TPA-311

1.01

Quick Installation Guide

English 1

1. Before You Start

2. 2

How to Install

Technical Specifications 3

Troubleshooting

Table of Contents

Version 09.17.2009

ENGLISH

ESPAÑOL

PORTUGUÊS

1. Before You Start

?Ethernet enabled device (e.g. PC, router)

?Existing RG-59/U Coaxial cabling

Package Contents

?TPA-311

?Multi-Language Quick Installation Guide

?Power Adapter (7.5V, 1A)

?Cat.5 Ethernet Cable (1.5 m/4.92 ft.)

System Requirements

ENGLISH

ESPAÑOL

PORTUGUÊS

2. Hardware Installation

1. Connect an Ethernet cable from Ethernet1 or

Ethernet2 on the TPA-311 to the Ethernet port

on your PC or Ethernet-enabled device.

2. Connect a coaxial cable from the HPNA port on

the TPA-311 to the F-type connector on the

wall.

3. Connect a coaxial cable from the HPNA port on

the TPA-311 to the F-type connector on your TV

set.

4. Connect the AC Power Adapter to the

TPA-311 and then to a power outlet.

Your Installation is complete

To ensure the highest level of customer service and support, please take a moment to

Thank you for choosing TRENDnet

For detailed information regarding the TPA-311 configuration and advanced settings, please

refer to the Troubleshooting section or TRENDnet's website at http://www.trendnet.com.

5. Verify that PWR, LAN1 or LAN2 and HPNA

LEDs are lit.

Technical Specifications

Standards

Interface ?HomePNA Coax: F-Type Female Coax

?TV Coax: F-Type Female Coax Connector

?2 x 10/100Mbps Auto-MDIX Ports

Data Transfer Rate ?Fast Ethernet: 100Mbps (half-duplex), 200Mbps (full-duplex)

?HPNA: Up to 256Mbps (PHY Rate), Up to 144Mbps (Throughput)

Flash Memory 1024Kb

Max Attenuator 60db@64Mbps

Point to Multipoint ?10 clients per band (CG3210 Environment)

?8 clients per band (Mix: CG3210, CG3110, CG3010)

Quality of Service 802.1p Priority Queue, TOS, Tag-based VLAN Pass through

QoS, Guaranteed QoS on HomePNA 3.1 parameterized QoS

Diagnostic LEDs ?PWR: Lights green when adapter is receiving power

?LAN1/LAN2: Lights green when the Ethernet port is connected

successfully. Blinks green when data is being transmitted or

received.

?HPNA: Lights green when the HPNA port is connected

successfully. Blinks green when data is being transmitted or

received.

?HPNA: 1600 meters

?Ethernet: 100 meters

Output : 7.5V DC, 1A

Distances

Power Adapter

4.5W(max)

Power Consumption

118.47 x 82.13 x 30 mm (4.664 x 3.233 x 1.18 in)

Dimensions

0.14kg (5 oz.)

Weight

?Operating: 0 ~ 40 C (32° ~ 104° F)

?Storage: -10° ~ 65° C (14° ~ 149° F)

° °

Temperature

10% ~ 95%, non-condensing

Humidity

CE, FCC

Certifications

?HomePNA 3.1 over Coaxial Cable

?IEEE 802.3, IEEE 802.3u

?ITU-T G.9954

After connecting the TPA-311 to a power outlet, the PWR LED does not turn on.

1. Check the connection of the external power adapter to the TPA-311 and the power outlet.

2. Check that the power outlet is receiving power.

The PWR LED is on, but the LAN LED does not turn on. What should I do?

1. Make sure the Ethernet cable is firmly connect on both the TPA-311 and the opposing

connection.

2. Try another Ethernet cable.

3. The maximum distance for Ethernet is 100 meters (333 feet). Do not use an Ethernet cable

longer than 100 meters.

The PWR LED is on, but the HPNA LED does not turn on. What should I do?

1. Make sure the Coaxial cable is firmly connected on both the TPA-311 and the F-connector.

2. Second, the maximum distance is 1600 meters (5,249 feet). Do not use a Coaxial cable

longer than 1600 meters.

If you still encounter problems or have any questions regarding the TPA-311, please contact

TRENDnet's Technical Support Department.

