StarTech.com PEX2ECOP Bedienungsanleitung

Introduction

Thank you for purchasing a StarTech.com PCI

Express to ExpressCard Adapter. This product

allows you to use an ExpressCard with your PCI

Express enabled PC.

Features

• Supports both 34 and 54 form factor

ExpressCards

• Compliant with PCI Express Base Spec.1.0a

• Works with PCI Express slots that provide

3.3V and 1.5V auxiliary power

System Requirements

• PC with an available PCI Express slot

• Windows 2000/XP/2003 Server

Package Contents

• PCI Express to ExpressCard Adapter (1)

• Low Profile Bracket (1)

• 3’ 5-pin Header USB Cable (1)

• User Manual (1)

HHaarrddwwaarreeIInnssttaallllaattiioonn

PPEEXX22EECCDDPPUUsseerrMMaannuuaall

DDuuaallPPrrooffiilleePPCCIIEExxpprreessssttooEExxpprreessssCCaarrddAAddaapptteerr

Please note: Please note: Although PEX2ECDP supports both USB and PCI Express-based

ExpressCards, only USB-based cards offer hot-swappable connectivity. As such, please

consult the documentation that was included with your purchase of the intended

ExpressCard, to determine whether or not it supports hot-swapping.

1. Make sure that your computer system is unplugged and that you are grounded.

2. Remove the cover of your system (see your computer's user manual for details, if necessary) and

gently turn your computer onto its side, so that the PCI Express expansion slot openings on the

motherboard are facing upwards.

3. Locate an empty PCI Express slot and remove the metal plate that covers the corresponding rear

bracket. You may need a Phillips screwdriver to perform this step. Retain the screw! You will need it to

secure the card later.

4. Gently insert the card into the empty slot, making sure it is firmly seated.

5. Secure the card in place using the screw you removed in Step 3.

6. Connect the 5-pin header provided by PEX2ECDP to an available USB header on the host computer,

noting the following diagram. Once complete, replace the cover and power on the computer.

USB

+5V

USB

D+

USB

D-

Signal

Ground

Please note: If the motherboard does not have a USB header available for connection, please connect

the USB Type ‘B’ connector provided by PEX2ECDP to an available USB port connected to the mother-

board. Failing this, hot-plugging will not be available for inserted cards.

SSppeecciiffiiccaattiioonnss

Support, Warranty Information, and Regulatory Compliance

Statement

If you ever need help with your product, visit www.startech.com/sup-

port and access our comprehensive selection of online tools, docu-

mentation, and downloads. This product is backed by a lifetime war-

ranty. In addition, StarTech.com warrants its products against defects

in materials and workmanship for the periods noted, following the ini-

tial date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion.

The warranty covers parts and labor costs only. StarTech.com does not

warrant its products from defects or damages arising from misuse,

abuse, alteration, or normal wear and tear.

Limitation of Liability: In no event shall the liability of StarTech.com

Ltd. and StarTech.com USA LLP (or their officers, directors, employees

or agents) for any damages (whether direct or indirect, special, puni-

tive, incidental, consequential, or otherwise), loss of profits, loss of

business, or any pecuniary loss, arising out of or related to the use of

the product exceed the actual price paid for the product. Some states

do not allow the exclusion or limitation of incidental or consequential

damages. If such laws apply, the limitations or exclusions contained in

this statement may not apply to you.

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interfer-

ence to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which

can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the fol-

lowing measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

PPiinnHHeeaaddeerrss

PEX2ECDP offers several control/status pins:

Label Signal Name Signal description

GND GND Signal ground

CKE CLKEN Clock Enable

OC OC# Over current status

SHD SHDN# Shut down control input.

Slow down to Hi-Z mode

STB STANDBY# Standby control input

KRQ CLKRQ# Clock Request from

device

CUB CPUSB# USB device present

status

CPE CPPE# PCI Express device

present status

***Please note:

1.Signal denoted with “#” indicates “low

active”.

2. All signals either have IC internal pull-

up or on-board pull-up

LLEEDDDDeessccrriippttiioonnss

1234

Green - D1 (3.3 Vout)

Yellow - D3 (1.5 Vout)

Green - D2 (Vaux)

Red - D4 (Over current)

Bus Type PCI Express

Form Factor 34 and 54 ExpressCard

Connectors

1 x 34/54 ExpressCard Slot

1 x Internal USB Type B Port

1 4-pin USB header

Regulatory Certifications FCC, CE, ROHS

Revision A: October 11, 2007
