TF-S3000CHD

User Guide

High Deﬁnition

Digital Satellite Receiver

USB PVR-Ready

Common Interface

Conax Embedded

Default PIN: 0000

The lightning ﬂash with arrowhead symbol, in an equilateral triangle, is intended to alert the

user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of

suﬃcient magnitude to constitute a risk of electric shock to a person.

The exclamation point, in an equilateral triangle, is intended to alert the user to the presence of

important operation and maintenance instructions in the literature accompanying the product.

Precautions

• Read, keep and follow these instructions.

• Heed all warnings.

• Clean with a dry cloth only.

• Do not block any of the ventilation openings.

• Do not install near any heat sources or in direct sunlight as this will impair cooling.

• Do not operate this product near water. Do not place any of the objects ﬁlled with liquids, such as

vases on this unit.

• Do not try to change the plug or defeat its safety purpose. If the provided plug does not ﬁt into

your outlet, consult an electrician for replacement of the obsolete outlet.

• This product is designed for indoor use only.

• Place the digital receiver on a ﬁrm and level surface.

• Do not lay any objects such as magazines on this unit.

• Do not overload power outlets. Doing so may result in a risk of ﬁre or electrical shock.

• Never open this unit’s casing under any circumstances, or the warranty will be void.

• Unplug this unit during lightning storms or when unused for long periods of time.

• Refer all servicing to qualiﬁed service personnel. Servicing is required when the unit has been

damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or

objects have fallen into the unit, the unit became wet from rain or moisture, does not operate

normally, or has been dropped.

• Batteries, including those which contain no heavy metals, may not be disposed with other

household wastes. Please dispose of used batteries in an environmentally sound manner. Find

out the legal regulations which apply in your area.

iii

About this user guide

Thank you for purchasing our digital receiver. Please read this user guide carefully before you use the

digital receiver and keep it handy for future reference.

This User Guide covers the model TF-S3000CHD .

• Illustrations pictured in this manual may not be exactly the same as the actual product.

• The screenshots used in this manual may not be exactly the same as those you see on the actual

on-screen displays.

• Designs and speciﬁcations of the digital receiver and other accessories are subject to change with-

out any notice in order to introduce new features or improve the functionality of the product.

