Tally T2040 Bedienungsanleitung

Reference manual Matrix printer

T2240/9

T2240/24

T2340/9

T2340/24

Table of contents Introduction

1 Operation

The control panel 1 - 1

The LC display 1 - 2

Messages in the LC display 1 - 3

LC display language 1 - 4

Selecting the LC display language 1 - 4

Unlock the Menu mode 1 - 4

Terminating Menu mode 1 - 6

Key functions when turning on the printer 1 - 7

Programming via the control panel 1 - 7

Calling up the menu 1 - 8

Calling up a locked menu 1 - 8

Menu configurations 1 - 8

Menu handling 1 - 10

Save settings 1 - 11

Example of the menu structure 1 - 12

Menu description table 1 - 13

Menu settings (example) 1 - 21

Bidirectional print adjustment (L/R Adj) 1 - 22

2 Emulations

General 2 - 1

Escape sequences 2 - 1

What are escape sequences? 2 - 1

MTPL sequences 2 - 1

What are control codes? 2 - 1

The $$ procedure 2 - 2

Table of contents

How are escape sequences used? 2-3

MTPL 2-4

Example in BASIC 2-4

Example in Pascal 2-4

Printout 2-4

List of available control codes 2-5

Barcode 2-17

List of available barcodes 2-17

LC printing 2-19

List of additional control codes 2-20

Configuring the printer for your computer 2-21

3 Troubleshooting, care and maintenance

Test functions and hardware settings 3-2

Printer self-test (Rolling ASCII) 3-3

Exiting Test mode 3-5

Interface test (Hex-Dump) 3-6

Printout in Hex-Dump 3-6

Terminating Hex-Dump 3-7

Setting the Formlen function 3-8

Wrap 3-9

Sound 3-10

CX-bid 3-11

CX-IF 3-12

ChTrFr 3-13

Mechanical adjustments to the printer 3-14

Setting the basical top margin and L/R adjustment 3-14

Troubleshooting 3-17

The display remains dark 3-17

The display is lit, but the printer does not print 3-18

Problems with the paper feed 3-18

Paper jam (fanfold paper) 3-19

Paper jam (single sheets) 3-20

Tear off position cannot be adjusted 3-21

Paper does not move to tear off position 3-21

Problems with the print quality3 - 22

Print is too pale3- 22

Smudged print3 - 22

Prints undefined characters3 - 22

The first line is not completely printed out at the top3 - 22

Dots within characters are missing3 - 22

Error messages via the display3 - 23

Load paper from ...3 - 23

Printhead hot3 - 23

Parity Error3 - 23

Hardware Alarm3 - 23

Home Position3 - 23

Eject Error3- 24

Load Error3 - 24

Additional display messages3 - 25

Press any key3 - 25

Loading Default3 - 25

Only available in Epson mode3 - 25

Park position3- 25

Tear paper off3 - 25

Turn paperlever3 - 25

Care and maintenance3 - 26

Cleaning the housing 3 - 26

Cleaning the interior3 - 27

Ribbon3 - 27

A Character sets

Character sets A - 1

MTPL standard character set A - 2

MTPL international substitution characters – normal font A - 3

OCRA Character Set A - 4

OCRB Character Set A - 5

Available character sets and fonts A - 6

Table of contents

BInterfaces

Parallel interface B - 2

Jumper settings B - 3

Serial interface RS232C/V.24 B - 4

Connector assignment B - 4

Interface cable RS232C B - 5

Protocol description B - 6

Jumper settings B - 7

Serial interface RS422/V.11CB - 9

Connector assignment B - 9

Protocol description B - 9

Jumper settings B - 10

CSpecification

Printer specifications C - 1

Interface specifications C - 3

Paper specifications C - 4

DOptions and Accessories

Options D - 1

Accessories D - 2

Table of contents

Introduction

About Part II of the

operator’s manual The reference manual contains a detailed description of the printer, its char-

acteristic features and additional information.

