TRENDnet TV-IP110W - Wireless Internet Camera Server... Bedienungsanleitung

• Quick Plug and Play installation

• Supports TCP/IP networking, SMTP Email*, HTTP

• High quality MJPEG video recording with up to 30 frames per second

• Record streaming video to your computer

• Compatible with wireless g and b devices

• Advanced encryption mode include WEP, WPA-PSK(TKIP), WPA2-PSK

• Supports still image snapshot to FTP and Email

• Motion detection with Email notification*

• Control two adjustable motion detection windows with just-in-time snapshot

• Supports time stamp overlay

• Free SecurView™ software: view and record up to 16 cameras simultaneously **

• 3-year limited warranty

* Monitoring multiple cameras may require a high performance CPU and graphics card

FEATURES

The Wireless Internet Camera Server (TV-IP110W) transmits real-

time high quality video over the Internet. View your camera from any

Internet connection. Complimentary SecurView camera

management software provides advanced monitoring of up to 16

cameras to protect what you value most.

This stylish and compact Internet camera provides crystal clear

MJPEG video streams.

Mount the wireless camera on most surfaces with an included

mounting kit. Intuitive software features motion detection recording,

email alerts*, and scheduled recordings. The camera’s brilliant image

quality, intuitive setup and complimentary software make it ideal for

your home or office.

TV-IP110W (A1.0R)

SecurView Wireless Internet Camera

medianet

TV-IP110W

rev: 07.19.2010

* Does not support SSL

** Monitoring multiple cameras may require a high performance CPU and graphics card.

SPECIFICATIONS

Resolution

Compression Ration Setting

Fixed Lens

Resolution

Flip Images

LAN

Image Setting

Protocol

• ¼” Color CMOS Sensor

• 5 Levels

• 640 x 480 pixel

• 640 x 480, 320 x 240, 160 x 120

• Vertical / Horizontal

• HTTP, FTP, TCP/IP, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, PPPoE, UPnP

• f: 4.6mm, F: 2.6 (Board Lens)

• Adjustable brightness, saturation & contrast

• 30fps @VGA, QVGA, QQVGA

• 10/100Mbps Auto MDIX

Image Frame Rate

Frame Rate Setting

Video/Image

Communication

Sensor

Image Sensor

• 1 ~ 30fps

RAM

CPU

Memory Size

Resolution

• ARM9 base

• 16Mbyte SDRM

• Linux

• 350MHz or above

• 256MB RAM or above, 512MB RAM or above

• 800 x 600 or above

System Requirement (Web Configuration)

CPU

System

SecurView Wireless Internet Camera

TV-IP110W

Minimum Illumination • 0.5Lux

Viewing Angle • 60 Degree

Light Frequency • 50Hz, 60Hz or Outdoor

Exposure Control, White Balance,

Gain Control • Automatic

Video Format • MJPEG

ROM • 4Mbyte Nor Flash

Browser • Internet Explorer 6.0 or above

Supported OS • Windows 2000/XP/Vista

CPU

Memory Size

Resolution

• 1GHz or above

• 512MB or above

• 1024 X 768 or above

System Requirement (SecurView™ Software)

Supported OS • Windows 2000/XP/Vista

Zoom • 3 x Digital Zoom

TV-IP110W

rev: 07.19.2010

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

SecurView Wireless Internet Camera

TV-IP110W

To Order Please Call:

1-888-326-6061

ORDERING INFORMATION

RELATED PRODUCTS

PACKAGE CONTENTS

• Multi-Language Quick Installation Guide

• Power Adapter (5V DC 2.5A)

• TV-IP110W

• Utility CD-ROM

TV-IP212W

TV-IP110

TV-IP312W SecurView Wireless Day/Night Internet Camera

SecurView Wireless Internet Camera

SecurView Internet Camera

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

Dimension

Weight

Power Consumption

LEDs

Power

Temperature

• xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx

• 70 x 100 x 57mm (2.67 x 3.94 x 2.95 in.)

• Camera: 125g (4.4oz.); Stand: 135g (4.76oz.)

• Enable/Disable Support

• 6 Watts (Max)

• Operating: 0ºC ~ 45ºC (32ºF ~ 113ºF); Storage : -10ºC ~ 60ºC (14ºF ~ 140ºF)

• 5V DC, 2.5A External Adapter

• Power (Orange), Link (Green)

Physical/Environmental

SPECIFICATIONS

NETWORKING SOLUTIONS

• 1.8m/5.9ft Cat.5 Fast Ethernet cable

• Camera Stand

Wireless Internet Camera Server

(TV-IP110W)

Wireless G Firewall Router

(TEW-432BRP)

54Mbps

Modem

Notebook with

Wireless G PC Card

(TEW-421PC)

Internet

Standard

Security

Antenna

• 64/128bit WEP (HEX/ASCII),WPA-PSK(TKIP/AES), WPA2-PSK (TKIP/AES)

• 2dBi detachable Reverse SMA Connector

Wireless

• IEEE 802.11b/g
