USE & CARE GUIDE

PRO 48 Refrigeration

Important Note

To ensure the safe and efficient use of Sub-Zero equip-

ment, please take note of the following types of highlighted

information throughout this guide:

IMPORTANT NOTE highlights information that is especially

important.

CAUTION signals a situation where minor injury or product

damage may occur if instructions are not followed.

WARNING states a hazard that may cause serious injury or

death if precautions are not followed.

Contents

PRO 48 Refrigeration ............................ 3

PRO 48 Features ................................ 4

PRO 48 Models ................................. 5

PRO 48 Use & Care .............................. 6

Keeping Food at Its Best ........................ 15

Food Storage Recommendations ................. 19

Water Filtration System Data ..................... 25

California Certification .......................... 26

Troubleshooting Guide .......................... 27

Service Information ............................. 30

Sub-Zero Warranty ............................. 31

Features and specifications are subject to change at any time

without notice. Visit our website, subzero.com for the most

up-to-date information.

PRO 48 Refrigeration 3

subzero.com

Thank You

Thank you for purchasing your new Sub-Zero PRO 48 unit.

With Sub-Zero, you can rely on a 60-year tradition of

quality and reliability.

Built in to cabinetry or freestanding, the PRO 48 is just

the latest example of Sub-Zero pushing food preservation

to new heights. And of course, the PRO 48 meets rigorous

Department of nergy standards for residential use.

Featuring a glass door on model 648PROG or top-to-

bottom stainless steel on model 648PRO. The PRO 48

brings together the latest technology and finest features in

home refrigeration to give you the freshest food possible.

Your Sub-Zero is protected by a warranty that is one of

the finest in the industry. Take a moment to read the

warranty statement at the end of this guide and refer to it

should service become necessary.

This use & care guide will answer most of your questions

about the features, operation and maintenance of your

PRO 48 unit. If you have questions that are not addressed

here, call Sub-Zero customer care at 800-222-7820 or visit

our website, subzero.com.

Dual Refrigeration

The PRO 48 continues the Sub-Zero tradition of superior

quality and reliability. Sub-Zero pioneered the develop-

ment of our dual refrigeration system, giving you optimum

fresh and freezer food storage in ideal self-contained

sections. Both refrigerator and freezer maintain accurate,

consistent temperatures. Dual refrigeration keeps your

food fresh longer than any other system available.

With dual refrigeration, the freezer maintains a constant

temperature within one degree of the temperature you set

within our range of -5°F (-21°C) to +5°F (-15°C), without

unwanted moisture and odor from the refrigerator. Simi-

larly, you can adjust the refrigerator temperature within a

range of 34°F (1°C) to 45°F (7°C), for proper humidity levels

tailored for longer food life expectancy.

The dual refrigeration system also means there is no

transfer of fresh food odors to frozen food or ice. The

Sub-Zero system does not freeze the moisture out of the

air in the fresh food section.

Sub-Zero dual refrigeration is also more energy efficient

than old-fashioned single refrigeration systems. When the

refrigerator is used frequently during the day it does not

require the freezer to circulate its very cold, dry air to the

refrigerator. Instead, the refrigerator uses moist air to keep

fresh foods fresh and energy use minimal.

PRO 48 Features 4

PRO 48 Features

•Can be built in or, with the freestanding accessory kit,

used in a freestanding application.

•Stainless steel construction, inside and out, for profes-

sional strength and beauty.

•Dual refrigeration system with two compressors and

three evaporators keep foods fresher longer and

prevent odor transfer.

•Microprocessor with up-front touch controls monitor

pattern-sensing defrost and automatic service alerts.

•xterior temperature displays with easy-to-read digital

readout are accurate within one degree of your preset

temperatures.

•Triple-pane, UV-resistant glass door (model 648PROG).

•L D lights bathe upper compartments in a soft glow.

Channeled sidewall L Ds on the refrigerator side can

serve as a door area night light (model 648PROG).

•Auto-close system with an advanced hinge design lets

doors finish closing easily and automatically.

•Adjustable shelves are cantilevered and spill-proof,

with stainless steel trim (refrigerator) and 100%

stainless steel (freezer).

•Removable, slide-out stainless steel bins hold small

items and fit neatly under any shelf.

•Touch-and-glide crisper drawer with a tight-sealing

clear cover gives vegetables generous humidity.

•Storage drawers allow full access to food with

adjustable, removable and interchangeable dividers.

•Automatic ice maker with advanced water filtration

system for ice as pure as it is fresh.

