TRENDnet’s TE100-S88E, 8-port palm-sized 10/100Mbps N-

way Ethernet Switch, present the perfect choice for small

workgroups for any desktop space. They allow users to simply

plug any port to either a 10Mbps or 100Mbps network to

multiply bandwidth, boost response time and satisfy heavy

load demands. With 8 ports readily available, The TE100-

S88E is easy to install and expand. The N-way ports

automatically negotiate between 10Base-T and 100Base-TX

network speeds, as well as between half- and full-duplex

modes. Thus, any port is capable of uplinking to Fast Ethernet

or downlinking to Ethernet. The TE100-S88E provide cost-

effective, and high-performance solutions.

TE100-S88E

8-Port 10/100Mbps N-Way Ethernet Switch

Compliant with IEEE 802.3 and IEEE 802.3µ

standards

8-port N-way 10/100M auto-detection

1 uplink/MDI-II connector for easy expansion

(shares with port 1)

Half- or full-duplex for each port

Operates at maximum packet filtering and

forwarding rate

Supports for store-and-forward of packet switching

256KB RAM buffer memory

Filtering Address Table up to 8K entries (per device)

Compact design for external power adapter

Comprehensive LED indications for port status

Network looped detecting

5 Year Warranty

FEATURES BENEFITS

Flexible:

Performance:

Easy-To-Use:

Reliable:

Compatible:

Connects both 10Mbps and 100Mbps

segments to one network.

All ports are full-duplex which double

network speed.

Built-in address self-learning

technology.

Store-and-Forward Ethernet packet

switching provides low latency and

high data integrity.

Complies with 10Base-T, IEEE802.3

and 100Base-TX, IEEE802.3µ

standards

TE100-S88E (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TE100-S55E: 5-port 10/100Mbps N-way Ethernet

Mini Switch

TE100-S55Eplus: 5-port 10/100Mbps N-Way

Ethernet Mini Switch

TE100-S88E: 8-port 10/100Mbps N-way Ethernet

Mini Switch

TE100-S88: 8-port 10/100Mbps N-way Ethernet

Switch

TE100-S1616: 16-port 10/100Mbps N-way

Ethernet Switch

TE100-S2424: 24-port 10/100Mbps N-way

Ethernet Switch

NETWORKING SOLUTIONS

SPECIFICATIONS

Standards:

• IEEE 802.3 for 10Base-T Ethernet

• IEEE 802.3µ for 100Base-TX Fast Ethernet

• ANSI/IEEE 802.3µ N-way auto-negotiation

Data Transfer Rate:

• 10/100Mbps (20/200Mbps in full-duplex mode)

Protocol:

• CSMA/CD

Connectors:

• 8 UTP/STP RJ-45

Network Media:

• UTP CAT 3, 4, 5 (100m) for 10Base-T

• EIA/TIA-568 100-ohm STP (100m) for

10Base-T/100Base-TX

• UTP CAT 5 (100m) for 100Base-TX

Packet Forwarding Rate:

• 10Base-T: 14,880 ppp per port (half-duplex)

• 100Base-TX/100Base-FX: 148,800 pps per

port (half-duplex)

Topology:

• Star

Diagnostic LEDs:

• Power, Link/Activity, Collision/Full-duplex, and

10/100Mbps status

Power:

• External power supply

(Max. power consumption: 18 W)

Dimensions:

• 171 x 98 x 28 mm (6.73 x 3.86 x 1.14 inches)

Weight:

• 460 g (1.01 lbs.)

Temperature:

• Operating: 0° to 50° C

• Storage: -20° to 70° C

Humidity:

• Operating: 10% to 90% RH

• Storage: 5% to 90% RH

Certifications:

FCC, UL, CE, CSA, C-tick, VCCI

TE100-S88E

8-Port 10/100Mbps N-Way Ethernet Switch

TE100-S88E

8-Port 10/100Mbps N-Way Ethernet Switch

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com

ORDERING INFORMATION

TRENDnet

TRENDware, USA
