UT07/UT07L OBD GPS Tracker

User Manual

(Version V1.0)

Thank you very much for using GPS TRACKER, the user manual will guide how to operate this

product, please read it carefully before using it in order to get the correct method of operation. If

the appearance, color and accessories of this product are modified, please refer to the actual

product. The manufacturer is not liable for faults and omissions which in the user manual.

www.uniguardgps.com

UniGuard Technology Limited

、

Product functions & Parameters

1.1 Product functions

Location inquiry, geo-fence, over-speed alarm, power-off alarm, historical route playback,

voice monitoring

1.2 Parameters

●UT07 2G Frequeny: 850/900/1800/1900 Mhz;

●UT07L 4G Frequeny: LTE FDD: B1/2/3/4/5/7/8/28/66 and 850/900/1800/1900 Mhz;

●Wide voltage input range: 8 - 24V;

●Location time: average warm start:≤3sec(open sky)

Average cold start:≤35sec(open sky)

●Device dimensions:42mm × 28mm × 17mm;

●Location accuracy:≤10 meters;

●Working Temp:-20℃ - 75℃

●Backup battery: 200mAh

、

Product accessories and LED light status

2.1 Accessories:

Standard: device, user manual

2.2 Device LED light status

2.2.1 Yellow LED (GSM signal status)

Light status

Meaning

Flash every 2 seconds

GSM initialization

GPRS normal communication/online

off

GSM sleep/power off

2.2.2 Blue LED (GPS signal status)

Light status

Meaning

Flash every 2 seconds

GPS signal searching

GPS location finished

off

GPS sleep/power off

、

Installation instructions

3.1 Preparation before installation:

1, Open the box and check whether the device and the accessories are complete, otherwise please

contact your dealer.

2, SIM card selection, the device works with Micro SIM card, and support full Netcom band.

3, SIM card installation, SIM card corner inside, chip face to the side with shrapnel, which can help

to hold the card.

Note: (1) Before installing or removing the SIM card, please switch off the device;

(2) Should activate the GPRS function of the SIM card;

www.uniguardgps.com

UniGuard Technology Limited

(3) Should activate the caller ID function; (activate or not according to the

functions you chose.)

(4) If your SIM card required you to input the SIM PIN, please refer to your

mobile phone user manual to turn off the SIM PIN function.

(5) Please ensure that the SIM card is valid.

3.2 Installation

Device with standard OBDII socket

、

SMS commands and instructions:

Send SMS command from user’s SIM card number to the SIM card number which inside the

GPS device.

The commands in the following SMS command list are in English input format, and the letters

are case-sensitive according to the instruction requirements.

Common commands

SMS command format

Device reply

Check setup

CXZT

Version, ID, IP, etc…

Set admin number

admin123456 15012404563

Admin ok

Set new password

pwd123456 654321

Password reset okay.

Device restart

CQ OK

Restore factory settings

FORMAT

FORMAT OK

Revise APN

NAPN=cmnet,,

APN OK

Over speed alarm

SZCS#SPEED=120

SETOK:SPEED=90

、

App

Search GPSPOS at Appstore

Search POSGPS at Google Play
