Vax DynamoPower U85-DP-Be Bedienungsanleitung

U85-DP-Be

U85-DP-Pe

U85-DP-Re

U85-DP-Te

LET’S GET STARTED.

DynamoPower

Let’s talk safety

• Turn o all controls on the vacuum cleaner before disconnecting

or connecting the plug from the mains socket.

• Always keep the power cord away from the brushes during use.

After use always wrap the power cord around the cord

clips provided.

• Always make sure both the pre-motor/post-motor lters are

in place before use.

• Always ensure the brushbar is raised to the highest setting when

using the vacuum cleaner on the stairs and take extra care when

positioning the vacuum cleaner on the stairs.

Do’s

Please keep instructions for further use and use only as instructed

in this guide.

This vacuum cleaner is intended for household use only and NOT

for commercial or industrial use.

• Only use the vacuum cleaner indoors on dry surfaces and keep

the area you’re cleaning well lit.

• Keep ngers, hair and loose clothing away from moving parts

and openings whilst using the vacuum cleaner.

• This vacuum cleaner can be used by children aged from 8 years

and above and persons with reduced physical, sensory or mental

Basic

safety

precautions

• Don’t use this vacuum cleaner if it has been dropped,

damaged or left outdoors.

• Don’t run over the power cord or use vacuum cleaner if the power

cord or plug is damaged. Please contact our customer care line on:

0330 026 8455 (Mon-Fri 8:30am-6:30pm, Sat 9:00am-5:00pm).

• Don’t handle the plug or use the vacuum cleaner with wet hands.

• Don’t pull or carry this vacuum cleaner by the power cord.

• Don’t use the power cord as a handle, pull the power cord around

corners, sharp edges or close a door over the power cord.

• Don’t vacuum up any ammable or combustible materials (lighter

uid, petrol, kerosene etc.) or use the vacuum cleaner in an area

with explosive vapours or liquid.

Don’ts

Let’s talk safety

• Always switch o the vacuum cleaner before disconnecting or connecting

the hose and accessories.

• Keep all openings clear and free from debris as this may aect the airow/suction.

• Always replace the fuse in the plug with a British 13amp fuse. Always protect

the power cable from heated surfaces and open ames.

• Use only CE approved 13amp extension cords, non-approved extension cords

may overheat. Care should be taken to arrange the extension cord as it can

be a trip hazard.

• Store the vacuum cleaner in a cool, dry area. If lters have been cleaned as per

the user guide instructions ensure they are thoroughly dry before storing away.

capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the vacuum cleaner

in a safe way and understand the hazards involved. Children shall not play

with the vacuum cleaner. Cleaning and user maintenance shall not be made

by children without supervision.

• This vacuum cleaner is tted with a constantly rotating brush bar. To avoid

damage to your ooring, make sure the brush bar is raised to the highest setting

when using the accessories and when using on stairs.

• Only Vax recommend tools should be used with this vacuum cleaner,

use of non-branded Vax accessories/tools will invalidate your warranty.

• Don’t unplug vacuum cleaner by pulling on the power cord.

• Don’t vacuum up any ammable or combustible materials (lighter uid,

petrol, kerosene etc.) or use the vacuum cleaner in an area with

explosive vapours or liquid.

• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning

items or use in an area where there may be harmful uids (chlorine, bleach,

and ammonia drain cleaner).

• Don’t attempt to remove blockages with sharp objects as this may cause damage

to the vacuum cleaner. Remove blockages only as instructed in this guide.

• Don’t vacuum up hard or sharp objects such as glass, nails, screws or coins etc.

• Don’t use the vacuum cleaner with incorrect voltage as this may result in damage

or injury to the user. The correct voltage is listed on the ratings label.

Thank you for buying this Dynamo Power.

Taking care of your carpets and hard oors

The Dynamo Power is designed to make vacuuming carpets and hard oors regularly,

as eective and ecient as possible and this user guide will help you get the most out

of your machine.

Maintaining your carpets and hard oors will ensure they keep their appearance for longer.