Troubleshooting

Limited Warranty

- 2 Year Limited Warranty

AC/DC Power Adapter, Cooling Fan and Power Supply carry a 1 year limited warranty

TRENDnet warrants its products against defects in material and workmanship, under normal

use and service, for the following lengths of time from the date of purchase.

TPA-311

If a product does not operate as warranted during the applicable warranty period, TRENDnet

shall reserve the right, at its expense, to repair or replace the defective product or part and deliver

an equivalent product or part to the customer. The repair/replacement unit's warranty continues

from the original date of purchase. All products that are replaced become the property of

TRENDnet. Replacement products may be new or reconditioned. TRENDnet does not issue

refunds or credit. Please contact the point-of-purchase for their return policies.

TRENDnet shall not be responsible for any software, firmware, information, or memory data of

customer contained in, stored on, or integrated with any products returned to TRENDnet

pursuant to any warranty.

There are no user serviceable parts inside the product. Do not remove or attempt to service the

product by any unauthorized service center. This warranty is voided if (i) the product has been

modified or repaired by any unauthorized service center, (ii) the product was subject to accident,

abuse, or improper use (iii) the product was subject to conditions more severe than those

specified in the manual.

Warranty service may be obtained by contacting TRENDnet within the applicable warranty

period and providing a copy of the dated proof of the purchase. Upon proper submission of

required documentation a Return Material Authorization (RMA) number will be issued. An RMA

number is required in order to initiate warranty service support for all TRENDnet products.

Products that are sent to TRENDnet for RMAservice must have the RMAnumber marked on the

outside of return packages and sent to TRENDnet prepaid, insured and packaged appropriately

for safe shipment. Customers shipping from outside of the USA and Canada are responsible for

return shipping fees. Customers shipping from outside of the USA are responsible for custom

charges, including but not limited to, duty, tax, and other fees.

Product Warranty Policy

WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE AS

WARRANTED ABOVE, THE CUSTOMER'S SOLE REMEDY SHALL BE, AT TRENDNET'S

OPTION, REPAIR OR REPLACE. THE FOREGOING WARRANTIES AND REMEDIES ARE

EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED,

EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING

WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

TRENDNET NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME

FOR IT ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION

MAINTENANCE OR USE OF TRENDNET'S PRODUCTS.

TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND

EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT

EXIST OR WAS CAUSED BY CUSTOMER'S OR ANY THIRD PERSON'S MISUSE, NEGLECT,

IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO REPAIR OR

MODIFY, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY

ACCIDENT, FIRE, LIGHTNING, OR OTHER HAZARD.

LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET ALSO

EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER BASED IN

CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL,

INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OFANY KIND, OR FOR LOSS OF REVENUE

OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATE, OR OTHER

FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION,

MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF THE

POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR,

REPLACEMENT, OR REFUND OF THE PURCHASE PRICE PAID,AT TRENDNET'S OPTION.

THIS DISCLAIMER OF LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY

REMEDY PROVIDED HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.

Governing Law: This Limited Warranty shall be governed by the laws of the state of California.

Some TRENDnet products include software code written by third party developers. These codes

are subject to the GNU General Public License ("GPL") or GNU Lesser General Public License

("LGPL").

Go to or Download section and look for

the desired TRENDnet product to access to the GPL Code or LGPL Code. These codes are

distributed WITHOUT WARRANTY and are subject to the copyrights of the developers.

TRENDnet does not provide technical support for these codes. Please go to

or for specific terms of

each license.

http://www.trendnet.com/gpl http://www.trendnet.com

http://www.gnu.org/licenses/gpl.txt http://www.gnu.org/licenses/lgpl.txt

PWP05202009v2

Certifications

This equipment has been tested and found to comply with FCC and CE Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received. Including interference that may

cause undesired operation.

Waste electrical and electronic products must not

be disposed of with household waste. Please

recycle where facilities exist. Check with you Local

Authority or Retailer for recycling advice.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV

INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.

SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE

EQUIPMENT.

ADVERTENCIA

En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de

alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al

mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador de

alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria

existente en el pais o zona de instalación.

Product Warranty Registration

Please take a moment to register your product online.

Go to TRENDnet’s website at http://www.trendnet.com/register
