TRENDnet TEW-652BRU Bedienungsanleitung

300Mbps Wireless N Home Router with USB Port

TEW-652BRU

1.01

ŸQuick Installation Guide (1)

Minimum Requirements

USB Port Software Utility Requirements

TEW-652BRU

Multi-Language Quick Installation Guide

CD-ROM (Utility and User's Guide)

Network cable (1.5 m / 5 ft.)

Power adapter (5V DC, 2A)

Computer with an Ethernet port and Web browser

Broadband Internet

Installed modem

Package Contents

1. Before You Start

Supported Operating

Systems CPU Memory

Windows 7 (32/64-bit)

Windows Vista (32/64-bit)

Windows XP (32/64-bit)

1GHz or above

800MHz or above

300MHz or above

1GB RAM or above

512MB RAM or above

256MB RAM or above

Mac OS X (10.6)

Mac OS X (10.7)

1.06GHz or above

1GB RAM or above

2GB RAM or above

Mac OS X (10.5) 867MHz or above 512MB RAM or above

Mac OS X (10.4) 333MHz or above 256MB RAM or above

2. Installation

1. Verify that you have an Internet connection.

2. Power down your modem.

3. Disconnect the network cable from your modem and your computer.

4. Connect your modem to the TEW-652BRU's WAN port.

5. Connect your computer to one of the TEW-652BRU's LAN ports.

6. Connect the power adapter to the TEW-652BRU and then to a power outlet. Push the power button

to the “On” position.

7. Power on your modem. Wait until the LEDs indicate that modem is fully booted up. For more

information on your modem's LEDs, please consult with your modem's User's Guide.

8. Verify that the status LED indicators on the front of the router to confirm that the device is fully

functional (Power is solid green, Status is blinking green, WAN and WLAN (Wireless) are solid

green, and the LAN port for which your computer is connected is solid green).

WAN

9. Open your web browser, type

http://192.168.10.1 in the Address bar, and

then press Enter.

10. Enter the User Name and Password and

then click OK. By default:

User Name: admin

Password: admin

Note: User Name and Password are case

sensitive.

11. The Wizard will automatically appear. If the

Wizard does not automatically appear, click

the Wizard button on the bottom left side of

your screen.

13. Open up your browser and enter in a URL

(e.g. www.trendnet.com) to verify that you

have Internet connection.

Note: For instructions on using your USB

device with the TEW-652BRU, please refer

to the User's Guide on the provided

CD-ROM.

12. Follow the setup Wizard's instructions and

then click Restart.

Note:

ŸTo protect your network from

unauthorized access it is recommended

to enable wireless encryption. Please

refer to the User's Guide on the CD-ROM

for information on setting up encryption.

ŸOnce encryption is enabled on the

router, make sure your encryption key is

in a safe location. The router now

prompts users to input the encryption key

when connecting for the first time.

Wireless router installation is now complete

For detailed information regarding the TEW-652BRU’s configuration and advanced settings, please refer to the

User's Guide included on the CD-ROM, or TRENDnet's website at http://www.trendnet.com.

TRENDnet

20675 Manhattan Place

Torrance, CA 90501. USA