You’ve chosen the carpets and hard oors for your home for a reason and Vax will help

you take good care of them.

Taking care of your Dynamo Power

Also inside this guide are instructions on maintaining your new machine, so that it’s always

ready when you are to tackle your carpets and hard oors.

Let us know what you think @VaxUK

Taking care of you

We’re here if you need us. Instead of taking me back

to the shop, simply visit:

vax.co.uk/support or call:

(UK) 0330 026 8455 (ROI) 1-800 928 308

Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm

Calls are charged at the UK local rate. Please make a note of the serial number and model number

of the product before calling.

Alternatively, you can write to us at:

Vax Ltd., Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich,

Worcestershire, WR9 0LW, UK

This user guide can be found online at: vax.co.uk/support

Contents

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

Let’s talk technical

What to do if it goes wrong

Getting in touch

Accessories

Dynamo Power

(Included in all models)

3-in-1 Tool (Crevice, Dust

and Upholstery Tool)

Included with

your machine

Pre-motor Filter

Post-motor Filter

TurboTool

Hard Floor Adaptor

Tool Connector

Up-top Tool

Initial Setup for normal operation

1. Use the base accessories.

– Shortest hose

– Extension tube set to shortest practicable length.

2. Clean lters installed.

3. Dust receptacle empty.

4. All Bleeds must be closed.

5. Floor heads/tools set to Carpet Mode for carpet cleaning.

6. Mechanical Agitation turned ON for carpet cleaning.

7. Floor heads/tools set to Hard Floor Mode for hard oor cleaning.

8. Mechanical Agitation turned OFF for hard oor cleaning.

Dynamo Power Pet

Dynamo Power Reach

Longer power cord

Dynamo Power

Total Home

Handle

TurboTool holder (not shown)

Post-motor lter cover

Hose to

machine

connector

Floor type

adjustor

Handle release button

Separator

Dirt container

release button Power

On/O button

Hose

Power cord

Getting to know your machine

Technical Specication

Name Dynamo Power

Voltage Please refer to product rating label

Wattage Please refer to product rating label

Cord length 7-10m

Weight 6kg

Accessories & Consumables

Filter Kit (Type 98)*

1-1-134233-00

Belt Kit (Type 1)*

1-1-130669-01

TurboTool (Type 6)*

1-1-134419-00

Subject to technical change without notice. *To purchase consumables and accessories, please visit vax.co.uk

Quick release

cord hook

Extension tube

(hidden)

Assembling your upright

Getting started

PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE

Insert the back panel into

the oorhead.

Insert the lower quick release

cord hook into the hole at the

bottom of the back panel.

Now take the small clip and

push it down between the

post-motor lter cover and

back panel, over the quick

release cord hook to lock

into place.

Insert the end of the hose

into the tube at the back of

the machine and connect the

hose end to the oorhead.

Place the dirt container onto

the machine and push until it

clicks into place.

Insert the extension tube into

the handle.

Push handle into the top of

the machine until it clicks

into place.

Push TurboTool holder on to

the handle.

Clip TurboTool into position.

If your model comes with a TurboTool

Using your machine

Twist the quick release

cord hook to release the

power cord.

How to use

Before you begin cleaning

• Always switch o and unplug the vacuum cleaner before connecting or disconnecting the hose/attachments, or removing and

emptying the dirt container.

• The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does overheat the thermostat

will automatically turn the vacuum cleaner o. If this happens, switch the vacuum cleaner o and unplug from electrical

socket. Remove and empty the dirt container also check the vacuum cleaner for blockages. Allow the vacuum cleaner to cool

for approximately 1 hour (if you have cleaned the lters please wait 24 hours for the lters to fully dry before putting back into

the vacuum).

• For best cleaning results, lters should be tapped over a bin every 4-6 uses to remove dirt and debris and washed

every 3 to 6 months (depending on the level of use).

• If the vacuum cleaner is blocked, switch o and unplug before removing the blockage.

• When using the accessories always make sure the brushbar is raised to the highest setting.

