TRENDnet TW100-S4W1CA Bedienungsanleitung

FCC Warning

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a commercial environment.

This equipment generates, uses and radiates radio frequency energy. If not

installed and used in accordance with the instructions, it may cause

harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful interference. In

this case the user will be required to correct the interference at their own

expense.

CE Mark Warning

This is a Class B product. In a domestic environment, this product may

cause radio interference, in which case the user may be required to take

adequate measures.

TABLE OF CONTENTS

About This Guide..................................................................................1

Purpose ............................................................................................1

Overview of this User’s Guide..........................................................1

Introduction .........................................................................................3

Applications: ....................................................................................4

Features: ..........................................................................................5

Unpacking and Setup ...........................................................................5

Unpacking ........................................................................................5

Setup ................................................................................................5

Hardware InstalLation..........................................................................7

Front Panel.......................................................................................7

Rear Panel ........................................................................................8

Side Panel.........................................................................................9

Hardware connections ...................................................................10

Connect the Internet Broadband Router ...................................10

Check the installation.................................................................11

PC Network TCP/IP Setting ................................................................11

Windows 7/ Vista ...........................................................................11

Windows XP/2000..........................................................................12

Windows NT4.0..............................................................................12

Windows 95/98/ME .......................................................................14

4-Port Broadband Router Configuration............................................16

Quick Setup ....................................................................................17

Advanced Setup .............................................................................22

Technical Specifications ....................................................................44

Limited Warranty...............................................................................46

ABOUT THIS GUIDE

Congratulations on your purchase of this 4-Port Broadband Router! This

device integrates 100Mbps Fast Ethernet and 10Mbps Ethernet network

capabilities. This router is a complete solution for sharing the Internet

and other office resources.

Purpose

This manual discusses how to install the 4-Port Broadband Router.

Overview of this User’s Guide

Introduction. Describes the Broadband Router and its features.

Unpacking and Setup. Helps you get started with the basic installation of

the Router.

Identifying External Components. Describes the front panel, rear panel,

and LED indicators of the Router.

Connecting the Router. Explains how you connect the Router to your

xDSL/Cable Modem.

Technical Specifications. Lists the technical (general, physical and

environmental, performance and Routers settings) specifications of the

Broadband Router.

INTRODUCTION

With the explosive growth of the Internet, accessing information and

services at any time, day or night, has become standard fare for most

people. The era of the standalone PC is waning. Networking technology is

moving out of the exclusive domain of corporations and into homes with

at least two computers.

Broadband network access is also gaining ground. Allowing more than

two computers to access the Internet at the same time, however, has

typically entailed significantly higher costs. Thus, there is a great demand

for technology that enables users to share a single Internet connection.

Employing a router to share an Internet connection solves the problem

of high network access costs. Using such a device, each networked

computer is able to make full use of broadband capabilities.

This device not only comes equipped with a wide range of features but

also can be installed and configured right out of the box. This device

supports a simple local area network and Internet access sharing.

A local area network connects home computers and enables users to

access the Internet, share resources, and play online games –the

essentials of the family computing lifestyle.

Applications:

Broadband Internet access sharing:

Enable several computers to share a single high-speed broadband

Internet connection (LAN and WAN-Internet).

Resource sharing:

Share printers, scanners, and other peripherals.

File sharing:

Exchange data, messages, and files -- thus making good use of hard disk

space.

Online gaming:

Your local area network allows you to play online games and use e-

commerce services.

Firewall:

A built-in firewall function protects against hackers.

Features:

1 x 10/100Mbps port (WAN/Internet)

4 x 10/100Mbps Auto-MDIX ports (LAN)

Supports Cable/DSL Modems with Dynamic IP, Fixed IP,

PPPoE, and PPTP connection types

Provides Network Address Translation (NAT) Firewall

Supports Virtual Servers (Port Forwarding 10 Entries) and

DMZ (5 Entries)

Supports static routes (20 entries)

Client Filtering by Date/Time (6 Entries and Special

Applications Filter 10 Entries)

MAC Address control to allow or deny access (32 entries)

Supports Dynamic DNS service

Multiple VPN pass-through sessions for IPsec, L2TP, and

PPTP (8 VPN sessions)

Web URL Filtering (32 URL entries)

Universal Plug and Play (UPnP) and Application Level

Gateway support for Internet applications such as email,

FTP, gaming, and more

Easy Web browser configuration and remote management
