TRENDnet TV-IP212 - Internet Camera Server Bedienungsanleitung
TV-IP212/TV-IP212W
TV-IP312/TV-IP312W
Quick Installation Guide
Table of Contents
English ......................................................................................................
Troubleshooting ........................................................................................
1
1
4
3
7
1. Before You Start
2. Hardware Installation .........................................................................
3. Configure the Internet Camera ..........................................................
.................................................................................
Table of Contents
Version 08.03.2007
System Requirements
Package Contents
1. Before You Start
English
1
?
?
?
?
?
?AC Power Adapter (5V, 2.5A)
?1 x 2dBi Detachable Antenna
(
TV-IP212/TV-IP212W/TV-IP312/
TV-IP312W
Quick Installation Guide
Utility CD-ROM
Camera Stand
RJ-45 Cable
TV-IP212W/TV-IP312W)
?
?
?
?
?
?
10/100Mbps Ethernet
CPU: 1GHz processor or above
Memory: 256MB RAM or above/ 512MB RAM or above (Windows Vista)
VGA Resolution: 800 x 600 or above
Web Brower: Internet Exploreer (6.0 or higher)
Windows Vista/XP/2000
Application
English
2
Modem
2-Way Audio
Internet Camera Server
(TV-IP212/TV-IP312)
Cable/DSL 4-Port
Broadband Router
(TW100-S4W1CA))
Mobile Phone with
3G Support & Service
Internet
Notebook with
PC Card
(TE100-PCBUSR)
10/100Mbps
Wireless 2-Way Audio
Internet Camera Server
(TV-IP212W/TV-IP312W)
Wireless Firewall Router
(TEW-432APB)
54Mbps
Modem
Notebook with
Wireless PC Card
(TEW-421PC)
Mobile Phone with
3G Support & Service
TV-IP212W
TV-IP212
TV-IP312W
TV-IP312
Internet
2. Hardware Installation
English
3
1. Attach the Antenna. (TV-IP212W/
TV-IP312W)
3. Connect external speaker to the
Internet Camera Server (optional)
4. Connect the AC Power Adapter to
the Internet Camera Server and
then to a power outlet.
6. Verify the Power and Link LEDs
are on (TV-IP312W is shown).
2. Connect a RJ-45 network cable
from a Switch/Router to the
Ethernet port of the Internet
Camera.
5. Connect USB flash drive to the
Internet Camera Server (optional)
English
4
1. Open your web browser, type
http://192.168.10.30 in the
Addres bar, and press Enter.
3. Configure the Internet Camera
Note: It is recommended that you configure the Internet Camera from a wired
computer. Before the Internet Camera can be configured, a Static IP address
must be assigned on your computer's network adapter in the subnet of
192.168.10.x. Since the Internet Camera's default IP address is
192.168.10.30, make sure no other network devices are assigned an IP
address of 192.168.10.30. (Refer to the Troubleshooting section on how to
configure TCP/IP settings on your PC.)
2. Enter user name and password,
then click OK.
User name: admin
Password: admin
3. Right click and select Active X
Control.
English
5
6. Click Network and then click
Wireless. Configure your wireless
settings to match your wireless
network's settings and then click
Apply (Enable/Enter the
WEP/WPA key when your wireless
network is encrypted. Contact
your network administrator for
more information).
(TV-IP212W/TV-IP312W only)
4. Click Install.
5. Click Setup and then click
Network. Configure the network
settings to be in the same subnet
as your network. Then click
Apply.
7. Disconnect the RJ-45 cable
(TV-IP212W/TV-IP312W).
8. Verify the Power and Link LEDs
are on.
Note: The TV-IP212W/TV-IP312W will not work wirelessly until you disconnect
the Ethernet cable from the back of the camera.
9. Click Live View. Then click
MJPEG compression if you are
using Firefox or Safari browser.
Note: For detailed information regarding the TV-IP212/ 212W/TV-
IP312/TV-IP312W configuration and advanced settings, please refer to the
Troubleshooting section, User's Guide on the Utility CD-ROM, or TRENDnet's
website at http://www.trendnet.com.
TV-IP
Your installation is now complete.
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register
Thank you for choosing TRENDnet
English
6
Q1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
Q5:
A5:
Q6:
A6:
The Image is blurry. How can I adjust the focus on the Internet camera?
You can adjust the Internet Camera’s focus by rotating the lens.
How do I configure TCP/IP settings on my computer?
When I click on Live View the image does not load?
First, make sure that you are using a browser that supports Active X (Internet Explorer)
or Java (Firefox or Safari). Second, make sure that Active X or Java is installed.
How do I connect the TV-IP212W/TV-IP312W to my wireless router or access point?
Make sure that you configure the camera to have the same SSID, encryption mode and
key (if enabled). Follow the instructions in section 2 to configure the camera with the SSID
and encryption key.
After I successfully configured the TV-IP212W/TV-IP312W to match my wireless network
settings, I can not connect to the camera.
First, verify that the wireless settings match your wireless network settings. Second,
verify in the wireless section of the browser configuration that the Enable option is checked.
Third, make sure to disconnect the Ethernet cable from the camera and verify that the LINK
LED is blinking green.
I forgot my password. What should I do?
Take a pin or paperclip and press the reset button on the back of the unit for 15 seconds.
This will return settings back to factory defaults. The default IP address is 192.168.10.30.
The default administrator ID and password is admin.
If you still encounter problems or have any questions regarding the TV-IP212/TV-IP212W/
TV-IP312/TV-IP312W, please contact TRENDnet’s Technical Support Department.
7
Troubleshooting
1. Go into the Control Panel and double-click
the Network Connections icon, and then
right-click the Local Area Connection icon
and then click Properties.
2. Click Internet Protocol (TCP/IP) and then
click Properties. Then click on Use the
following IP address, and make sure you
assign your network adapter an IP address
in the subnet of 192.168.10.x.
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de
alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al
mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador
de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria
existente en el pais o zona de instalación.
