Swann Alpha D01 Bedienungsanleitung
Alpha D01 DVR
4 Channel Digital Video Recorder
SWA41-D1
www.swannsecurity.com
Operating Instructions
22
FCC Verification:
NOTE: This equipment has been tested and found to comply with the limits for
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are de-
signed to provide reasonable protection against harmful interference in a residen-
tial installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio or television reception, which can be deter-
mined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
· Reorient or relocate the receiving antenna
· Increase the separation between the equipment and the receiver
· Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected
· Consult the dealer or an experienced radio/TV technician for help
These devices comply with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) These devices may not cause harmful interference, and
(2) These devices must accept any interference received, including interference
that may cause undesired operation.
IMPORTANT NOTE: Prohibition against eavesdropping
Except for the operations of law enforcement officers conducted under lawful
authority, no person shall use, either directly or indirectly, a device operated pursu-
ant to the provisions of this Part for the purpose of overhearing or recording the
private conversations of others unless such use is authorized by all of the parties
engaging in the conversation.
WARNING: Modifications not approved by the party responsible for compliance
could void user’s authority to operate the equipment.
IMPORTANT SAFETY INSTRUCTIONS:
· Make sure product is fixed correctly and stable if fastened in place
· Do not operate if wires and terminals are exposed
· Do not cover vents on the side or back of the DVR and allow adequate space for
ventilation
Before You Begin
3
Contents
Before You Begin 2
Contents 3
Package Contents 4
DVR Layout 5-6
Front Panel & Removable Remote 6
Rear Panel 6
Connections & Installation
Connecting Cameras and Power Adapter 7
Connecting the DVR to a TV Monitor 8
Turning the DVR On/Off and Auto Recovery 8
Menu Operation 9
Accessing and Navigating the Menu System 9
Setting DVR Time 9
Image Display 10
Single Camera View 10
Multi Camera View 10
Camera Menu 11
Record Menu 11-12
Motion Detection Menu 12-13
Screen Menu 13
Audio Menu 14
System Menu 14-15
Time Search 15
Language Menu 16
Exit Menu 16
Starting the DVR With a New Hard Drive 16
Changing the Hard Drive 17
Backing Up Footage to PC 18
Viewing Backup Footage on a PC 19
Using the VVFPlayer software 19
VVFPlayer Interface 19
Extract footage from a larger video clip 20
Exporting an AVI file 20
Troubleshooting Guide 21
Technical Specifications 22
Warranty Information 23
Technical Support Details Back cover
44
Package Contents
Alpha D01 DVR Unit
Front Panel Remote Control X 2
Operating Instructions
Easy Setup Guide
Power Adapter with Cable
Software CD
RCA Video Cable
BNC to RCA adapters X 4
Security Stickers (4 Pack)
If you are missing any of the components above, contact Swann
Communications for assistance.
5
1. Hard Drive Indicator
Lights when hard drive is ac-
tive (flashes when recording,
searching etc.)
2. Power Indicator
Lights on when DVR powered
3. Channel 1 Button
Press to view camera 1 in full
screen / Press again to return to
quad view
4. Channel 2 Button
Press to view camera 2 in full
screen / Press again to return to
quad view
5. Menu Button
Press to select Menu / previous
menu / exit menu
Note: some menu functions
require a password. Default
password is “111111”
6. Set Button
Press to confirm selection
7. Record/Stop Button
Push to begin or stop recording
Note: will not work if time
or motion record is set.
8. Play/Pause Button
Push to open EVENT LIST,
begin last recording or pause
playback
9. Remote Control Sensor
10. Channel 3 Button
Press to view camera 3 in full
screen / Press again to return to
quad view
11. Channel 4 Button
Press to view camera 4 in full
screen / Press again to return to
quad view
12. Up Arrow
Move cursor up in menus
13. Down Arrow
Move cursor down in menus
14. Rewind Button
Push to rewind playback /
Move cursor left in menus
15. Fast Forward Button
Push to fast forward playback
/ Move cursor right in menus /
Activate AUTO SWITCH func-
tion
Note: 3-15 removable front
panel remote
DVR Layout
Front Panel & Removable Remote
1
10 11 12 13
23 4 5 6 7 8
914 15
The remote control contains a battery that must be activated before use.
