Vax Advance VX96 Bedienungsanleitung

LET’S GET STARTED.

VX96

BARREL

VACUUM

vax.com.au

vax.co.nz

Advance

VACUUM CLEANER

Let’s talk safety

Basic

safety

precautions

Don’ts

Do’s

This vacuum cleaner is intended for household use only and

NOT for commercial or industrial use.

READ ALL THE INSTRUCTIONS BEFORE USING

THIS APPLIANCE

• Only use the vacuum cleaner indoors and keep the area you’re

cleaning well lit.

• Keep ngers, hair and loose clothing from moving parts and

openings whilst using the vacuum cleaner.

• This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities

or lack of experience and knowledge unless they have

been given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

• Don’t pull or carry by cord, use cord as a handle, close a door

on cord, or pull cord around sharp edges or corners. Do not

place product on cord. Do not run appliance over cord.

• Don’t handle the plug or use the vacuum cleaner with wet

hands.

• Don’t use the vacuum cleaner with incorrect voltage as

this may result in damage or injury to the user. The correct

voltage is listed on the rating label.

• Don’t vacuum up hot coals, cigarette butts, ash, matches or

smoking hot burning items or use in an area where there

may be harmful uids (chlorine, bleach, and ammonia drain

cleaner).

• Always make sure the lter and dirt container are tted

correctly before using your vacuum cleaner.

• Turn o all controls on the vacuum cleaner before

disconnecting or connecting the battery.

• Take extra care when cleaning on the stairs.

• Always switch o the vacuum cleaner before disconnecting

or connecting the hose and accessories.

• Always protect the cord from heated surfaces

or near open ames.

Children should not play with the vacuum cleaner. Cleaning and user

maintenance should not be made by children without supervision

• Only Vax recommend tools and accessories should be used with this

vacuum cleaner

• Vax recommends the use of a Residual Current Device rating of 30 mA or less.

• If the supply cord is damaged, it must be replaced by the manufacturer,

or similarly qualied person in order to avoid a hazard, or invalidating

the warranty.

• IMPORTANT: The motor is equipped with a thermal cut-out. If for any

reason the unit should overheat, the thermostat will automatically turn the

unit o. Should this occur, unplug the vacuum cleaner from the electrical

outlet and turn o the switch. Remove dirt container and empty. Clean

lters. Allow the unit to cool for approximately one (1) hour. To re-start,

plug into an electrical outlet and switch back on.

• Don’t attempt to remove blockages with sharp objects as this may cause

damage to the vacuum cleaner.

• Don’t vacuum hard or sharp objects such as glass, nails, screws or coins etc.

• Don’t not vacuum plaster dust, concrete dust or any other building

or vitreous material.

• Don’t vacuum our, baking soda or any other powder-based carpet refresher

or deodoriser.

• Don’t use this vacuum cleaner if it has been dropped, damaged or left outdoors.

• Don’t vacuum up any ammable or combustible materials (lighter uid, petrol,

kerosene etc.) or use the vacuum cleaner in an area with explosive vapours

or liquid.

• Use only SAA approved 10amp extension cords. Care should be taken to

arrange the extension cord as it can be a trip hazard.

• Always carry the vacuum cleaner by the handle.

• Store your vacuum cleaner in a cool, dry area.

• Always keep the power cord away from the brushes whilst using your

vacuum cleaner.

PLEASE KEEP INSTRUCTIONS FOR FURTHER USE.

Thank you for buying this Compact Vacuum Cleaner.

Taking care of your carpets and hard oors

The Compact Vacuum Cleaner is designed to make vacuuming carpets and hard oors regularly

as eective and ecient as possible and this user guide will help you get the most out of your

machine. Maintaining your carpets will ensure they keep their appearance for longer. You’ve

chosen the carpets and hard oors for your home for a reason and Vax will help you take good

care of them.

Taking care of your Compact Vacuum Cleaner

Also inside this guide are instructions on maintaining your new machine, so that it’s always ready

when you are to tackle your carpets and hard oors.

We’re here if you need us

For troubleshooting simply visit or call:

Australia: 1300 VAX AUS (1300 829 287)* vax.com.au

New Zealand: 0800 VAX NZL (0800 829 695)* vax.co.nz

*Monday – Friday: 8:30am -5:00pm

Calls are charged at the standard local rate. Please make note of the serial

number and model number of the product before calling.

