UniGuard GT06R Bedienungsanleitung

UniGuard Technology Limited

GSM/GPRS/GPS TRACKER

USER MANUAL

(GT06R)

UniGuard Technology Limited

Welcome purchasing the Accurate Pro, please read user manual

carefully

◆Specification

Content

Specs.

Dim.

97 mm x 51 mm x 15 mm

Weight

80g

Chip

MTK2503AV

Network

GSM/GPRS/GPS, TCP/IP

Battery

120mAh

Band

850/900/1800/1900 Mhz

GPS sensitivity

-159dBm

GPS accuracy

10m

Time To First Fix

Cold status 45s-90s

Warm status 50s

Hot status 15s

Work voltage

12V-36V

Storage Temp.

-40°C to +85°C

Operation Temp.

-20°C to +55°C

Humidity

15%--95%

Accessory

Remote controller

External horn

Relay

SOS

Microphone

Car Siren

◆Main Feature

1. Real-time Tracking

2. Remote engine control

3. Two way calling

4. Geo-fencing

5. SMS inquiry

6. Car Finding

7. Anti-theft armed/disarmed

8. One key to cut fuel.

9. One key for SOS

◆SIM card installation

Please insert SIM card before turning the device power switch to

on;The SIM card need open the data GPRS service; please make sure

SIM card with enough balance.

UniGuard Technology Limited

◆Device light description

Color

Represents

Status

Red

Power supply

Stable light on

Yellow

GSM signal

Stable light on

Green

GPS signal

Stable light on

Note: All lights will turn off after 5 minutes, if you call the

device number, lights will wake up.

◆Power Wires connection

1)4P power red wire connects to vehicle power positive +

2)4P power black wire connects to vehicle power negative -

3)4P power yellow wire connects to fuel pump or electricity control wires

4)4P power green wire connects to ACC ignition wire.

5) Horn cable connection: Make sure black cable to black, Red to Red.

6) Other wires connecting to relative accessories in package. If press the

SOS button 3-4 s, device will reply "SOS alarm!" to authorized number.

Controller buttons:

Button

Function

Description

ARM

Cut fuel

Short Press to arm (Horn beep in emergency)

Long Press for 3s to cut off fuel/oil.

DISARM

Recover fuel

Short Press to disarm (Horn beep will be cancel).

Long press for 3s to recover fuel/oil.

Mute Horn

SOS

Short Press , to turn off car finding horn beep.

Long Press for 3s for SOS alarm

Car Finding

Short Press to activate horn honking for car finding.

◆Device wiring diagram

UniGuard Technology Limited

◆Installation attentions

NOTE: device front side towards the sky.

Installation: if the windscreen glued by metal thermal insulation layer or

heating layer, it will reduce the GPS receive signal and lead to GPS work

disorder.

UniGuard Technology Limited

Function

SMS Command

Example

Default password:123456, each command must get a reply represents configure OK

World APN refer to website: http://bigfun.tripod.co.uk/

Step1 IP and Port setting

#IP#password#ip address#port#

#IP#

123456#121.201.109.14#696

Step2 Setting APN

#apn#password#APN content#APN

user name#APN password#

#apn#123456#cmnet#

Step3 Single Locating

#smslink#password#

More Features Below (Not necessary)

Check device parameters

TCP

Cut fuel or electricity

#stopoil#password#

#stopelec#password#

#stopoil#123456#

#stopelec#123456#

Recover fuel or

electricity

#supplyoil#password#

#supplyelec#password#

#supplyoil#123456#

#supplyelec#123456#

Set password

#password#old password#new

password#

#password#123456#666888#

Set ACC ON alarm

Cancel ACC ON alarm

#ACC#ON#

#ACC#OFF#

Set overspeed alarm

#speed#password#speed number#

#speed#123456#080#

Cancel overspeed alarm

#nospeed#password#

#nospeed#123456#

Set time Interval

#at#time interval#sum#0#

#at#10#sum#0#

Resume password

#resume#

Set admin number

#admin#password#cell phone

number#

#admin#123456#1381234567

Cancel admin number

#noadmin#password#number#

#noadmin#123456#13812345

678#

Initialization

#begin#password#

#begin#123456#

UniGuard Technology Limited

◆Web platform GPS tracking software

Website: www.gpspos.net

Default IMEI as user name, password 123456.

Searching name “GPSPOS” to download APP from GooglePlay or Apple

store.

Guarantee Card

Voice Surveillance

#monitor#password#

#monitor#123456#

Recover Tracker Mode

#tracker#password#

#tracker#123456#

Two-way calling

#call#password#

#call#123456#

Turn on SMS alert

#KC#123456#1#

Kc ok

Trun on Call alert

#KC#123456#2#

Kc ok

Arming Car

arm123456

Disarming Car

disarm123456

Car Finding Honking

find123456

Mute horn

silent123456

Turn off vibration alarm

#vibrate#123456#0#

#yibrate#123456#0#

Two-way call Mode: use phone to dial the device number, car horn or speaker rings, press

SOS button to pickup the call so it can realize two-way talking function.

Car finding horn will honk for 10s and can be muted manually.

User Name

Phone

Purchase Date

IMEI No

1.Within warranty period, if any damage caused by the product's own quality, user

can bring the purchasing invoice and warranty card to supplier to arrange repair.

2.Those machines that has refitted or added other functions by user own will not be

accepted to repair.

3.Attempt to disassemble the product can damage it and void your warranty.

4.This card and the purchasing invoice are both considered as a receipt for repair,

please reserve it carefully.
