Uplus Lighting PF350 Bedienungsanleitung

User manual

PF350

Please read the instructions carefully before use

TABLE OF CONTENTS

1. Safety Instructions……………………………………………………………………………3

Technical Specifications………………………………………………………………………4

Control Panel ……………………………………………………………………………………4-5

DMX Channels ……………………………………………………………………………………5

Trouble Shooting…………………………………………………………………………………6

Fixture Cleaning………………………………………………………… ………………………6

STATEMENT

The product has well capability and intact packing when leave factory. All of the user should

comply with warning item and manual, any misuse cause of the damages are not included in our

guarantee, and also can not be responsible for any malfunction & problem owing to ignore the

manual.

1.Safety Instructions

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also

receive this instruction booklet.

•Unpack and check carefully there is no transportation damage before using the unit.

•Before operating, ensure that the voltage and frequency of power supply match the power requirements of the

unit.

•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

•The unit is for indoor use only. Use only in a dry location.

•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent surfaces. Be sure

that no ventilation slots are blocked.

•Disconnect main power before replacement or servicing.

•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.

•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always by taking its

base.

•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher than this Unit

surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand during its operation. Turn off

the power and allow about 15 minutes for the unit to cool down before replacing or serving.

•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit by yourself.

Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the nearest authorized

technical assistance center. Always use the same type spare parts.

•DO NOT touch any wire during operation as high voltage might be causing electric shock.

Warning:

•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.

•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

Caution:

•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any repairs yourself. In

the unlikely event your unit may require service, please contact your nearest dealer.

Installation:

•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid

vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is

secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can

hold 12 times of the weight of the unit when installing the fixture.

•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the touch of

people.

2.Technical Specifications

Lamp: LED 350W import LED

Color Temperature: 3200K / 4500K / 6500K / 8500K

Power Consumption: 600 W

Power Voltage: AC 220V-240V, 50/60Hz

Average life: 50000H, control lamp on/off

Color：5 colors + white(ROYGBW)

Zoom：adjust the room big or small, manual adjustment the definition

Strobe：1-11hz/S

Projection distance：5-50meters/5-120meters

Cooling system: use 6piece 8 mm thick copper tube heat conduction through 66 pieces of large

aluminum radiator, ensure the LED bead heat cooling, make the light within the normal range,

guarantee the life of lamp bead. If the temperature is too high, will Trigger high-pressure protection,

use new aluminum exterior design, the light is beauty and generous

Light size：600*220*220mm

Light weight：12KG

3.Control Panel

Control Panel:

1) Power switch;

2) Power connector;

3) OLED display;

4) Fader block to control the CRT wheel, iris, dimmer,

stroboscope;

5) Color selection buttons;

6) Button on / off the light source;

7) XLR connectors, for controlling the spotlight via DMX.

4.DMX Channels

Control mode:

When a DMX signal is input, the DMX control mode takes precedence; OLED display

displays DMX channel address

Channels

Function

Value

CTO

IRIS

0--255

Dimming

0--255

Strobe

0-9 disabled

10-255 slow to fast

Color

0-9 white

10-49 red 1

50-99 yellow 2

00-149 blue 3

150-199 green 4

200-255 orange 5

5.Trouble Shooting

ollo

ing

few

oble

y occu

uring

ope

tion

. He

tion

leshooting

The

does

work

, no

ght

Check

nect

ion of p

owe

eas

ure

ins

volt

Check

pow

LED

responding

LED

on.

che

nectors,

link

ope

If th

nd no

espons

el,

che

ess

etti

s a

ity

nter

ittent

oble

che

ins

onn

ecto

PCB

nit

the

iou

ntroller

Check

or run

lon

volta

les

terfer

ence

inter

face

circui

. One

the

cha

ing

tep

moto

dam

the

nect

to th

PCB

oken.

oto

’

ive

PCB

ndition

6.Fixture Cleaning

The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to

optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,

smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.

Clean with soft cloth using normal glass cleaning fluid.

Always dry the parts carefully.

Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
