

Installing the PCI Express Cardd.......................................................................................................2

Driver Installation......................................................................................................................................2

Windows 2000/XP ..........................................................................................................................2

Windows Vista ...................................................................................................................................3

Connecting devices to the card ......................................................................................................3

Specications.....................................................................................................................................................4

Technical Support...........................................................................................................................................5

Warranty Information....................................................................................................................................5

Instruction Manual 1

Introduction

Thank you for purchasing a StarTech.com 3 Port PCI-E 1394b FireWire 800 Card. The perfect

solution for connecting portable hard drives, DV camcorders, digital cameras and more,

PEX1394B3 allows you to connect up to three FireWire 800 peripherals for fast,

hot-swappable operation.

Features

• 1394 OHCI Specication 1.1 compliant

• Supports maximum data transfer rate of 800 Mbps

• Provides hot-swappable connectivity for FireWire 800 peripherals

Before You Begin

System Requirements

• An available PCI Express slot

• Operating system requirements: 2000/XP/Vista/7 and Linux and Mac OS X and up

Package Contents

This package shoudl contain:

• 1 x PCI Express FireWire Card

• 1 x Instruction Manual

• 1 x Low Prole Bracket

• 1 x FireWire Cable

• 1 x Software CD

Instruction Manual 2

Installation

Installing the PCI Express card

1. Make sure that your system is unplugged and that you are grounded.

2. Remove the cover of your system (see your computer's user manual for details, if necessary)

and gently turn your computer onto its side, so that the PCI Express expansion slot

openings on the motherboard are facing upwards.

3. Locate an empty PCI Express slot and remove the metal plate that covers the corresponding

rear bracket.You may need a Phillips screwdriver to perform this step.

Retain the screw! You will need it to secure the card later.

4. Gently insert the card into the empty slot, making sure it is rmly seated.

5. Secure the card in place using the screw you removed in Step 3.

6. Replace and secure the computer cover.

Driver installation

Once the PCI Express card has been installed, it is safe to power up the computer. The operating

system will detect the presence of the card and automatically install the necessary software:

Windows 2000/XP

You will notice the following taskbar message balloons, indicating the status of the installation:

To verify that installation was successful:

1. From the main desktop, right-click on My Computer and select Manage to open the

Computer Management window.

2. In the left pane, click on Device Manager.

3. In the right pane, click on IEEE 1394 Bus Host Controller, under which you should notice

AGERE OHCI Compliant IEEE 1394 Host Controller listed. This conrms that the card was

successfully installed, and is ready for use.

Instruction Manual 3

Windows Vista/7

You will notice the following taskbar message balloons, indicating the status of the installation;

specically that the device driver software was installed successfully:

To verify that installation was successful:

1. Right-click on Computer and select Manage to open the Computer Management window.

2. In the left pane, click on Device Manager.

3. In the right pane, click on IEEE 1394 Bus Host Controller, under which you should notice

AGERE OHCI Compliant IEEE 1394 Host Controller listed. This conrms that the card was

successfully installed, and is ready for use.

Connecting devices to the card

Once the card and necessary software have been installed on the host computer, FireWire

devices can be connected to the ports provided by the card, by simply inserting the cable or

connector provided by the device to one of the three ports now available. This can be performed

whether the computer is powered or not, as the card supports FireWire hot-pluggability

Instruction Manual 4

Specications

Regulatory Certications FCC, CE, ROHS

Bus Type 1394B PCI Express Card

Connectors 2 x FireWire 800 9 Pin Female

1 x FireWire 6 Pin Female

Maximum Data Transfer Rate 800Mbps

Chipset Agere system FW643

OS Support Windows 2000/XP/Vista/7, Linux

MAC OS X and above

Instruction Manual 5

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commit-ment to provide

industry-leading solutions. If you ever need help with your product, visit www.startech.com/

support and access our comprehensive selection of online tools, documentation,

and downloads.

Warranty Information

This product is backed by a lifetime warranty.

In addition, StarTech.com warrants its products against defects in materials and workmanship for

the periods noted, following the initial date of purchase. During this period, the products may

be returned for repair, or replacement with equivalent products at our discretion. The warranty

covers parts and labor costs only. StarTech.com does not warrant its products from defects or

damages arising from misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers,

directors, employees or agents) for any damages (whether direct or indirect, special, punitive,

incidental, consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss,

arising out of or related to the use of the product exceed the actual price paid for the product.

Some states do not allow the exclusion or limitation of incidental or consequential damages. If

such laws apply, the limitations or exclusions contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.

StarTech.com is your one-stop source for every connectivity part you need. From

the latest technology to legacy products — and all the parts that bridge the old

and new — we can help you nd the parts that connect your solutions.

We make it easy to locate the parts, and we quickly deliver them wherever they

need to go. Just talk to one of our tech advisors or visit our website. You’ll be

connected to the products you need in no time.

Visit www.startech.com for complete information on all StarTech.com products

and to access exclusive resources and time-saving tools.

StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology

parts. StarTech.com was founded in 1985 and has operations in the United States,

Canada, the United Kingdom and Taiwan servicing a worldwide market.