Contents

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

What to do if it goes wrong

Getting in touch

Accessories

Notes

Compact Vacuum Cleaner

Included with

your machine

Telescopic wand

Dusting brush

Crevice tool

Hose and handle

Combination oor tool

Getting to know your machine

Name Advance Bagless Vacuum Cleaner

Model VX96

Voltage 220-240V ~50/60Hz

Wattage 2000W

Cord length 5m

Weight 4.1kg

Dirt Capacity: 2.0L

Technical Specication

Subject to technical change without notice.

Filter pack*

VWCF2 Filter Pack

Accessories & Consumables

*To purchase consumables and accessories, please visit vax.com.au Made in China.

Double

Insulated

This product

meets applicable

regulatory

requirements

Indoor

Use

Only

Read

Instructions

Dirt container

Dirt container release latch

Variable power dial

Cord rewind button (hidden)

Wheel outer

Wheel inner

(lter hidden under

wheel cover)

Base

Main body

Power Button

Dirt container lid

Hose Connector

Inner seperator

Outer cyclone

Dirt container release latch

Dirt container handle

PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE

Getting started

CAUTION: Before plugging the cord into the electrical socket, make sure the switch is in the ‘o’ position.

Assembling your cylinder

Insert the end of the hose

into the unit. Ensure the

hose has clicked into place.

Slot the metal telescopic

extension tube and hose

handle together. All accesso-

ries can be tted to the end of

the metal telescopic extension

tube and hose handle.

Fully unwind the power

cord. A yellow mark on the

cord indicates the

recommended cord length.

Do not exceed the cord

beyond the yellow mark.

Plug in and switch the

unit on by pressing the

power button.

Using your machine

Hard oors

Carpets

How to use

Packing away and storage

Adjust the power by rotating

the dial for dierent surfaces

as required.

For use on carpets click

rocker switch forward. For

use on hard oors click rocker

switch back.

Cable rewind button is located

at the rear of the machine.

After unplugging press the

cable rewind until the cord is

fully retracted.

For convenience there is a parking slot located at the rear of the

vacuum cleaner where the oor head and tubes can be attached

for storage and carrying.

IMPORTANT: If the air inlet, hose or telescopic tube is blocked, switch o the vacuum cleaner and remove the

blockage(s) before re-starting the vacuum cleaner.

IMPORTANT: The motor is equipped with a thermal cut-out. If for any reason the unit should overheat, the thermostat

will automatically turn the unit o. Should this occur, unplug the vacuum cleaner from the electrical socket and turn

o the switch. Remove and empty the dirt container. Check the hose for blockages. Clean the lters. Allow the unit to

cool for approximately one hour (if you have washed the lters you will need to wait twenty four hours for the lters

to dry before putting them back in the machine). To re-start the machine, plug it into an electrical socket and switch it

back on.

Emptying and cleaning the dirt container

Cleaning the pre-motor lter

MAX

40˚C

24hr

Remove dirt container

by pushing down the dirt

container release button and

lifting the dirt container.

Hold the dirt container over a bin and press the dirt release latch

(located at the rear of the dirt container).

4 5 6

Hold the dirt container and

twist the lid anti-clockwise.

Lift the lid to reveal the

pre-motor lter.

Lift out the pre-motor lter.

Tap excess dirt from the lter. Rinse under a tap and leave to dry for 24 hours.

IMPORTANT: Water

temperature should

not exceed 40°C when

washing pre-motor lter.

IMPORTANT: Ensure

lters are completely dry

before inserting back into

the vacuum cleaner.

Taking care of your machine – Filters

2 3

Cleaning the shroud

Cleaning the HEPA media post-motor lter

TAP

1 4

Hold the dirt container and

twist the lid anti-clockwise.

Post motor lter is located in

the right side wheel. Hold the

centre of the wheel and twist

wheel cover anti-clockwise.

Ensure to align the arrows on

the lter cap when replacing

the lter cap back onto the

wheel.

Remove the inner separator

from the container.

Lift the lid to reveal the

pre-motor lter.

With the wheel cover o

the post-motor lter is

easily removed.

Remove the cap from the

inner separator.

Lift out the pre-motor lter.

Tap all excess dirt o the

lter. Do not wash.

Dislodge any excess dirt

by gently tapping the inner

separator upside down above

a bin.

Taking care of your machine – Filters What to do if it goes wrong