Find and remove the clear plastic tab at the bottom of the remote. The
remote will now be ready for use.
Using the Remote Control for the First Time
IR LED
Remove
plastic tab on
this end of
remote.
66
1. Video Output
Output to TV
2. Video Input
Inputs for cameras x 4 RCA
3. Audio Input
Input for microphone 1 x RCA
4. Audio Output
Output to speaker 1 x RCA
5. USB Connection
Download backup footage to Flash Drive (not
included)
6. DC 12V Power Input
Power Adapter connection for DC 12V adapter
only
Rear Panel
3
4 51 2 6
DVR Layout (cont)
Use the indent to
remove the control from
the DVR unit
Removing the Remote Control
Note: To secure the DVR and prevent unauthorised use remove the
remote and store in a secure place.
7
Connecting Cameras and Power Adapter
1. Connect the Power and BNC ends of the Security Camera to an
Extension Cable.
2. Connect the BNC end of the Extension Cable to the RCA adapter.
3. Connect the end of the RCA adapter to camera input on the back of the DVR.
4. Connect the power end of the Extension Cable to the Power Splitters.
5. Connect the Power Splitter to the Camera Power Adapter.
6. Plug in the Camera Power Adapter and the DVR Power Adapter to mains
power outlets.
1
2
3
4
5
Cameras and
accessories optional
6
88
Connecting the DVR to a TV Monitor
12
1. Connect an RCA end of the Video Cable to the Yellow Video
INPUT on the back of the TV Monitor.
2. Connect the other RCA end of the Video Cable to the Video OUTPUT
connection on the back of the DVR.
3. Tune your TV to the correct input channel to view the DVR. Using your TV’s
Remote Control press the Input button until the DVR appears on screen. Most
TVs will label this button as Input, Video, Source, A/V, TV/AV, Line, Channel 0,
etc. If you are unable to view your DVR on your TV contact your TV’s manufac-
turer for assistance.
Back of TV
Powering the DVR On/Off
To turn on your DVR connect the Power Adapter to the DC 12V input on the
back of the unit. To turn the DVR off unplug the DVR from the wall outlet or
power point.
If the DVR will not be in use for extended periods of time Swann recommends
unplugging the unit.
Auto-Recovery Feature
The Alpha D01 DVR is equipped with an Auto-Recovery feature. Should a power
outage occur while you are recording the DVR will automatically resume record-
ing once power is restored.
Turning the DVR On/Off and Auto Recovery
9
Menu Operation
Accessing and Navigating the Menu System
The main Setup Menu can be accessed by pressing the MENU Button
To navigate the menus press the directional arrow keys UP DOWN
To change selections use the REWIND & FAST FOWARD
buttons
To select the highlighted option press the SET button
To return to the previous menu press the MENU button
Note: The menu cannot be accessed
while in playback or backup mode.
Return to the main camera view before
entering the menu.
Main Setup Menu
Setting DVR Time
To change the DVR time, go into the SYSTEM
menu and select TIME SET.
With TIME SET highlighted press the SET
button to display the selection arrows.
Use the FAST FOWARD & REWIND buttons to
select between the date (year, month, day)
and time (hour, minute, seconds)
Using the UP & DOWN buttons change the
selected option
1010
Single Camera View
Multi Camera View
5
6
23
1. Current Camera Channel
2. Motion Detection Icon
3. Recording Icon
4. Main Display
5. Current Date & Time
6. Mute Audio
7. No Camera Signal Icon
Multi Camera View with 4 Cameras Multi Camera View with No Cameras
7
MUTE
Image Display
1
4