If you need to operate your printer as soon as possible, it is sufficient to

read

Installing the printer

in the Operator’s manual. For further information

and correct use of your printer the complete operator’s manual must be

read.

The reference manual is divided into three chapters with their titles printed

in the top margin of the page. The current chapter is marked by a black bar.

The chapters of this manual describe the following topics:

■Chapter 1 Operation contains information on programming your printer via

the operating panel.

■Chapter 2 Emulations deals with programming via the interface. The avail-

able programming sequences are listed. (Detailed information about these

codes are available in an optional Programmer’s Application Manual which

can be purchased separately.)

■Chapter 3 Troubleshooting, care and maintenance helps you to deal with

common problems and shows you how to use the test and adjustment

functions of your printer. Hints on identifying and repairing faults yourself are

provided. At the end of the chapter, cleaning and care of your printer are

described.

■Appendix A Character sets lists the available character sets.

■Appendix B Interfaces explains the interfaces.

■Appendix C Specifications informs you about the technical specifications of

your printer and the paper which should be used.

■Appendix D Options and accessories contains information about options

and accessories you can purchase for your printer.

Introduction

Explanation of symbols Notes on the symbols used:

●Texts marked with this dot describe operations which must be performed in

the given order.

■This mark indicates a list.

Text sequences marked by this symbol must be noted and observed under

all circumstances since any misuse could injure the operator or damage

the equipment.

This symbol marks important information and notes.

STOP

Introduction

Setup

Online

123 4

Operation 1

The control panel The control panel is located on the front left side of your printer and

consists of a two-line LC display and six keys.

The functions of the keys depend on the printer’s current mode (status).

There are four basic modes.

The

Online mode

is the printer’s normal operating status. Data from your

computer can be received and printed.

In the

Offline mode

the link between printer and computer is interrupted,

i.e. no data can be received and printed.

In the

Setup mode

you can either select the printer menu or carry out the

so-called quick-switch function. The quick-switch option was included so

that you can change the most important parameters (character density,

font, paper path) directly without having to enter them via the menu. The

parameters character density, paper path and font can also be selected in

the printer menu.

In the

Menu mode

printer settings (line spacing, size of the interface buffer

etc.) can be altered and saved permanently.

LC display

Online key

Setup key

1 - 1

123 4

Setup

Online Trac.1

Tear

Online

The LC display The LC display tells you all the important printer settings and informs you

which functions are currently assigned to which keys.

In Normal mode the upper line tells you the printer’s status (Online or

Offline mode – in the example below the printer is in the Online mode), and

the selected paperpath (below:

Trac.1 = push tractor mode).

The second line informs you which functions are currently assigned to

which keys. The word or symbol directly above a key tells you the current

function of the key. In our example the right key is assigned with the Tear

function. If you were to press this key the loaded fanfold paper would be

advanced to the tear position.

Example:

Printer status Paperpath

Key

functions

The control panel

1 - 2

Messages in the

LC display If the printer detects an internal fault or user error or if it expects you to do

something, a message will appear in the LC display. Below you will find a

list of messages with brief descriptions of each message. The messages

are described in more detail in the section

Troubleshooting

in chapter 3

Troubleshooting, care and maintenance

Message Meaning

Eject error The printer cannot eject paper/advance it to park position.

Hardware Alarm Internal hardware error/print head blocked.

Head hot The printer reports that the print head is hot and that print

speed will be reduced.

Initializing This message appears during the printer’s initializing

phase.

Load error The printer cannot draw in the loaded paper.

Loading default Indicates that the printer is being initialised and is

carrying out the internal self-test immediately after

turning on the printer.

Load paper from

Single

Tractor1

Tractor2

ASFauto

The printer has detected paper end during operation or

the printer was switched on with no paper loaded.

The user is requested to insert paper into the paper input

selected.

Parity error A parity error during data transmission is indicated.

Press any key The user is requested to press any key.

Tear Paper off The user is requested to tear off paper which has been

advanced to the quick tear edge.

Turn paperlever The user is requested to turn the paper type selection

lever.

The control panel

1 - 3