•asy-access grille flips up, without tools, to access the

water filter for replacement and condenser for cleaning.

•Alarm with an audible chime lets you know when doors

or drawers are left open.

•Holiday mode allows you to power down one or both

sides for extended periods or just the weekend.

•For installations at or above 5,000' (1524 m) in eleva-

tion, high altitude glass is available as a special order.

•Certified by Star-K to meet religious regulations.

•UL approved for US and Canada.

•Sub-Zero products are covered by a two, five and

twelve year residential warranty (exclusions apply).

See warranty details at the end of this guide.

This appliance is certified by Star-K to meet

strict religious regulations in conjunction with

specific instructions found on www.star-k.org.

PRO 48 Models 5

subzero.com

PRO 48 Models

MODELS 648PRO AND 648PROG

Model 648PROG

with glass door

Model 648PRO

Automatic ice

maker

Auto-close

hinge system

Location of

water filter

xterior freezer

temperature display

asy-access grille

Adjustable stainless

steel shelves

Location of rating

plate (open drawer)

Sidewall lighting

Stainless steel

construction

Storage drawers

with dividers

Adjustable spill-

proof glass shelves

Touch control

panel

Microprocessor

xterior refrigerator

temperature display

Slide-out stainless

steel bins

Crisper drawer

Triple-pane, UV-resis-

tant glass (648PROG)

Dual refrigeration

system

Model 648PROG with glass door shown.

lectronic Control System

The electronic control system of the PRO 48 monitors and

accurately displays compartment temperatures within one

degree of your pre-set temperatures. It also monitors the

operation of the unit and lets you know if there is a

problem. The interior control panel located at the top of

the refrigerator door compartment has key pads to set

temperatures and control functions of the electronic

control system. Refer to the illustration below.

TEMPERATURE CONTROL

Your new PRO 48 was thoroughly inspected and tested

before it was shipped from the Sub-Zero factory. Tempera-

tures are preset at 38°F (3°C) in refrigerator compartments

and 0°F (-18°C) in the freezer compartments.

There are three sets of WARM R and COLD R key pads

on the interior control panel, two for the refrigerator

compartments (upper door and lower drawers) and one for

the freezer compartments. To adjust the temperature in

any of the three compartments, press the WARM R or

COLD R key pad for that compartment. Digital tempera-

tures for each of the three compartments are displayed in

the exterior temperature display.

Temperature ranges are -5°F (-20°C) to +5°F° (-15°C°) in the

freezer sections and 34°F (1°C) to 45°F (7°C) in the refriger-

ator sections. It is normal for temperatures to fluctuate

slightly, depending on external influences such as an open

door, the degree of humidity and room temperature.

IMPORTANT NOTE: Always allow 24 hours for compart-

ments to reach the temperature you set.

PRO 48 Use & Care 6

EXTERIOR TEMPERATURE DISPLAYS

lectronic control system functions, such as digital

temperatures and service indicators, are displayed in two

exterior temperature displays located on the grille. The

display in the lower left area of the grille shows the

temperature and indicators for freezer compartments, and

the display in the lower right gives readouts for refrigerator

compartments. Refer to the illustrations below.

Freezer Temperature

Controls

Ice Maker

On/Off

Power

On/Off

Alarm

On/Off

Lights

On/Off

Refrigerator

Temperature Controls

Upper

Compartment

Drawer

Compartments

Exterior temperature displays.

Control panel.

PRO 48 Use & Care 7

subzero.com

lectronic Control System

POWER

The POW R key pad on the control panel will shut off all

electrical power to the unit. When the power is off, the

OFF indicator light will be visible in the exterior tempera-

ture display. Using the POW R key pad means you do not

have to shut off power at the circuit breaker or unplug the

unit. The POW R key pad can be used for extended

vacations.

It is possible to shut off power to one compartment of the

PRO 48 for an extended period without affecting operation

of the other compartments.

First, turn the unit off by pressing the POW R key pad.

Then push and hold the WARM R key pad of the

compartment you wish to shut down. Press the POW R

key pad to turn the unit back on. The disabled zone will be

indicated with ‘--’ in the exterior temperature display.

Repeat the process to resume power to the compartment.

ALARM FEATURE

The PRO 48 has an alarm feature that lets you know with

an audible chime if a door or drawer is left ajar. The alarm

will sound after 30 seconds if a door or drawer is left open

and will stop once the door or drawer is closed. This alarm

can be disabled for cleaning or restocking by pressing the

ALARM key pad on the control panel.