iv CONTENTS

Contents

Contents iv

1 Introduction 1

1.1 Features .............................. 1

1.2 Controlling the digital receiver .................. 2

1.2.1 Front panel ........................ 3

1.2.2 Remote control ...................... 4

1.3 Subscription card information .................. 6

1.4 Common Interface ......................... 6

2 Setup 8

2.1 Unpacking ............................. 8

2.2 Safety precautions ......................... 8

2.3 Rear panel connections ...................... 9

2.4 Connecting up your digital receiver ............... 11

2.4.1 Connecting to the antenna ................ 11

2.4.2 Connecting to your television set ............ 12

2.5 Switching on for the ﬁrst time .................. 14

3 Service Search 16

3.1 Searching for broadcasting services ............... 16

3.1.1 Conﬁguring LNB settings ................ 17

3.1.2 Conﬁguring DiSEqC 1.2 settings ............ 19

3.1.3 Conﬁguring USALS settings ............... 20

3.1.4 Searching for services .................. 21

CONTENTS v

3.2 Editing the transponder list ................... 24

3.3 Resetting to factory settings ................... 25

3.4 Resetting to user settings ..................... 26

4 Preference Settings 27

4.1 Language settings ......................... 27

4.1.1 Menu language ...................... 27

4.1.2 Subtitle language ..................... 27

4.1.3 Hard of Hearing ..................... 28

4.1.4 Audio language ...................... 28

4.2 Video and audio settings ..................... 29

4.2.1 High deﬁnition television ................ 29

4.2.2 Television aspect ratio .................. 30

4.2.3 Colour format ....................... 31

4.2.4 Audio mode ........................ 31

4.3 Local time setting ......................... 32

4.4 Parental control .......................... 34

4.5 Options for recording ....................... 36

4.6 Options for playback ....................... 37

4.7 Options for on-screen display .................. 38

4.8 Options for standby mode .................... 39

4.9 Options for navigation buttons .................. 39

5 Every Day Use 40

5.1 Volume control .......................... 40

5.2 Watching television ........................ 40

5.2.1 The services list ...................... 40

5.2.2 The favourite service lists ................ 42

5.2.3 Viewing programme information ............ 44

5.2.4 Selecting audio tracks .................. 44

5.2.5 Selecting subtitle tracks ................. 45

5.2.6 Viewing teletext ...................... 45

5.3 Viewing electronic programme guide .............. 45

5.4 Watching multifeed programme ................. 46

5.5 Using time-shift .......................... 47

vi CONTENTS

6 Organising Services 49

6.1 Editing the services list ...................... 49

6.2 Editing the favourite lists ..................... 51

6.3 How to use on-screen keyboard ................. 53

7 Recording and Playback 54

7.1 Recording a programme ..................... 54

7.1.1 Instant recording ..................... 55

7.1.2 Timer recording ...................... 56

7.1.3 Scheduling recordings using the programme guide . . 59

7.1.4 Recording a pay service programme .......... 60

7.2 File archive ............................. 61

7.2.1 To delete a recording ................... 62

7.2.2 To sort recordings ..................... 62

7.2.3 To lock a recording .................... 62

7.2.4 To rename a recording .................. 62

7.2.5 To make a new folder ................... 63

7.2.6 To move a recording to another folder ......... 63

7.3 Playing back a recording ..................... 63

7.3.1 To navigate using the progress bar ........... 64

7.3.2 To play in slow motion .................. 64

7.3.3 To play in fast motion ................... 64

7.3.4 To make a bookmark ................... 65

7.3.5 To play back a recording repeatedly .......... 65

7.3.6 To play back recordings in sequence .......... 66

7.3.7 To play back a scrambled recording ........... 66

7.4 Copying a recording ....................... 67

7.5 Playing back a video ﬁle ..................... 67

7.6 Formatting the hard disk ..................... 68

8 Entertainment 69

8.1 Conﬁguring the network setting ................. 69

8.2 Playing back YouTube contents (optional) ........... 70

8.3 SHOUTcast Internet radio (optional) .............. 71

8.4 Google weather forecast (optional) ............... 72

CONTENTS vii

9 Firmware Update 73

9.1 From a memory stick ....................... 73

9.2 From the ﬁrmware server via the Internet ........... 74

9.3 Over the air(optional) ....................... 75

Chapter 1

Introduction

The TF-S3000CHD digital receiver is fully compliant with the

international Digital Video Broadcasting (DVB) standard, and

thus is able to receive digital broadcasts of that standard. For

its operation you need an antenna, which must be installed ap-

propriately.

NOTE

In general we equate a channel with a frequency. However,

unlike analogue broadcasts, digital broadcasts are not all

assigned to their own frequencies; instead, multiple televi-

sion broadcasts are transmitted through a single frequency.

The frequency in digital broadcasting is usually called trans-

ponder or multiplex. To reduce confusion in this manual,

the word service is preferably used than channel as a term

to indicate one television or radio broadcast.

1.1 Features

This digital receiver has the following features:

• Supports DiSEqC 1.0, DiSEqC 1.1, DiSEqC 1.2 and US-

ALS protocols.

2 Introduction

• Can store up to 10,000 television and radio services.

• You can edit the services list.

• Can create lists of your favourite services.

• Can view information about the current television or ra-

dio programme.

• Has an electronic programme guide that provides an

overview of scheduled programmes.

• Time-shift is a special technical feature available on this

digital receiver. You can pause a programme you are

watching and resume it again at a later time. Then you

can quickly go to any part of the current programme by

fast forward or rewind search.

• If you have an external hard drive connected to the dig-

ital receiver via the USB port, you can record television

programmes into it.

• You can use various Web services including YouTube.

(optional)

1.2 Controlling the digital receiver

You can operate the digital receiver with the remote control or

the buttons on the front panel.

NOTE

When the digital receiver is oﬀ but plugged into a wall

socket, we say that it is in standby mode; on the other hand,

when it is on, it is in active mode. Even when you are not

using the digital receiver, you should keep it plugged into

a wall socket to be in standby mode so that it can run timer

events at any time.
