SureWest Whole Home DVR Bedienungsanleitung

Back to Table of Contents

SureWest

Whole Home

DVR Manual

Reference Guide Spring 2012

Important

information!

Retain for your

reference.

Back to Table of Contents

SureWest Whole

Home DVR

SureWest Whole Home DVR makes your cable experience, a better cable

experience. Our Whole Home DVR allows you to watch your recorded programs

on any TV in your home with just one DVR! And, you can record you up to 2

programs per DVR at one time! In the middle of watching a recorded program

and need to ﬁnish watching it in another room? No problem, just press stop and

start it up in another room. Can’t decide which show to record? Record them all

and don’t forget to record every episode with the Program Series Record feature.

SureWest’s Whole Home DVR enables you to watch what you want, when you

want from anywhere in your home. We’ll change the way you watch TV!

SureWest Whole Home DVR…a better experience!

Contents

Let’s Get Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

• Get to know your SureWest Whole DVR and set-top box. . . . . . . . . . . . 4

• Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

• Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

• Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

• Name your DVR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

• HDTV Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

• Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

DVR/Set-top box Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

• Control Live TV and Recording . . . . . . . . . . . . . . . . . . . . . . . . .14

• Record and Replay Programs . . . . . . . . . . . . . . . . . . . . . . . . . .16

• Default Recordings Settings . . . . . . . . . . . . . . . . . . . . . . . . . . .17

• Series Recording. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

• Conﬂict Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

• Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

• Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

• Favorites . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

• Parental Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

• Closed Captioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

• Caller ID on TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

• FAQs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Click on the table of contents sections to go to that page.

Back to Table of Contents

Let’s Get Started

Get to know your SureWest Whole Home DVR and Set-top box

Your SureWest Whole Home DVR/set-top box is a Cisco Explorer 8652/4652HDC. It supports

all of SureWest’s cable TV services including Pay Per View, Video on Demand and HD.

Your DVR and set-top box must be handled much in the same way as a computer to reduce

potential for damage.

• PositionitinanopenspacetoallowairowaroundtheDVR/set-topbox

• DonotplacetheDVR/set-topboxinanenclosedentertainmentunitorcabinet

• DonotplacetheDVR/set-topboxonasoftsurfacesuchasarug,sofa,bedorother

similar surface

• TheDVR/set-topboxshouldnotbenexttoanexternalheatsourcethatcouldraise

the temperature of the unit

• Connectionintoasurgeprotectoralongwithyourotheraudio/videoequipmentis

highly recommended

Included Accessories

Remote control

Batteries

Power Adaptor HDMI cable

RGB (component) cables

DVR/Set-top box Manual

Programming Remote

Control Guide

Back to Table of Contents

Front Panel

Item Description Function

1Power The power button will turn the

DVR/set-top box on and off.

2Up, down, left and

right arrow keys

Up and down arrows allow you to change

channels. Left and right arrow keys allow you

to navigate through the guide and menu.

3Select Conﬁrms channel or menu selections

4Indicator Light

When this indicator is lit up with Red it indicates

the DVR/set-top box is recording a program, the

Green light indicates the DVR is powered on

5Clock The time or channel can be indicated here.

6Cisco DVR/set-top

box model number

8652 identiﬁes the DVR and 4652

identiﬁes the set-top box

7USB Drive Reserved for future use

8Guide Press this button to activate your

on screen programming guide

9 Info Press this button to activate the

on-screen program information bar

10 Exit Press this button to exit on-screen

applications to return to live TV

11 List Press this button to go to a list of the recorded

programs available for viewing on your DVR

1 2 3

910

Back to Table of Contents

Back Panel

Item Description Function

1Cable In Coax input for home cable network

2Output Video and Audio output connections

3Optical Audio Out S/PDIF audio output to a digital home theater receiver

4S- Video Out Video output for VCR or TV with S-Video connections

5Cable Out RF output to connect VCR or DVD player

6HDMI Input for high-deﬁnition TV or home

theater receiver with HDMI connectors

7USB USB connection

8SATA External hard drive extension

91394 Firewire port

10 Ethernet Ethernet port to connect to the home network

11 Power output Polarized 2-prong outlet, 500W max

1 2 3

74 8

910611

Back to Table of Contents

Remote Control

To view you Cable TV service, complete the following steps:

Remote Control

1. Press the TV button on your remote control

2. Press the Power button on your remote control

3. Press the CBL button on your remote control

4. Press the Power button on your remote control

5. Press the Menu button to display the main menu

6. Use the arrow keys to select an option: TV, Recorded TV,

Applications or Settings

You are now ready to sit back, relax and enjoy a better TV experience!

Back to Table of Contents

Remote Control

Mode buttons to control TV

and additional devices

Access your on screen

program guide

Numeric keys

Replay the previous few seconds

of a program

Use your cursor keys to navigate

guide and menu screens

Go to the main menu screen

Aspect control

Browse channels

Go directly to your list of

recorded programs

PIP controls

Pause your programming

OK conﬁrms your menu and

guide selections

Return to live TV

Rewind/Fast-forward controls

Go to the On Demand menu

Stop recording or replay modes

Increase/Decrease audio volume

Mute the sound on your TV

Remote Control Functions

Use your remote control to access programs, adjust volume, control your DVR/set-top box and

On Demand selections as well as scroll through and conﬁrm actions within the on-screen menus.

Batteries

To change the batteries, open the cover on the back of the remote. Press the cover tab gently and

lift the cover up. Other ways of opening the cover may result in breaking the cover. The batteries

should be installed observing the polarity presented on the inside of the battery compartment.