ICE MAKER CONTROL

The IC MAK R key pad on the control panel switches

power to the ice maker system on or off. Use the IC

MAK R key pad to shut down ice maker operation during

extended vacations. The ice bucket icon will be visible in

the exterior temperature display if the ice maker system

is on.

VISUAL SERVICE DISPLAY

The electronic control system monitors compartment and

component temperatures as well as the ice maker system.

If there is a temperature or ice maker problem, you will be

alerted by a flashing S RVIC indicator light in the exterior

temperature display. This same S RVIC light will also

flash if the condenser needs cleaning.

SABBATH MODE (STAR-K)

Sabbath mode is available for the observance of certain

religious holidays. This mode turns off the lights, ice maker

system and door alarm and prevents them from turning on

again. Normal cooling operations will still take place.

To initiate Sabbath mode while the unit is on, press the

POW R key pad on the control panel so that ‘OFF’ is

visible in the exterior temperature display. Then press and

hold the POW R key pad for 10 seconds. This will turn the

unit back on with lights and ice maker disabled. There will

be four short chimes, indicating that the Sabbath mode

has been set. To return the unit to normal operation, press

and release the POW R key pad.

If you have questions about Star-K compliance, visit

www.star-k.org.

Shut off power to the unit at the control panel during

service.

PRO 48 Use & Care 8

Refrigerator Storage

AD USTABLE GLASS SHELVES

The adjustable glass shelves of the PRO 48 upper refriger-

ator compartment are cantilevered and spill proof with

stainless steel trim.

To remove a shelf, tilt the shelf up at the front, then lift it

up and out of the tracks on the rear wall of the refrigerator.

To replace a shelf, insert in the tracks with the front of the

shelf raised slightly. As you push the shelf in, lower the

front of the shelf until it locks into position. Refer to the

illustration below.

IMPORTANT NOTE: Use care when handling glass shelves

to prevent breaking the glass or scratching the interior.

AD USTABLE SLIDE-OUT BINS

The PRO 48 features two versatile, adjustable stainless

steel slide-out bins that fit neatly under any refrigerator

compartment shelf. The glass shelves have integrated rails

that make it possible to position the slide-out bins in a

variety of locations.

To remove the slide-out bin, pull the handle of the bin

forward until it stops, lift it up and out of the rails mounted

below the glass shelf. Refer to the illustration below.

CRISPER LID

The PRO 48 upper refrigerator drawer features a tight-

sealing crisper lid for higher humidity storage in the

drawer compartment. This clear lid provides visibility and

easy access to the compartment.

To remove the crisper lid assembly, pull the upper refriger-

ator drawer all the way out, raise the front edge of the

crisper lid up and pull out from the back. Refer to the illus-

tration below.

STORAGE DRAWER DIVIDERS

The PRO 48 refrigerator storage drawers give you full

access to food with adjustable and removable dividers.

The dividers are interchangeable between the upper and

lower refrigerator drawer. Two long dividers run the full

depth of the drawer, with shorter dividers that connect to

the long dividers to compartmentalize the drawer.

To remove the short dividers, lift up and out of position

from supports on the long dividers and sides of the

drawer. The long dividers can also be removed by lifting

up and out of position from drawer support tabs. Refer to

the illustration below.

Adjustable glass shelf. Adjustable slide-out bin. Storage drawer with crisper lid.

PRO 48 Use & Care 9

subzero.com

Freezer Storage

AD USTABLE SHELVES

The adjustable shelves of the PRO 48 upper freezer

compartment are cantilevered and 100% stainless steel.

The freezer shelves are repositioned the same way as the

glass shelves in the refrigerator compartment. To remove

or adjust the freezer shelves, first tilt the shelf up at the

front, then lift it up and out of the tracks on the rear wall of

the freezer.

To replace a shelf, insert in the tracks on the rear wall of

the freezer with the front of the shelf raised slightly. As you

push the shelf in, lower the front of the shelf until it locks

into position.

ICE BUCKET REMOVAL

The automatic ice maker and stainless steel ice bucket are

located in the lower freezer drawer.

To remove the ice bucket, pull the freezer drawer out until

it stops, lift the ice bucket up and out of the drawer. The

entire lower freezer drawer can now be used for more ice

storage if necessary.

Storage Drawers

DRAWER REMOVAL

The refrigerator and freezer storage drawers are remov-

able for cleaning. The drawers have an automatic stop

built in to prevent drawers from coming all the way out of

the unit.