IMPORTANT: When the vacuum cleaner is stood in the upright position or when using on stairs and the hose/tools,

the brushbar height adjust dial must be set to hard oor.

Choose your desired carpet

height or hard oor setting.

Plug in your machine and

push On/O button to

switch on.

Don’t over ll the dirt

container to avoid clogging

your lter.

Lie vacuum cleaner on its

back exposing brushbar.

Align Hard Floor Adaptor

with base of vacuum

cleaner, push until its clicks

into place.

Using the Hard Floor Adaptor

Apply the Hard Floor Adaptor for optimum results on hard oors.

The Hard Floor Adaptor can be used on any oor setting.

TIP

To ensure the Hard

Floor Adaptor is

correctly tted,

the wheels should

be towards the back

of the oor tool

when attached to

vacuum cleaner.

Using your machine

Extension tube

Remove extension tube

from inside the handle.

Turn the extension tube and

attach to the handle.

Using accessories

Remove hose end from

the oorhead.

Attach hose to the top of

the handle.

Push accessory on to the

extension tube.

Choose an accessory.

“turbo tool some

models only”.

Attach accessory adapter to

hose end.

If required use

tool connector.

Hold the machine to steady

when using on the stairs.

Always make sure the

brushbar is overhanging the

stair tread during use.

Using your machine on the stairs

This machine

has a constantly

rotating brushbar.

When using the machine

on stairs, ensure the

height adjuster dial is set

to hard oor and the

brushbar is overhanging

the stair tread (as pic-

tured). Always take extra

care when cleaning stairs.

CAUTION

Taking care of your machine

Emptying and cleaning the dirt container

Press dirt container

release button to remove

the dirt container.

Hold dirt container over

a bin and unclip the lock

on the bottom of the dirt

container, allowing the dirt

to fall out.

Close the base of the dirt container, align the

dirt container base back onto the machine

and push until it clicks back into place.

Cleaning the pre-motor lter

Turn the dirt container

lid anti-clockwise.

Lift the dirt container lid

to remove.

Lift to remove the

pre-motor lter

MAX

40˚C

24hr

Wash the lter under

running water (40°C max).

Leave to fully dry for at

least 24 hours before

placing back in

the machine.

Tap the lter over a bin to

remove any dirt/debris

TIP

Wash lters with warm

water (MAX 40°C)

at least every

3 months.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Vax Staubsauger Handbücher

Vax

Vax Air3 Pet Plus VRS114 Montageanleitung

Vax

Vax DUAL V-124 Bedienungsanleitung

Vax

Vax W91-RS-B SERIES Bedienungsanleitung

Vax

Vax Flair C86-FD-Be Montageanleitung

Vax

Vax W87-DV series Bedienungsanleitung

Vax

Vax Dust & Vac Cordless HF86-DV-B Bedienungsanleitung

Vax

Vax Cordless VII VX67 Bedienungsanleitung

Vax

Vax V-118SP Bedienungsanleitung

Vax

Vax Powermax VRS3 Series Bedienungsanleitung

Vax

Vax Mach 2 SERIES Bedienungsanleitung

Vax

Vax Zoom U87-ZM-B Bedienungsanleitung

Vax

Vax VCW-01 Bedienungsanleitung

Vax

Vax Air3 Agile Bedienungsanleitung

Vax

Vax U86-PM Series Bedienungsanleitung

Vax

Vax V-031B Series Bedienungsanleitung

Vax

Vax H85-AC21-B Bedienungsanleitung

Vax

Vax 6131 Bedienungsanleitung

Vax

Vax Power Plus 6 Bedienungsanleitung

Vax

Vax Powerplus pet 18 V Bedienungsanleitung

Vax

Vax Sirit VR300 Bedienungsanleitung

Vax

Vax Essentials VEC-03 Bedienungsanleitung

Vax

Vax VCT-01 Bedienungsanleitung

Vax

Vax Power5 C85-P5-Be Montageanleitung

Vax

Vax U89-MAF SERIES Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
