16CH and 32CH Network Video Recorder with Local Display

Version 1.0.0

ESV16U, ESV32U

Quick Installation Guide

2 ESV16U, ESV32U Quick Installation Guide

Table of Contents

Preliminary............................................................................... 3

System Overview...................................................................... 8

Front View..................................................................................... 8

Rear View...................................................................................... 8

LED Status .................................................................................... 9

Installation............................................................................. 10

HDD Installation........................................................................... 10

Rack Mounting Kits and Screws.................................................... 15

Connecting to the NVR.................................................................. 16

Using NVR Device Search Utility ......................................................16

Accessing the NVR with its default IP address ...................................19

Password Setup ............................................................................21

Camera Installation...................................................................... 22

Adding a Camera -- Automatic Search .............................................22

Adding a camera manually .............................................................24

Refer to the user's manual (PDF file) contained in the CD-ROM for settings,

operations and other information.

The application Adobe®Reader®is needed to view PDF files. If you do not

have this application, download it from the Adobe Systems Incorporated

website.

http://www.adobe.com/

For information on our latest products and peripheral devices, refer to the

following Website:

http://www.toshibasecurity.com

ESV16U, ESV32U Quick Installation Guide 3

Preliminary

Thank you for purchasing the ESV16U and ESV32U Network Video Recorder

(NVR). Before using the NVR, read this quick installation guide (QIG)

carefully to ensure correct usage. After reading this quick installation guide

(QIG), save it for future reference.

The design, specifications, software, and QIG contents are subject to change

without prior notice.
