UNINEX KOOLZONE Gebrauchsanweisung

UNINEX INTERNATIONAL

5780 SMITHWAY STREET COMMERCE, CA 90040

T. 800-864-3288 / 323-890-9246 / F. 323-890-9249

KOOLZONE

MOBILE SPOT COOLER

THANK YOU FOR PURCHASING THE KOOLZONE MOBILE SPOT COOLER.

PLEASE READ THE INSTRUCTIONS BEFORE USING.

AND PLEASE KEEP THESE INSTRUCTIONS FOR REFERENCE.

QUICK USER GUIDE FOR N407-TC

MANUAL - COLD AIR DUCT / HEAT-REMOVAL DUCT FITTING

PARTS OF THE MACHINE

UNINEX.COM 800.864.3288

INSTALLATION

1. Installing the duct: Fit the elbow into the upper part of the body and press in until it clicks.

2. How to install the cold air duct: Fit the recess of the elbow into the convex of the duct, then turn it counter- clockwise until it stops.

3. How to install the heat-removal duct: When inserting the heat-removal duct, please note the heat-removal mouth recess.

Heat-Removal Duct

Cold Air Duct

Duct Cap

Operation Spot

Revolving Switch Swing Switch

Duct Elbow

Drain Tank (5L)

Particle Filter

Caster

Heat-Removal Mouth

High

Swing Switch

OFF

Low

Off

Power

Insertion

Heat-Removal Mouth

Cooling Duct

Convex

Recess

Swing Installment

*When installing the duct elbow,

please note, not to bump

the swing installment.

Drain Hose

TURN THE SPOT COOLER ON/

DIRECTION ADJUSTMENT

DRAIN TANK / DIRECT DRAIN

IMPORTANT - KEEP DISTANCE

Heating Outlet

Direction above 80cm

Air Outlet

Direction above 30cm

Cooling Outlet

Direction above 30cm

UNINEX.COM 800.864.3288

200º

High

Swing Switch

OFF

Low

Off

Power

Drain Tank

Extraction

Drain Mouth

⏀

Extraction Drain Tank

Red Water Line

Base Hole

Draining Water Mouth

PLEASE NOTE

UNINEX.COM 800.864.3288

OPTIMUM OPERATING TEMPERATURE RANGE FOR

KOOLZONE MOBILE SPOT A/C COOLER

IS FROM 64 - 104° FAHRENHEIT.

PROPER USUAGE OF THIS UNIT, AT THE COOLING DUCT,

WILL REDUCE THE AMBIENT TEMPERATURE

BETWEEN 10 - 15° FAHRENHEIT.

MAKE LIFE SIMPLE AND MORE CONVENIENT

WITH UNINEX

EXCLUSIVELY DISTRIBUTED BY:

UNINEX INTERNATIONAL

5780 SMITHWAY STREET COMMERCE, CA 90040

T. 800-864-3288 / 323-890-9246 / F. 323-890-9249

MANUFACTURE:

NAKATOMI CO.,LTD.

6445-2, TAKAI, TAKAYAMA, KAMITAKAI, NAGANO, JAPAN

SCAN ME