To remove, pull the drawer all the way out until it stops, lift

up evenly on both sides of the drawer front and pull out.

To reinstall, raise the front of the drawer and place onto

the drawer slide tracks. Be sure to engage the front of

the drawer slide with the drawer assembly. Refer to the

illustration below.

IMPORTANT NOTE: To reduce the weight of the drawer, be

sure to unload the contents before removing the drawer.

Storage drawer removal.

Storage drawers are heavy. Be sure to keep your feet

clear as you remove the drawer.

PRO 48 Use & Care 10

Water Filtration System

The PRO 48 features a water filtration system that

supplies filtered water to the ice maker to produce great-

tasting ice. The water filter has been factory installed

behind the grille assembly.

It is important that the operation, maintenance and filter

replacement requirements be carried out as scheduled.

Refer to the following information on the water filter

cartridge monitor.

IMPORTANT NOTE: If the unit has been turned off or the

ice maker disabled for one month or longer, the water filter

cartridge should be replaced once the unit and ice maker

are back in operation.

IMPORTANT NOTE: Do not use with water that is microbi-

ologically unsafe or of unknown water quality without

adequate disinfection before or after the system. Systems

certified for cyst reduction may be used on disinfected

waters that may contain filterable cysts.

Refer to the performance data on page 25 for additional

information regarding the water filtration system.

WATER FILTER CARTRIDGE MONITOR

The water filter cartridge is designed to last for up to one

year of continuous use of the ice maker. The electronic

control system monitors the life of the water filter cartridge

and indicates when it needs to be replaced. An indicator

that reads ‘R PLAC FILT R’ will be visible in the left

side exterior temperature display. Follow steps to replace

the water filter cartridge on the following page.

Once the filter cartridge has been replaced, the control

automatically resets the water filter life monitor and the

‘R PLAC FILT R’ indicator will no longer be displayed.

Although it is designed to last for up to one year of use,

the actual life of the filter cartridge may vary with water

supply conditions. Therefore, it is recommended that the

filter cartridge be replaced when the ‘R PLAC FILT R’

indicator is displayed or if the ice cubes become hollow or

smaller.

IMPORTANT NOTE: The warranty for the water filter

cartridge supplied with the unit only covers defects in

materials or workmanship and not replacement due to

normal use.

REPLACEMENT CARTRIDGES

Replacement Sub-Zero water filter cartridges can be

ordered online at subzerowolfstore.com. For questions,

contact Sub-Zero customer care at 800-222-7820.

Andere Handbücher für PRO 48

Inhaltsverzeichnis

Andere Sub-Zero Kühlschrank Handbücher

Sub-Zero

Sub-Zero 600 Series BI-48SD Bedienungsanleitung

Sub-Zero

Sub-Zero 700BR Bedienungsanleitung

Sub-Zero

Sub-Zero IC-27R Bedienungsanleitung

Sub-Zero

Sub-Zero 424FS Leitfaden

Sub-Zero

Sub-Zero 600 Series BI-36R Bedienungsanleitung

Sub-Zero

Sub-Zero 600 Series BI-30U Bedienungsanleitung

Sub-Zero

Sub-Zero 736TCI Bedienungsanleitung

Sub-Zero

Sub-Zero UC-24BG/S/TH-RH Bedienungsanleitung

Sub-Zero

Sub-Zero Designer Series Bedienungsanleitung

Sub-Zero

Sub-Zero 601R-2 Betriebsanleitung

Sub-Zero

Sub-Zero 700BC-3 Betriebsanleitung

Sub-Zero

Sub-Zero ICBBI-36R Leitfaden

Sub-Zero

Sub-Zero 245 Gebrauchsanweisung

Sub-Zero

Sub-Zero ID-30CI Bedienungsanleitung

Sub-Zero

Sub-Zero 500 Series Technisches Handbuch

Sub-Zero

Sub-Zero 400 Series Service-Handbuch

Sub-Zero

Sub-Zero DEC3650RL Bedienungsanleitung

Sub-Zero

Sub-Zero PRO3650G Bedienungsanleitung

Sub-Zero

Sub-Zero PRO 48 Montageanleitung

Sub-Zero

Sub-Zero ICB700 T Series Bedienungsanleitung

Sub-Zero

Sub-Zero 661 Bedienungsanleitung

Sub-Zero

Sub-Zero 648PRO Bedienungsanleitung

Sub-Zero

Sub-Zero PRO 48 Bedienungsanleitung

Sub-Zero

Sub-Zero 700TCI Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
